KIT CONTENTS
2.
Determine mounting location and wire routing path.
Recommendation: Under vehicle hood, on vehicle frame
or along other wiring bundles. Avoid sharp edges, heat
and moving parts.
Quick Start Guide
TRUCK / SUV WARN® HUB RECEIVER
1.
Download the WARN® HUB App (HUB
App) from the App Store or Google Play.
Data rates may apply.
Apple is a trademark of Apple Inc., registered in the U.S. and in other
countries. App Store is a service mark of Apple Inc.
Google Play is a trademark of Google Inc.
MOUNT
3.
Using the included zip-ties, mount HUB Receiver firmly
to vehicle.
4.
Route the winch remote plug end behind the vehicle
grille and towards the winch remote socket plug. NOTE:
Make sure to route wires/cables away from sharp edges,
heat and moving parts.
NOTE: Zip tie cables to vehicle in regular intervals to keep cables secure and
in place.
BEFORE YOU BEGIN
WARN HUB
Advertisement
Table of Contents
Related Manuals for Warn 103955
Summary of Contents for Warn 103955
- Page 1 Quick Start Guide TRUCK / SUV WARN® HUB RECEIVER KIT CONTENTS BEFORE YOU BEGIN Download the WARN® HUB App (HUB App) from the App Store or Google Play. WARN HUB Data rates may apply. Apple is a trademark of Apple Inc., registered in the U.S. and in other countries.
- Page 2 Quick Start Guide TRUCK / SUV WARN® HUB RECEIVER WIRE POWER The HUB Receiver is active when the yellow light is on. Connect HUB Receiver to winch remote plug. o avoid NOTICE vehicle battery drain, unplug the d-plug from winch and secure...
- Page 3 WARN® HUB Receiver General Safety/ Tips/Trouble Shooting/ Customer Service Guide WARNING Always Know Your Winch. Take time to fully read these instructions, your quick start guide and the Basic Guide to Winching Techniques, in order to understand your product operations.
-
Page 4: Information To User
FCC Regulation equipment. In cases where the manual is provided only in a form other than paper, such as on a computer disk or over the Internet, the This device complies with Part 15 of the FCC Rule. Operation is information required by this section may be included in the manual in subject to the following two conditions: that alternative form, provided the user can reasonably be expected... -
Page 5: Trouble Shooting/Error Conditions
• Be sure to allow vehicle to charge before using. Low battery voltage operation • Check battery connections. Receiver connected to • The WARN HUB receiver is not designed for continuous winch with solenoid use with some legacy solenoid control packs. control pack HUB overheating •... -
Page 6: Maintenance
Problem Possible cause Corrective action Smart device is out of • Move closer to the receiver. range Interference with an other • Disconnect from other bluetooth devices. device Bluetooth turned off on • Follow device owner’s manual to turn on Bluetooth. smart device Receiver will •...
