Baby Bed Rail
V2
INSTRUCTION MANUAL
90cm
(35.4")
(17.7")
WIDE
Fits up to Queen size
Max 155cm / 61"
IMPORTANT! READ AND FOLLOW
THESE INSTRUCTIONS
CAREFULLY AND KEEP
FOR FUTURE REFERENCE.
This product complies with safety standard BS7972:2001+A1:2009
45cm
TALL
INSTALL VIDEO
Better Lives for Kids
#2774
Advertisement
Table of Contents
Related Manuals for Perma child safety V2
Summary of Contents for Perma child safety V2
- Page 1 INSTALL VIDEO Baby Bed Rail Better Lives for Kids INSTRUCTION MANUAL #2774 90cm 45cm (35.4”) (17.7”) WIDE TALL Fits up to Queen size Max 155cm / 61” IMPORTANT! READ AND FOLLOW THESE INSTRUCTIONS CAREFULLY AND KEEP FOR FUTURE REFERENCE. This product complies with safety standard BS7972:2001+A1:2009...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY INFORMATION General Maintenance Warnings 04-05 WHAT’S IN THE BOX Parts INSTALLATION Bar Installation Mesh & Bottom Rail Installation Hinge Installation Positioning the Bed Rail Positioning the Bed Rail - Minimum Distance OPERATION How to Operate Cleaning Instructions SUPPORT Warranty Certificate Warranty Card... -
Page 3: Safety Information
SAFETY INFORMATION GENERAL Read this instruction manual carefully and keep it in a safe place for future reference. The correct use and maintenance of this product is essential. MAINTENANCE Regularly check that the product is functioning correctly, lubricate hinges and moving components. Tighten and adjust mounts to ensure secure smooth operation. -
Page 4: Warnings
WARNING • Adult assembly required. • Carefully read all instructions before assembly and use of the product. • Dispose of all packaging materials carefully after assembly. • Not suitable for use of children under the age of 18 months or when the child is over the age of 5 years. •... - Page 5 WARNING • Any additional or replacement parts should be obtained from the Customer Service Centre of the entity you purchased this product. • The bed rail should not be used on a sleeping surface that is more than 600mm from the floor. •...
-
Page 6: What's In The Box
WHAT’S IN THE BOX PARTS 1 x Bed Rail Mesh 1 x Upper Support Bar 2 x 1.55m (Left & Right) Adjustable Straps & Under Bar 1 x Bottom Support Bar 1 x Bottom Rail (Left & Right) (Left & Right) -
Page 7: Installation
INSTALLATION Step 1. Bar Installation 1. Insert Upper Support Bar (left & right) into Bottom Support Bar (left & right). Fit vertically so that the pieces connect securely. 2. Connect the two sides horizontally and ensure the frame is connected securely. 3. -
Page 8: Mesh & Bottom Rail Installation
INSTALLATION Step 2. Mesh & Bottom Rail Installation 1. Fit the mesh over the frame. 2. Slide bottom rail through the loop of the mesh, then through one hole of bottom support bar, pushing the spring button on the rails. 3. -
Page 9: Hinge Installation
INSTALLATION Step 3. Hinge Installation 1. Slide both adjustable straps and under bars onto the assembled panel. Press the metal spring button inwards and slide further to connect. Ensure both sides are secure. Refer to below steps. -
Page 10: Positioning The Bed Rail
INSTALLATION Step 4. Positioning the Bed Rail 1. Put bed rail in locked position and place on the side you want protected. Place the round plates with the strap on the opposite side of the bed rail and mount to the outer edge of the bed frame. Adjust the sliders on the Straps and Under Bars to fit firm against the base of the bed. -
Page 11: Positioning The Bed Rail - Minimum Distance
INSTALLATION Step 4. Positioning the Bed Rail 2. Ensure both left and right under bar assemblies are parallel to one another, then place mattress on top of the bed rail. WARNING To prevent the risk of strangulation, ensure that when the bed rail is fitted into position, there is a gap of at least 220mm between each end of the bed and the corresponding end of the bed rail. -
Page 12: Operation
OPERATION HOW TO OPERATE Locked Position Swing panel up. Latches will automatically close once in 90˚ position. Bed rail is now locked. Unlocked Position Press down on both lock tabs simultaneously and swing the panel down. Bed rail is now unlocked. Always check Bed Rail is properly locked NOTE: and secure when in use. -
Page 13: Cleaning Instructions
CLEANING INSTRUCTIONS No part of Bed Rail requires lubrication. Clean using warm soapy water, or a damp cloth and dry thoroughly after cleaning. Do not use abrasive cleaners or bleach. -
Page 14: Support
SUPPORT WARRANTY CERTIFICATE Congratulations! You have made an excellent choice of this quality product. Our commitment to quality also includes our service. Should you, contrary to expectations, experience defects due to manufacturing faults, we will provide you with a warranty against defects as follows: WARRANTY The product is guaranteed to be free from from defects in workmanship and parts for a period of 12 months from the date of purchase. -
Page 15: Warranty Card
SUPPORT WARRANTY CARD DETAILS: Baby Bed Rail PRODUCT NAME: 2774 PRODUCT NUMBER: YOUR NAME: ADDRESS: PHONE: EMAIL: DATE OF PURCHASE: LOCATION OF PURCHASE: We recommend that you keep a copy of your receipt, showing the date of purchase, with this warranty certificate and keep for your reference. - Page 16 Scan the QR code for Live Chat Support or visit: permachildsafety.com/contact-us Perma Child Safety @permachildsafety...
