Amana APCH3 Manual

Standard Features
• Energy-efficient scroll compressor
• Multi-speed ECM indoor blower motor
• Quiet horizontal discharge
• All-Aluminum evaporator coil
• Copper tube / aluminum fin condenser coil
• Compressor sound blanket
• Totally enclosed, permanently
lubricated condenser fan motor
• Fully charged system
• Electric heat kit available as a
field-installed option
• AHRI Certified; UL listed
SS-APCH3-R32
Amana® is a registered trademark of Maytag Corporation or its related companies and is used under license. All rights reserved.
Cabinet Features
• Heavy-gauge galvanized-steel cabinet
with attractive Architectural Gray
powder-paint finish
• Aluminum foil-facing internal insulation
reinforced with fiberglass scrim
• Meets cabinet air leakage requirements
when tested in accordance with ASHRAE
standard 193
• Fully insulated blower compartment
with convenient access panels
• Louvered condenser coil protection
• One footprint for all tonnages
• When properly anchored, meets the 2023 Florida
Building Code unit integrity requirements for
hurricane-type winds (Anchor bracket kits available.)
* Complete warranty available from your local dealer or at www.amana-hac.com. To receive the 10-Year Parts
Limited Warranty, online registration must be completed within 60 days of installation. Online registration
is not required in California, Florida, or Québec. The duration of warranty coverages in Texas and Florida
differs in some cases. Other limitations and exclusions apply, refer to complete warranty details for full list of
limitations and exclusions.
www.amana-hac.com
APCH3
Packaged Air Conditioner
13.4 SEER2
2 to 5 Tons
Contents
Nomenclature ...................................... 2
Product Specifications .......................... 3
Expanded Cooling Data ........................ 4
Airflow Data ....................................... 18
Heater Kit Specifications ................... 19
Dimensions ......................................... 20
Wiring Diagram .................................. 21
Accessories ......................................... 23
03/25
