Summary of Contents for mundoclima MU-IN
- Page 1 AIR CURTAIN User and installation manual MU-IN EC06471 to EC06474 This unit must be installed by a professional according CE 795/2010. English...
-
Page 2: Installation Caution
IDENTIFICATION & INSTALLATION DIMENSIONS MODEL 347.5 347.5 MU-IN 09 1200 347.5 295 347.5 MU-IN 12 1500 390.5 504 390.5 MU-IN 15 MU-IN 18 1800 INSTALLATION CAUTION Must follow the following asking when installing air curtain: 2.1 Please install the unit in a sturdy place to 2.2 Please install the unit inside the room. -
Page 3: Installation
2.3 Don’t install the unit too low, no less than 2.4 When the entrance is wider than the unit, it 2.3 meter from the ground. is recommended to install two or more units in parallel. In this case, provide 20-40mm gaps between the units. - Page 4 B. Installing on the wooden wall 3.2.1 Fix the mounting plate in the proper 3.2.2 Same as the step 3 of A positions with tapping screw. C. Hanging from the ceiling 3.3.1 Remove the mounting plate from main 3.3.2 Fixing ceiling brackets as Fig. body (Same as step3.1.1) 3.3.3 Set the mounting plate on the ceiling 3.3.4 Do the same as step A to install the...
-
Page 5: Technical Parameter
Air volume Noise power speed Volt. Freq Net weight (dB) Model (m/s) (V~) (Hz) (Kg) 1100 MU-IN 09 1500 1200 18.5 MU-IN 12 1900 1500 MU-IN 15 MU-IN 18 2280 1800 WIRING DIAGRAM OPERATION 6.1 Turn on the power switch 6.2 Select the best speed: High[H], Low[L]... -
Page 6: Technical Assistance
ASK FOR MORE INFORMATION: Phone: +34 93 446 27 80 - Fax: +34 93 456 90 32 eMail: mundoclima@salvadorescoda.com TECHNICAL ASSISTANCE: Phone: +34 93 652 53 57 - Fax: +34 93 635 45 08...
