Chevrolet EQUINOX 2025 Manual

INSTRUMENT PANEL

Instrument Panel Overview - Part 1

Instrument Panel Overview - Part 2
Optional equipment

SYMBOLS

Low Fuel
Brake System Warning
Cruise Control Set
Security
Forward Collision Alert
Fog Lamps
Traction Control/ StabiliTrak Active
Airbag Readiness
High-Beam Headlamps
Check Engine
Traction Control Off
Stability Control Off
Lights On Reminder
Antilock Brake System
Charging System
Low Tire Pressure
Lane Keep Assist
Pedestrian Ahead
Engine Oil Pressure
Engine Coolant Temperature Warning
Auto Stop
Door Ajar
Parking Brake Set
Vehicle Ahead
Service Electric Parking Brake
Driver Seat Belt Reminder

Due to current supply-chain shortages, certain features shown have limited or late availability, or are no longer available. See the window label or your dealer regarding the features on an individual vehicle.
Some equipment shown may not be included in your vehicle.

REMOTE KEYLESS ENTRY TRANSMITTER (KEY FOB)

Lock
Press to lock all doors.
Unlock
Press to unlock the driver's door.
Press again to unlock all doors and liftgate.
Power LIftgate
Press twice to open or close the liftgate.
Press once to stop power liftgate operation.

Vehicle Locator/Panic Alarm
Press and release to locate your vehicle.
Press and hold to activate the alarm.
Press again to cancel the alarm.

Remote Vehicle Start
Press twice to start the engine from out side the vehicle. After entering the vehicle, press the ENGINE START/STOP button.

  • The engine will run for 15 minutes. Repeat the steps to extend the remote start an additional 15 minutes.
  • To cancel a remote start, press the button until the parking lamps turn off.

Key Release
If vehicle power is lost, press the button on the side of the key fob to pull out the door key.

Note: To change the remote settings, go to Settings > Vehicle > Remote Lock, Unlock and Start on the infotainment screen.
See Keys, Doors and Windows in your Owner's Manual.

KEYLESS ACCESS SYSTEM

The Keyless Access System enables operation of the doors and liftgate without removing the Remote Keyless Entry transmitter (key fob) from your pocket or bag. The key fob must be within 3 feet of the liftgate or the door being unlocked/locked.

KEYLESS UNLOCKING

With the key fob within range:
Keyless Unlocking

  • Press the button on the driver's door handle to unlock the driver's door; press again within 3 seconds to unlock all doors and liftgate.
  • Press the button on a passenger's door handle to unlock all doors and liftgate.
  • Press the touchpad above the license plate to open the liftgate.

KEYLESS LOCKING

With the ignition off, the key fob removed from the vehicle, and all doors closed:

  • Press the button on any door handle to lock all doors and liftgate immediately.
  • All doors will lock automatically after a short delay once all doors are closed if Passive Locking is turned on in the Settings menu.

Note: To change the lock settings, go to Settings > Vehicle > Remote Lock, Unlock and Start on the infotainment screen.
See Keys, Doors and Windows in your Owner's Manual.

KEYLESS (PUSH-BUTTON) START

The Remote Keyless Entry transmitter (key fob) must be in the vehicle to turn on the ignition.

STARTING THE ENGINE

Starting the Engine

  • With the transmission in Park or Neutral, press the brake pedal and then press the ENGINE START/STOP button. The button indicator will be green.

Note: If the key fob battery is weak, place the key fob in the center console to enable the engine to start. Replace the key fob battery as soon as possible.

STOPPING THE ENGINE/OFF

  • Shift to Park and then press the ENGINE START/STOP button.

ACCESSORY MODE

  • With the engine off and the brake pedal not depressed, press the ENGINE START/STOP button to place the ignition in accessory mode. The button indicator will be amber.

See Driving and Operating in your Owner's Manual.

AUTO ENGINE STOP/START OPERATION

The fuel-saving stop/start system automatically turns off the engine, referred to as an Auto Stop, when the brake pedal is applied and the vehicle is at a complete stop, if certain operating conditions are met. In Auto Stop mode, the symbol displays in the Driver Information Center. When the brake pedal is released or the accelerator pedal is pressed, the engine will restart.

AUTO STOP DISABLE

  • To turn off the system, press the Auto Stop button on the left side of the instrument panel.

The Auto Engine Stop/Start system is enabled each time the vehicle is started.
See Driving and Operating in your Owner's Manual.

BUCKLE TO DRIVE

Buckle to Drive delays the vehicle from shifting out of Park if the engine is running, the brake pedal is pressed, and the driver's and front-seat passenger's seat belts are not buckled. Buckle the seat belts to shift out of Park. If a seat belt remains unbuckled, the vehicle can be shifted out of Park once the Driver Information Center message turns off after several seconds. Shifting from Park is delayed once each ignition cycle.

  • To turn off or on again, go to Settings > Vehicle > Buckle to Drive on the infotainment screen. The vehicle may need to be restarted to register the setting change.

Note: Rear Seat Reminder also will provide an alert if 2nd-row passengers have taken off their seat belts.
See Seats and Restraints in your Owner's Manual.

DIGITAL DRIVER INFORMATION CENTER

The reconfigurable Driver Information Center (DIC) displays a variety of vehicle messages and system information.
Digital Driver Information Center Overview

DIC CONTROLS

Use the controls on the right side of the steering wheel to view and select Vehicle, Audio and Phone information.
DIC Controls Overview

  • Press the Display button to view and scroll through the cluster display layouts.
  • Press the or switch to scroll through the active menu.
  • Press the switch to open a menu, or to select or reset an item.

VEHICLE INFORMATION

  1. Press the Vehicle Status icon on the infotainment screen to view all available vehicle information.
  2. Select the Maintenance, Gauges or Trip button, or select an item on the vehicle graphic.
  3. Select an item to view additional information or to reset an item.
  4. When viewing an item, select Add to Driver Display to display an item or Remove from Display to remove an item on the driver display.

See Instruments and Controls in your Owner's Manual.

ELECTRONIC PRECISION SHIFT TRANSMISSION

The automatic transmission is electronically controlled using the shift lever on the right side of the steering column. The selected position is illuminated in red on the lever and is shown on the cluster display.
Electronic Precision Shift Transmission Overview
Park – Press the P button on the end of the lever to shift into Park.
Reverse – Press the brake pedal and then pull the lever toward you and up to shift into Reverse.
Neutral – Press the brake pedal and then pull the lever toward you and hold briefly to shift into Neutral.
Note: The vehicle will not stay in Neutral for an extended period. It will automatically shift into Park.
See Car Wash Mode in your Owner's Manual.

Drive – Press the brake pedal and then pull the lever toward you and down to shift into Drive.
Manual Mode — With the transmission in Drive, press the L (Low) button on the steering wheel. Press the top-left (-) button (on the back of the steering wheel) to reduce the highest gear available and the top-right (+) button (on the back of the steering wheel) to increase the highest gear available. Press the L button again to return to Drive.
See Driving and Operating in your Owner's Manual.

ELECTRIC PARKING BRAKE

  • To apply the parking brake, press the Parking Brake button on the left side of the instrument panel.
  • To release the parking brake, turn on the ignition, press the brake pedal, and then press the button.

Note: The parking brake will automatically release if the vehicle is running, placed into gear, and an attempt is made to drive away.
See Driving and Operating in your Owner's Manual.

STEERING WHEEL ADJUSTMENT

  • With the vehicle parked, push down the lever under the left side of the steering column to adjust the steering wheel. The steering wheel can be moved up or down and in or out. Pull up the lever to lock the steering wheel in place.

See Instruments and Controls in your Owner's Manual.

POWER FRONT SEATS

Power Front Seats Overview

  1. Seat Adjustment
    Move the horizontal control to move the seat forward or rearward and to tilt, raise or lower the seat.
  2. Seatback Recline Adjustment
    Move the vertical control to recline or raise the seatback.
  3. Lumbar Support Adjustment
    Press and hold the round control to adjust the lumbar support.

SET MEMORY SEATS

  1. Adjust the seat and power outside mirrors.
  2. Press and release the SET button; a beep will sound.
  3. Immediately press and hold button 1 or 2 until two beeps sound.
  • To save a seat position for more clearance when entering or exiting the vehicle, repeat these steps using the Exit button instead of button 1 or 2.

RECALL MEMORY POSITIONS

  • Press and hold button 1, 2, or Exit until the saved position is reached.
  • To set the memory/exit positions to be recalled automatically when the ignition is turned on/off (for exit recall, the driver's door must be opened), go to Settings > Vehicle > Seating Position > Seat Entry Memory and Seat Exit Memory.

See Seats and Restraints in your Owner's Manual.

REAR SEAT REMINDER

A Rear Seat Reminder message may display on the Driver Information Center when the vehicle is turned off. Always check the rear seat before exiting the vehicle. The system does not actually detect people or items in the rear seat; instead, under certain conditions, it detects when a rear door has been opened, indicating that there may be something in the rear seat.
See Seats and Restraints in your Owner's Manual.

REAR SEATS

RECLINING THE REAR SEAT

  • Pull the lever (A) on top of the seatback and move the seatback to the desired position. Release the lever.

FOLDING THE REAR SEAT

Folding the Rear Seat

  1. Press the button on the head restraint.
  2. Pull the lever (A) on top of the seatback — a tab near the lever is visible when the seatback is unlatched — and fold the seatback forward.
  3. Stow the seat belt in the belt clip.

POWER LIFTGATE

OPEN/CLOSE THE POWER LIFTGATE

Open/close the Power Liftgate

  • Press the Power Liftgate button on the key fob twice.
  • Press the Power Liftgate button (A) on the driver's door.
  • Press the touchpad on the liftgate handle to open the liftgate.
  • Press the button next to the liftgate pull handle to close the liftgate.
  • To change the power liftgate settings, go to Settings > Vehicle > Comfort and Convenience on the infotainment screen.

AUTOSENSE POWER LIFTGATE

The liftgate will open automatically when the key fob is within 3 feet of the rear of the vehicle for 3 seconds. 4 beeps sound before the liftgate will open. Press and hold the liftgate handle touchpad until the taillights flash to disable or enable Autosense.

PROGRAMMING THE LIFTGATE HEIGHT

  1. Open the liftgate and adjust it manually to the desired position.
  2. To save the setting, press and hold the button next to the liftgate pull handle until the turn signals flash and a beep sounds.

See Keys, Doors and Windows in your Owner's Manual.

INFOTAINMENT SYSTEM

Read your Owner's Manual for important information about using the infotainment system while driving.
The infotainment system uses a Bluetooth or USB connection to link to a compatible device, such as a smartphone or portable audio player, and offers hands-free voice control. Use simple gestures on the touchscreen, such as tap, drag and swipe, to interact with the system. For additional information, visit chevrolet.com/support.
Infotainment System Overview

MANAGING HOME PAGE ICONS

  1. Press the Home icon.
  2. To enter edit mode, touch and hold the Home page icon to move.
  3. Continue holding the icon and drag it to the desired position on the screen or the app tray, and then release.

STORING FAVORITES

Radio stations from all bands (AM, FM or SiriusXM) can be stored in any order.

  1. Tune in a radio station. The Sources menu is at the top of the Audio page.
  2. Touch and hold one of the Favorite buttons until a beep is heard.

SIRIUSXM WITH 360L™

The personalized content of SiriusXM with 360L offers more than 200 channels, including ad-free music, sports, comedy, talk and news, along with access to On Demand shows, performances and interviews. Certain features require a SiriusXM subscription and a Connected Access plan. See siriusxm.com and onstar.com for details.

GOOGLE BUILT-IN

Google built-in provides access to your favorite apps, including Google Assistant, Google Maps and Google Play.

  • Sign in to your Google Account to get your apps, messages, custom directions and more in your vehicle.

Google Assistant – Talk to Google to get hands-free help. Easily get directions, play media, control vehicle functions and more.

  • To start, say "Hey Google," tap the Google Assistant icon on the Home page, or press the Push to Talk button on the steering wheel.

Google Maps – Reach your destination faster with real-time traffic information, automatic rerouting and voice control. Sign in for personalized maps with home and recent locations.
Google Play – Download some of your favorite apps in your vehicle just as you would on your phone to listen to music, podcasts, audiobooks and more.
Note: Google built-in services are subject to limitations and availability may vary by vehicle, infotainment system and location. Select service plan required. Certain Google actions and functionality may require account linking. User terms and privacy statements apply. Google, Google Play and Google Maps are trademarks of Google LLC.

APPLE CARPLAY® AND ANDROID AUTO™

  1. There are two ways to connect to Apple CarPlay or Android Auto:
    • Wireless Connection – Connect your phone by pairing it to the in-vehicle Bluetooth system. Turn on wireless Apple CarPlay or Android Auto in your phone's settings.
    • Wired Connection – Connect your phone to a USB data port using the USB cable provided with your phone. Aftermarket USB cables may not work.
  2. Follow the instructions on the infotainment system and the phone.
  3. The Apple CarPlay or Android Auto icon will illuminate when connected. Touch the icon to have your apps displayed.

PORTABLE AUDIO DEVICES

A smartphone, MP3 player or a USB flash drive can be connected to a USB data port located at the front of the center console.

  • Touch Audio and then touch Source to select the USB device.

NATURAL VOICE RECOGNITION

Control the music source and make phone calls hands-free (after pairing your Bluetooth-enabled phone) using the natural voice recognition system.

  1. Press the Push to Talk button on the steering wheel. A prompt will be played.
  2. After the prompt, say what you want it to do using natural speech. Example: "Call Dave." Say "Help" for assistance.

See Infotainment System in your Owner's Manual.

BLUETOOTH® SYSTEM

Read your Owner's Manual for important information about using the Bluetooth system while driving. Before using a Bluetooth-enabled device in the vehicle, it must be paired with the invehicle Bluetooth system. The vehicle must be stopped to pair a device. Not all devices will support all functions. Visit chevrolet.com/support for more information.

PAIR A PHONE

  1. Press the Push to Talk button to start the pairing process on the infotainment screen (if a phone is not connected) or select the Phone icon > Manage Phones > +Add Phone on the infotainment screen.
  2. Start the pairing process on your phone. From the phone's Bluetooth settings, select the name shown on the infotainment screen.
  3. Follow the pairing instructions.
  4. When pairing is complete, the phone screen is displayed.

FIRST TO CONNECT PAIRED PHONE

Multiple phones can be paired to the Bluetooth system. The system connects to the paired phone that is set as First to Connect.

  • To set the First to Connect phone, select Settings > Connections > Phones > Options for the connected phone > First to Connect.

See Infotainment System in your Owner's Manual.

5G LTE WI-FI® HOTSPOT

With the vehicle's available built-in 5G LTE Wi-Fi hotspot, up to 7 devices (smartphones, tablets and laptops) can be connected to high-speed internet. Visit onstar.com for more information.

  • To retrieve the name and password for the hotspot, select the Wi-Fi Hotspot icon or go to Settings > Connections > Wi-Fi Hotspot on the infotainment system.

See Infotainment System in your Owner's Manual.

WIRELESS PHONE CHARGING

The wireless charging system for smartphones is located at the front of the center console. To check device compatibility, visit chevrolet.com/support. See your phone retailer for details on required phone accessories.

  1. The vehicle must be On, or Retained Accessory Power must be active.
  2. Remove all objects from the charging pad.
  3. Place the phone horizontally on the pad with the screen facing up.
  4. The charging symbol will appear on the infotainment screen when charging. If not charging, remove the phone for 3 seconds, and rotate it 180 degrees, before placing it on the pad again.

See Instruments and Controls in your Owner's Manual.

AUDIO/PHONE STEERING WHEEL CONTROLS

Audio/Phone Steering Wheel Controls
Push to Talk
Press to use natural voice recognition with the Bluetooth system of a paired, compatible phone.
Answer/End Call
Press up to answer an incoming call and down to end a call, or to mute/unmute the speakers.
Audio
Press to display the Audio source on the Driver Information Center.
Volume (back of right side of steering wheel)
Press the top or bottom button to adjust the volume.
Next/Previous Favorite Station (back of left side of steering wheel)
Press the top or bottom button to go to the next or previous favorite radio station or track (on a connected device).
See Infotainment System in your Owner's Manual.

VEHICLE CUSTOMIZATION

Some features can be turned on/off or customized using the Settings menus on the infotainment screen, including Buckle to Drive, Door Locks, Driver Assistance and others.
Vehicle Customization

  1. Select Settings on the Home page.
  2. Select the desired menu item.
  3. Select the desired feature and setting.
  4. Press <Back to exit each menu.

See Infotainment System in your Owner's Manual.

CLIMATE CONTROLS

Climate Controls Overview
Dual Automatic Climate Controls shown

AUTOMATIC OPERATION

  • Press AUTO.
  • Set the temperature.

The system automatically controls the fan speed, air delivery, air conditioning and recirculation functions. Allow time for the system to reach the set temperature. If a function is manually adjusted, the Auto indicator light turns off and automatic operation for that function is disabled.
See Climate Controls in your Owner's Manual.

SUNROOF

Sunroof

  • Press or pull the SLIDE switch to express-open or express-close the sunroof. Press or pull again to stop operation.
  • Press or pull the TILT switch to vent the sunroof.
  • Press or pull the Sunshade switch to express-open or express-close the sunshade. Press or pull again to stop operation.

See Keys, Doors and Windows in your Owner's Manual.

WIPERS AND WASHERS

Rotate the outer band to activate the windshield wipers.
Wipers and Washers

OFF
INT Intermittent Wipes

Rotate the band up for more frequent wipes or down for less frequent wipes.

LO Slow Wipes
HI Fast Wipes
Single Wipe

Push the button on the end of the lever to the first stop for a single wipe. Hold the button for additional wipes.
Washer Fluid
Push the button on the end of the lever completely to wash the windshield.
Rear Window Wiper
Rotate the inner band to activate the rear wiper and wash the rear window.
See Instruments and Controls in your Owner's Manual.

EXTERIOR LIGHTING

  • Unique entry and exit lighting illuminates the exterior and interior of the vehicle. To adjust the lighting settings, go to Settings > Vehicle > Lighting.
  • Select the Automatic Light Control icon on the infotainment screen to turn the auto headlamps on/off.
  • To enable the IntelliBeam system, which automatically turns the high-beam headlamps on/off based on traffic conditions at night, go to Controls > Lights > Auto High Beams. The exterior lamps must be in the Auto setting. A green on the instrument cluster indicates the system is on. A blue appears when the highbeam headlamps are on.
    Note: IntelliBeam activates the high-beam headlamps only when driving more than 25 mph.
  • To operate the exterior lamp controls, go to Controls > Lights > Headlights on the infotainment screen. Select the Auto setting to have the exterior lamps turn on or off automatically, depending on outside lighting conditions.

See Lighting in your Owner's Manual.

CRUISE CONTROL

SETTING CRUISE CONTROL

  • Press the On/Off button. The Cruise Control symbol will illuminate in white on the instrument cluster.
  • When traveling at the desired speed, press down the switch to the SET position to set the speed. The symbol will illuminate in green on the instrument cluster.

ADJUSTING CRUISE CONTROL

Adjusting Cruise Control
+RES Resume/Accelerate
Press up to resume a set speed. When active, press once to increase speed 1 mph; press and hold to continue increase speed.
–SET Set/Coast
When active, press down once to decrease speed 1 mph; press and hold to continue decreasing speed.
Cancel
Press the button, or press the brake pedal, to cancel Cruise Control without erasing the set speed from memory.
The set speed is erased when Cruise Control or the vehicle ignition is turned off.

ADAPTIVE CRUISE CONTROL

The system enhances regular Cruise Control to automatically maintain a driver-selected following gap — the time between your vehicle and a vehicle detected directly ahead — by accelerating or braking automatically while you continue to steer.

  • Press the Following Gap switch to select a targeted gap setting of Far, Medium or Near. This is also the Forward Collision Alert setting.
  • Press and hold the Cancel button to switch between regular regular Cruise Control and Adaptive Cruise Control.

See Driving and Operating in your Owner's Manual.

DRIVER MODE CONTROL/AWD

The Driver Mode Control system automatically adjusts various vehicle control systems based on driving preferences, weather and road conditions.
Driver Mode Control/AWD

  • Rotate the MODE knob on the center console to activate each available drive mode.
  • Press the AWD button on the left side of the instrument panel to select the All-Wheel-Drive mode.

See Driving and Operating in your Owner's Manual.

DRIVER ASSISTANCE SYSTEMS

Safety or driver assistance features are not a substitute for the driver's responsibility to operate the vehicle in a safe manner. The driver should remain attentive to traffic, surroundings and road conditions at all times. Read your Owner's Manual for important feature limitations and information.
Following are some of the many advanced driver assistance systems that may be on your vehicle. Refer to your Owner's Manual for more information on all available systems.

CHEVY SAFETY ASSIST PACKAGE

  • To turn some of the following systems on/off or to change some settings, go to Settings > Vehicle > Collision/Detection Systems on the infotainment screen.

FORWARD COLLISION ALERT – The Vehicle Ahead Indicator is green on the instrument cluster when a vehicle that you're following is detected, and it is amber when you're following a vehicle ahead much too closely. When approaching a detected vehicle directly ahead too rapidly, a red alert flashes on the windshield and rapid beeps sound (if selected).

  • Press the Forward Collision Alert button on the steering wheel to set the alert timing to Far, Medium or Near.

FOLLOWING DISTANCE INDICATOR – The following distance to the vehicle detected ahead is indicated in seconds on the instrument cluster.

AUTOMATIC EMERGENCY BRAKING – The system works with Forward Collision Alert to help you avoid or reduce the severity of front-end collisions with a detected vehicle you're following. Camera technology is used to automatically provide hard emergency braking or enhance the driver's hard braking.

FRONT PEDESTRIAN BRAKING – During daytime driving below 50 mph, the system can detect pedestrians directly ahead and displays an amber indicator on the instrument cluster. When approaching a detected pedestrian too quickly, a red alert flashes on the windshield and rapid beeps sound. The system may also automatically provide hard emergency braking or enhance the driver's hard braking. Nighttime and low-visibility performance are limited.

LANE KEEP ASSIST WITH LANE DEPARTURE WARNING – The system may help you avoid collisions due to unintentional lane departures. The Lane Keep Assist indicator is green if the system is available to assist. If the vehicle approaches a detected lane marking, the system may assist by gently turning the steering wheel to help prevent lane departure and displays an amber . If active driver steering is not detected, the amber may flash and beeps may sound on the side of the departure direction as the lane marking is crossed. The system does not continuously steer the vehicle; the driver needs to steer and be in complete control of the vehicle. Alerts do not occur when using the turn signal in the lane departure direction or intentional lane departure is detected.
Note: IntelliBeam automatic high-beam headlamps are included with the Chevy Safety Assist Package. See Exterior Lighting.

SAFETY ALERT SEAT – The driver's seat pulses — left, right, or both sides — to alert the driver of the direction of potential hazards. Audible alerts or seat-pulsing alerts may be selected.

BLIND ZONE STEERING ASSIST – The system works with Lane Keep Assist to help you avoid a potential collision with a detected vehicle in an adjacent lane. While driving, a warning symbol is displayed on the left- or right-side mirror when a moving vehicle is detected rapidly approaching or is in that side blind zone. The warning symbol flashes if a turn signal is activated when a vehicle has been detected on the same side. If a vehicle is detected in the adjacent lane that you are entering, the system provides a brief, firm steering wheel turn to alert you to take action and beeps sound or the Safety Alert Seat pulses (if selected). The green Lane Keep Assist indicator will turn amber and the warning symbol will flash on the left- or right-side mirror. The steering correction will occur even when using the turn signal in the lane departure direction.

INTERSECTION AUTOMATIC EMERGENCY BRAKING — The system can help you avoid or reduce the severity of an intersection collision with a detected cross-traffic vehicle. It provides alerts and may automatically provide hard emergency braking or enhance the driver's hard braking.

REAR PEDESTRIAN ALERT – During daytime driving with the vehicle in Reverse, the system can detect pedestrians directly behind the vehicle and will display an amber indicator on the infotainment screen. When a pedestrian is detected close to the vehicle, the indicator flashes red and the Safety Alert Seat pulses or rapid beeps sound (if selected). Nighttime and low visibility performance are limited.

PARK ASSIST WITH BRAKING – During low-speed parking maneuvers, the system provides "distance to closest object" information on the instrument cluster and a beep sounds (if selected). When an object is very close, 5 beeps sound (if selected). The system may apply hard emergency braking, if you have not already done so, to help reduce the severity or help avoid collisions at very low speeds.

REAR CROSS-TRAFFIC BRAKING – When in Reverse, the system warns of detected cross traffic approaching in either direction and provides alerts and hard emergency braking to help reduce the severity or help avoid collisions at very low speeds.

REAR VISION CAMERA – When the vehicle is in Reverse, a view of the area directly behind the vehicle displays on the infotainment screen.

  • Touch the Guidance Lines button on the screen to turn the guidelines on or off.

HD SURROUND VISION – The system uses multiple cameras to display a high-resolution image of the area around your vehicle along with front- and rear-camera views on the infotainment screen. It works at low speeds and can help when parking.

  • Touch one of the Camera View screen buttons on the screen to change the view.
  • Select the Settings screen button to turn the guidelines on or off.

See Driving and Operating in your Owner's Manual.

REAR CAMERA MIRROR

The Rear Camera Mirror provides a wider, less-obstructed field of view than a traditional mirror to assist when driving, changing lanes and checking traffic conditions.

  1. On/Off
    Pull/push the lever at the bottom of the mirror to turn the video display on/off.
  2. Selection Control
    Press and release the button to select the brightness, zoom or tilt setting.
  3. Adjustment Controls
    Press and release either button to adjust the selected setting.

TRACTION CONTROL & STABILITRAK SYSTEMS

The traction control system limits wheelspin and the StabiliTrak® electronic stability control system assists with directional control of the vehicle in difficult driving conditions. Both systems turn on automatically every time the vehicle is started. Turn off traction control if the vehicle is stuck and rocking the vehicle is required.

  • To turn traction control or electronic stability control (ESC) on or off, go to Controls > Drive & Park > Traction Control.

See Driving and Operating in your Owner's Manual.

TIRE PRESSURE MONITORING WITH TIRE FILL ALERT

The Low Tire Pressure light on the instrument cluster illuminates when one or more of the vehicle's tires is significantly underinflated (excluding the spare tire). Fill the tires to the recommended pressures listed on the Tire and Loading Information label, located below the driver's door latch. Current tire pressures can be viewed on the Driver Information Center.
The Tire Fill Alert provides visual and audible alerts to help when inflating a tire to the recommended cold tire pressure (excluding the spare tire). The horn sounds and the turn signals change from flashing to solid when the recommended pressure is reached.
Note: Refer to your Owner's Manual for additional information about routine tire maintenance.
See Vehicle Care in your Owner's Manual.

ROADSIDE ASSISTANCE

1-800-CHEV-USA (1-800-243-8872)
TTY Users: 1-888-889-2438

As the owner of a new Chevrolet, you are automatically enrolled in the Chevrolet Roadside Assistance program for up to 5 years/60,000 miles, whichever occurs first, at no expense to you. The Chevrolet Roadside Assistance toll-free number is staffed by a team of trained advisors who are available 24 hours a day, 365 days a year to contact a service provider for light services (fuel delivery, jump start, flat tire and lockout) or make arrangements to tow your vehicle to the nearest Chevrolet dealer for any repairs.

ONSTAR® ROADSIDE ASSISTANCE
If you have a current OnStar Safety & Security plan, press the blue OnStar button or red Emergency button (for emergencies only) to get the help you need. An OnStar advisor will use GPS technology to pinpoint your vehicle location and contact the nearest service provider.
To learn more about OnStar services, press the blue OnStar button, visit onstar.com, call 1-888-4-ONSTAR (1-888-466-7827), or refer to your Owner's Manual.

MYCHEVROLET MOBILE APP

Download the myChevrolet app to your compatible smartphone (or device) and, if your vehicle is properly equipped, you can use your device to start or turn off your engine, lock or unlock your doors, view key diagnostic information, see your parking location and more.
The app is available on select Apple and Android devices. Service availability, features and functionality vary by vehicle, device and data plan. Device data connection required. Visit onstar.com for more details. Download the mobile app from the App Store or Google Play Store.

www.apple.com

play.google.com

MY CHEVROLET ACCOUNT

Get to know more about your vehicle and review your plans, services and rewards with your Chevrolet account. Check out an online Owner's Manual and how-to videos, track your service history and warranty status, manage your OnStar and Connected Services vehicle plans, review your current Vehicle Diagnostics report (active service account required) and more. Scan the QR code or go to chevrolet.com/owners to create an account today.

♦ Optional equipment
Some equipment shown may not be included in your vehicle.

We recommend always using ACDelco or GM Genuine Parts.
chevrolet.com

Documents / Resources

References

Download manual

Here you can download full pdf version of manual, it may contain additional safety instructions, warranty information, FCC rules, etc.

Download Chevrolet EQUINOX 2025 Manual

Advertisement

Need help?

Need help?

Do you have a question about the EQUINOX 2025 and is the answer not in the manual?

Questions and answers

Table of Contents
