- Page 1 INSTRUCTIONS FOR USE RBC576DNC1 REFRIGERATOR WITH FREEZER RBC597SND1...
-
Page 2: Table Of Contents
Contents Introduction ..........Wooden bottle rack (BottleTray) ....Welcome to our growing ASKO family! ..MultiBox ............Important notes and precautions ..... Wooden tray (Serving Tray) ......Before using the appliance for the first Operating the appliance ......time .............. -
Page 3: Introduction
Link to the EU EPREL database Information about your product can be found at www.asko.com/energylabel, where you will also find a link to the European Product Database for Energy Labelling, EPREL. Or else visit https:// eprel.ec.europa.eu directly. Follow the instructions to search by model name (see the information on the serial number plate). -
Page 4: Important Notes And Precautions
Important notes and precautions Before using the appliance for the first time Before connecting the appliance to the power mains, please read carefully the instructions for use which describe the appliance and its correct and safe use. The instructions apply to several appliance types/models;... - Page 5 Important notes and precautions WARNING! WARNING! Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer. WARNING! WARNING! Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.
-
Page 6: Important Information On The Use Of Appliance
Important notes and precautions When removing a used appliance, disconnect the power cord, remove the door, and leave the shelves in the appliance. This will prevent children from locking themselves in the appliance. For European markets only This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning... - Page 7 Important notes and precautions • catering and similar non-retail applications. WARNING! WARNING! Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. The appliance may not be used outdoors and it may not be exposed to rain. Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance.
-
Page 8: Installation And Connection
Installation and connection Selecting the location • Place the appliance in a dry and well aired room. The permitted ambient temperature range for the appliance depends on the appliance's climate class, which is shown on the type plate. • Do not place the appliance near a source of heat, such as a gas cooker, radiator or boiler, etc., and do not expose it to direct sunlight. -
Page 9: Connecting The Appliance
Installation and connection • The kitchen unit in which the appliance is to be built in must have an opening of at least 200 cm in its base to allow sufficient air to circulate. • The appliance's air outlet is at the top. Make sure that the outlet is not blocked. Blocking the outlet can result in damage to the appliance. -
Page 10: Before Using The Appliance For The First Time
Before using the appliance for the first time Before you use the appliance for the first time Do not connect the appliance to the mains until you have carefully read the instructions for the correct and safe use of the appliance. As these instructions are for various types and models, it is possible that the instructions for use refer to settings or parts that are not available on your appliance. -
Page 11: Description Of The Appliance
Description of the appliance A Refrigerator 1. Control panel 2. Air distribution system 3. Wooden bottle rack (BottleTray) 4. Glass shelves 5. Wooden tray (Serving Tray) 6. DuraFresh drawers 7. Door compartments B Freezer 8. Freezer drawers Air distribution system The advanced ventilation system evenly distributes the air and equalises the temperature throughout the entire cooling section. -
Page 12: Drawers
Description of the appliance Drawers Many drawers are mounted on telescopic movable guides. To pull the drawer out of the guides, pull it out completely. Lift the drawer at the front to remove it from the latch and then pull it out completely. To insert the drawer into the guides, pull both guides out fully. -
Page 13: Glass Shelves
Description of the appliance Glass shelves Empty shelves can be rearranged as you see fit across the guides in the appliance interior. To move or remove them from the appliance, slightly lift them at the back, pull them towards you, push them down at the front and then move or pull them out of the appliance. -
Page 14: Operating The Appliance
Operating the appliance Control panel On/Off key: • A long press to switch the appliance on or off. Intensive cooling/freezing on/off key: • Use button 04 to navigate to the refrigerator or freezer section, and then use button 02 to turn intensive cooling/freezing on or off. -
Page 15: Initial Use
Operating the appliance Table continued from last page Wi-Fi key: • Press and hold (2 seconds) shortcut to enter the connectivity menu and Wi-Fi functions. • Install the ConnectLife application and create an account. • The application then guides you through the entire process of connecting the appliance to your smartphone. -
Page 16: Temperature Setting
Operating the appliance You switch on the appliance by pressing the on on/off key . The appliance will start cooling with the setpoint temperature. Setting the language Set the desired language in which the appliance’s display texts will appear. The default setting is ‘English’. - Page 17 Operating the appliance Temperature in the refrigerator compartment can be set by pressing 01 to select a compartment 02 and then pressing 05 to set the desired temperature. Refrigerator compartment temperature can be set in the range from +3 °C to + 9°C. The recommended temperature setting is 4 °C.
- Page 18 Operating the appliance Fast freeze (freezer compartment) • Use this setting after switching on the appliance for the first time, before cleaning, or before inserting a large amount of food. Switching it on: to activate the Fast Freeze function, first press 01 to select the freezer compartment 03 and then press and hold 04.
-
Page 19: Menu
Operating the appliance Switching it on: to activate the Super Cool function, first press 01 to select the refrigerator compartment 02 and then press and hold 04. Switching it off: to deactivate the Super Cool function, press 04. In the event that the Fast Freeze and Super Cool functions are activated at the same time, to deactivate the function, you must first press 01 to select the... - Page 20 Operating the appliance DURA FRESH GUIDE (DURA FRESH GUIDE) Use the left/right arrows to navigate through the options below in this menu. • SEAFOOD (SEA FOOD) (-2 °C) • FRESH FISH (FRESH FISH) (-2 °C) • CHEESE (CHEESE) (0 °C) •...
- Page 21 Operating the appliance ECO MODE (ECO MODE) off The ECO mode is automatically deactivated even when you change the temperature of one of the compartments and when another function with a higher priority is selected. HOLIDAY MODE (HOLIDAY MODE) Use this function when you are away for a long period of time, for example when you are going on holiday or taking a long business trip.
- Page 22 Operating the appliance CLEANING MODE (CLEANING MODE) This function is used when cleaning the refrigerator compartment when the refrigerator compartment door is open for a long time. WARNING! When using water, switch off the appliance and remove the plug. CLEANING MODE (CLEANING MODE) on CLEANING MODE (CLEANING MODE) off The CLEANING MODE is automatically deactivated even when you change the...
- Page 23 Operating the appliance KEY LOCK (KEY LOCK) When the appliance keys are locked, it is not possible to switch off the appliance or to change any setting. In the meantime, the appliance's cooling system is working normally. Settings can only be changed in the mobile app.
- Page 24 Operating the appliance Connection setup (Connection setup) (after the Wi-Fi modul is activated the appliance is ready to connect to the mobile app. Follow instructions in the mobile app on how to connect) Unpair all (Unpair all) (activate to disconnect all paired user profiles from the appliance connected services).
-
Page 25: Alarms
Operating the appliance • Factory reset (Factory reset) (Restore factory default settings.) Alarms Please refer also to chapter "Tips & Tricks" to learn more about possible reasons for each particular alarm. All alarms will be displayed using the alarm pop-up. Temperature alarm If the temperature inside the appliance is too high, an acoustic alarm will be activated (intermittent tone) and the display will show a pop-up window with the information in which compartment the... -
Page 26: Storing And Freezing Food
Storing and freezing food Avoid contamination of food To avoid contamination of food, please respect the following instructions: • Opening the door for long periods can cause a significant increase of the temperature in the compartments of the appliance. • Regularly clean surfaces that can come in contact with food and accessible drainage systems. -
Page 27: Thawing Frozen Food
Storing and freezing food • Put the food directly on a shelf and on the base of the freezer. Freezing small quantities of fresh food/making ice cubes See the chapter ‘Recommended distribution’ for the best location for freezing fresh food (1 to 2 kilograms) and making ice cubes. - Page 28 Storing and freezing food • Some frozen products can be prepared without needing to thaw them first. The manufacturer will state this on the packaging. • The food needs to be packed in small portions. In this way the food thaws faster. •...
-
Page 29: Maintenance
Maintenance Defrosting the appliance The modern Total NoFrost technology in the freezer compartment prevents the formation of ice and the accumulation of frost on foods, thus enabling economical operation, greater transparency and full use of space. In the refrigerator compartment, it prevents food from drying out, as it maintains its humidity and freshness. -
Page 30: Faults
Faults Faults table When you have any doubts about whether your appliance is working properly you should not immediately assume that it is defective. We recommend that you should in any case check the points in the following table. Problem Cause/Solution •... - Page 31 Faults Table continued from last page Problem Cause/Solution Door does not open easily. You are trying to open the appliance's door just after you have closed the door. Then opening the door is difficult. When you open the door, cold air escapes from the appliance and is replaced by warm air from the surroundings.
- Page 32 Faults Table continued from last page Problem Cause/Solution The display shows error Freezer compartment temperature sensor error or fault. Call a service code t2. centre for repair. Until the appliance is repaired by a service technician, the appliance will operate in safe mode. The appliance will automatically maintain the most suitable temperature for each compartment.
-
Page 33: Environmental Aspects
Environmental aspects Disposal of packaging and appliance This appliance is made from sustainable materials. This appliance must be disposed of in a responsible manner at the end of its service life. Contact the local authorities for information about the method. INFORMATION! See also the chapter ‘Disposal’... -
Page 34: Compliance Information
Compliance information Radio equipment type: Wi-Fi module Operating frequency range: 2,412 GHz - 2,472 GHz Maximum output power: 20 dBm EIRP Maximum antenna gain: 2,7 dBi Radio equipment type: HL3215STG HLW3215-TG HLW3215-TG01 Wi-Fi Operating frequency range: 2,412 GHz - 2,472 GHz Maximum output power: ≤10 dBm/MHz ( EIRP) (Antenna gain 10 dBi) Maximum antenna gain:... -
Page 35: Your Notes
Your notes... - Page 36 The instructions for use can also be found on our website: www.asko.com 944766...
