- Page 1 SERENADE Wireless DAC and Headphone Amplifier PROFESSIONAL DIGITAL TO ANALOG CONVERTER WIFI HIFI...
- Page 2 3.Turn off the SERENADE Wireless’s power, remove the network cable, and restart SERENADE Wireless. You can get more detailed WI-FI setup tutorials by contacting HIFIMAN customer service. SELECT Function The SELECT button adjusts the brightness of the display. Additional features will be added after a firmware upgrade.
- Page 3 Real Panel Introduction Single-ended Analog Signal Balanced Analog Coaxial Digital WI-FI Plug/Switch (110V or 220V selection Output Signal Output Signal Input Antenna depending on the actual setting) FUSE: 2A/250V, 5*20mm Single-ended Analog Optical Digital Network Signal Input Signal Input Connector Connector upgrade Design Block Diagram...
-
Page 4: Specifications
Specifications and Package Contents Specifications Frequency Response: 20Hz-20KHz, ±0.1dB@1KHz THD+N: 0.0015%, -3dBFS@1KHz Signal to Noise Ratio: -110dB, 0dBFS@1KHz Channel Separation: -120dB, 0dBFS@1KHz DAC output level : 4.5V/XLR, 2.2V/RCA, 0dBFS@1KHz Headphone amplifier power output: THD+N<0.07% @1KHz, balanced output: 4000mW@32Ω, 760mw@300Ω; single-end output: 2800mW@32Ω, 510mW@300Ω Weight: ~3.9KG Dimension: 300*255*50mm, protrusions not included Package Contents... - Page 5 SERENADE Wireless is warrantied for a period of one year beginning with the original date of purchase. If you join the official HIFIMAN group on Facebook, your product warranty will be extended for an additional six months. Please contact HIFIMAN customer service if you need any assistance.
- Page 6 HIFIMAN Correct disposing of waste electrical and electronic equipment (WEEE) and symbol of the “crossed-out wheeled bin” The crossed-out wheeled bin on WEEE means that you are obliged by law to dispose of this equipment separately from the unsorted municipal waste collection system. Disposing of it in the residual waste bin, the yellow bin or yellow bag for recyclable materials is legally prohibited.
