Wireless Alarm System
Note:
.
1
The alarm system is pre-programmed , please
proceed to part 2 of the manual for setup. (Or please
search "HTZSAFE T704&806A SETUP" on YouTube,
there is a video for your reference)
.
2
If you want to add additional HTZSAFE sensors to
the system, program them according to part 3 of the
manual or contact us directly. (Or please search
"HTZSAFE T704 to 806A Connect " on YouTube, there
is a video for your reference)
After-sale Service:
E-mail:
1. System Components And Usage
Power Plug
Volume
Melody
Power Plug:plug the receiver into a socket
Volume: 4 adjustable volume levels
Melody: 35 optional melodies
Zone Number: flash for several seconds when the sensor
be activated
1
User Manual
contact@saferhomee.com
Plug-in Alarm Receiver
Zone Number
Advertisement
Related Manuals for Htzsafe T704
Summary of Contents for Htzsafe T704
- Page 1 If you want to add additional HTZSAFE sensors to the system, program them according to part 3 of the manual or contact us directly. (Or please search “HTZSAFE T704 to 806A Connect “ on YouTube, there is a video for your reference) After-sale Service: E-mail: contact@saferhomee.com...
- Page 2 Speaker Speaker:sound for several seconds when the sensor be activated Solar Wireless Motion Sensor Solar Panel Sensor Eye Drain Hole Sensor Eye: detects heat movements Solar Panel:charges the built-in battery of the sensor Drain Hole:used to drain out the rainwater(please note the drain hole must be facing down when you install the sensor) Charge Jack ON/OFF...
- Page 3 ATTENTION PLEASE The KIT includes a USB charging cord without a AC adapter which is used to manually charge the solar sensor before use or after pro-longed low light conditions causing low battery. Please kindly connect the charging cord with your own USB plug(such as the direct USB outlet, the phone's USB plug or computer's USB, etc.).If needed,please charge the sensor for 4 hours with the USB charging cord...
- Page 4 2. Operation Instructions Step 1 Plug the receiver into an outlet Ring tone prompt and the zone number will light up one by one for 3 times meaning the receiver works properly. Step 2 Turn on the Wireless Motion Sensor: Press the ON/OFF button 4 times ON/OFF press 4 times...
- Page 5 Step 3 Activate The Wireless Motion Sensor (wait about 30 seconds after you turn on the sensor) 1st method:press the ON/OFF button twice ON/OFF press twice) (the light of the ON/OFF button will flash once meaning the motion sensor was activated and sent the wireless signal) 2nd method: Walk through in front of the sensor to acivate 1 foot way (the light of the ON/OFF button will flash...
- Page 6 Step 4 Press “Melody” once to choose the melody for this sensor, total 35 optional melodies. Melody Step 5 Same operation if you have the additional sensor, and please refer to part 3 of the manual for other settings. Step 6 Installation Wireless Motion Sensor long screws...
- Page 7 Installation Notes: 1. Please fix the motion sensor tightly to ensure the position and the direction will not be moved easily by wind. 2.Please point the sensor towards a open field (not towards the trees or bushes) 3.please adjust the sensor a little down(never upwards) 4.please point the sensor eye towards to the engine or exhaust pipe if detecting vehicles.(the working principle of the senor is detecting the movements with heat sources)
-
Page 8: Other Settings
3. Other Settings (1)How to add additional sensors to the receiver (up to 4 sensors can be added to one or multiple receivers) Step 1 Plug the receiver into an outlet Step 2 Press and hold the “Volume” button for 5 seconds, release the button when one of the zone number flashing and a beep prompt one of the zones flashing... - Page 9 Step 4 Activate the sensor again to confirm the sensor has been added to the receiver already. Step 5 Press”Melody”button to choose the melody for this sensor. total 35 optional melodies . Step 6 Same steps to add more sensors to the plug-in receiver. (For example: add the 2nd sensor to the receiver) Press and hold the “Volume button”...
- Page 10 (3)How to adjust the volume Step 1 Plug the receiver into an outlet Step 2 Press the “Volume” once to adjust the volume of the receiver. (total 4 adjustable volume levels) Volume (4)How to change the melody for the sensors (total 35 optional melodies,you can match a different melody for each sensor) Step 1...
-
Page 11: Technical Parameters
Step 2 To select Low sensitivity----turn on the sensor by pressing the ON/OFF button 3 times. To select Medium sensitivity----turn on the sensor by pressing the ON/OFF button 4 times. To select High sensitivity----turn on the sensor by pressing the ON/OFF button 5 times. 4. - Page 12 Wireless Motion Sensor 92mm 45mm 90mm 103mm Technical parameters Technical Parameters Item Low sensitivity--25feet(7.5m) Mid sensitivity--30feet(9m) Detection Range High sensitivity--50feet(15m) Detection Angle 1/4 Mile(400m) Wireless Transmission Range Wireless Frequency 433MHz FSK+FHSS 3.3V Working Voltage Battery Type Chargeable LiFePO4 Battery Battery Capacity 500mAh Working Current Static: 1mA;...
