ENDA EPV242 PROGRAMMABLE AC/DC VOLTMETER
Thank you for choosing ENDA EPV242 Programmable AC/DC voltmeter.
77 x 35 mm sized
4 digits display
Selectable number of decimal point
Indicates between -999V and +9999V by using voltage transformer
Easy to use front panel keypad
Multi-function alarm output for lower and upper limits (NO + NC)
Multi-function alarm setpoints with alarm output (NO)
Communication feature over isolated RS485, using ModBus RTU protocol (Optional)
Measuring type can be selected as AC, DC or true RMS
CE Marked according to Europan Norms.
Order Code : EPV242 -
1 - Supply Voltage
UV.......90-250V AC
LV........10-30V DC /
8-24V AC
Technical Specifications
ENVIRONMENTAL CONDITIONS
Ambient / Storage Temperature
Max. Relative Humidity
Rated Pollution Degree
Height
Do not use the device in locations subject to corrosive and flammable gases.
ELECTRICAL CHARACTERISTICS
Supply Voltage
Power Consumption
Wiring
Scale
Sensitivity
Accuracy
Input Range
Input Impedance
Frequency Range
EMC
Safety Requirements
OUTPUTS
Output
Life Expectancy for Relay
HOUSING
Housing Type
Dimensions
Weight
Enclosure Material
While cleaning the device, solvents (thinner, gasoline, acid etc.) or corrosive materials must not be used.
SİSEL MÜHENDİSLİK ELEKTRONİK SAN. VE TİC. A.Ş.
Şerifali Mah. Barbaros Cad. No:18
ÜMRANİYE/İSTANBUL-TURKEY
Tel : +90 216 499 46 64 Pbx.
url : www.enda.com.tr
