Super Handy GUT172 Operator's Manual

7RDGMXVWWKHKHLJKWRIDUPUHVWV
(Fig.19)
• Loose knob on handle.
• Move armrest to required position.
• Tighten knob.
7.3.4 To remove the seat
• Turn the power OFF.
• Make sure the wheelchair is not in freewheel mode.
• Push the seat rotate lever while pulling up on the seat
to remove.
7.3.5 To rotate around the seat (Fig.20)
• Turn the power OFF.
• Make sure the wheelchair is not in freewheel mode.
• Lift up the seat rotate lever and then rotate the seat.
• Release the lever and carry on rotating the seat until it
locks in position.
7.3.6 To change the seat height (Fig.21)
• Remove seat (See "To remove the Seat")
• Remove the base cover.
• Disengage and remove the seat height adjustment
pin from the seat post.
• Remove the height adjustment pin from each of the
four posts.
• Raise or lower each post to the desired position.
• Reinstall the seat height adjustment pin through the
seat post and armrest post. (Bend the end of the pin
lock and position it over the end the pin.)
• Reinstall the base cover.
• Reinstall the seat.
• Plug the connectors into the electronics tray.
EN
Bolt Bolt
Fig. 20
Fig. 21
Armrest Armrest
Rotate Lever Rotate Lever
Fig. 19
14
