Wireless Alarm System
Note:
.
1
The alarm system is pre-programmed , please
proceed to part 2 of the manual for setup. (Or please
search "HTZSAFE T804&808A SETUP" on YouTube,
there is a video for your reference.)
.
2
If you want to add additional HTZSAFE sensors/receivers
to the system, program them according to part 3 of the
manual or contact us directly. (Or please search
"HTZSAFE T804 to 808A Connect " on YouTube, there
is a video for your reference.)
After-sale Service:
contact@saferhomee.com
E-mail:
1. System Components And Usage
Power Plug
Volume
Melody
1
User Manual
Plug-in Receiver
Indicator Light
Advertisement
Table of Contents
Related Manuals for Htzsafe T804
Summary of Contents for Htzsafe T804
- Page 1 If you want to add additional HTZSAFE sensors/receivers to the system, program them according to part 3 of the manual or contact us directly. (Or please search “HTZSAFE T804 to 808A Connect “ on YouTube, there is a video for your reference.) After-sale Service: contact@saferhomee.com...
-
Page 2: Wireless Motion Sensor
Power Plug:plug the receiver into an outlet. Volume: 4 adjustable volume levels. Melody: 35 optional melodies. Indicator Light: flashes for several seconds when the sensor is activated/flashes once each 8 seconds if the battery of the sensors go flat. Speaker Speaker:sounds for several seconds when the sensor is activated. -
Page 3: Indicator Light
Indicator Light Sensitivity Jumper Battery Compartment Indicator Light: flashes once meaning the motion sensor was activated and sent the wireless signal. Battery Compartment: please insert 3 pieces AA 1.5V Alkaline batteries (not included). Sensitivity Jumper : Factory default is Low sensitivity, if you want to select High sensitivity, please take out the jumper slightly by the plier first, and insert the jumper back to the left two needles. - Page 4 (Or please search "T804 Sensitivity Setup" on YouTube,there is a video for your reference) If High sensitivity, the detection range of the sensor is 50 feet; If Low sensitivity, the detection range of the sensor is 35 feet.
- Page 5 Step 4 Wave your hands in front of the sensor eye to activate. 1 foot way (the indicator light of the sensor will flash once meaning the sensor was activated,and then the sensor will automatically reset after a few seconds ready for next trigger.) Step 5 Fix the back cover ( the back cover must be fixed well to...
-
Page 6: Installation
Step 6 Press “Melody” once to choose the melody for this sensor, total 35 optional melodies. Melody Step 7 Same operation if you have the additional sensor,and please refer to part 3 of the manuel for other settings. Step 8 Installation. - Page 7 Installation Notes: 1. Please fix the motion sensor tightly to ensure the position and the direction will not be moved easily by wind. 2.Please point the sensor towards a open field (not towards the trees or bushes). 3.please adjust the sensor a little down(never upwards). 4.please point the sensor eye towards to the engine or exhaust pipe if detecting vehicles.(the working principle of the senor is detecting the movements with heat sources).
-
Page 8: Other Settings
3. Other Settings (1)How to add additional sensors/receivers to the system (up to 32 sensors can be added to one or multiple receivers) Step 1 Plug the receiver into an outlet. Step 2 Press and hold the “Volume” button for 5 seconds and release the button when you hear a beep prompt and the indicator light flashes. - Page 9 flashing quickly 1 foot way (a ring tone prompt and the indicator (the indicator light will flash once light flashes quickly meaning the meaning the motion sensor was sensor has been added to the plug-in activated and sent the wireless signal) receiver successfully) Step 4 Activate the sensor again to confirm the sensor...
-
Page 10: Technical Parameters
(3)How to adjust the alarm volume Step 1 Plug the receiver into an outlet. Step 2 Press the “Volume” once to adjust the volume of the receiver (total 4 adjustable volume levels). Volume (4)How to change the melody for the sensors (total 35 optional melodies;... - Page 11 High sensitivity----50 feet(15m) 15° Detection Angle Wireless Transmission Range 1/2 Mile (800m) 433MHz FSK+FHSS Wireless Frequency 4.5V Working Voltage 3pcs AA 1.5V Alkaline Batteries Battery Type (not included Static≤1mA; Alarming≤100mA Working Current Working Temperature Range -22°F to 158°F（-30℃ to 70℃) 30-HB202011-808A(2.2)T804(1.1)-03...
