Super Handy GUT172 Operator's Manual

Compact power wheelchair
Hide thumbs Also See for GUT172:
Table of Contents

Advertisement

Quick Links

Download this manual
Compact Power Wheelchair | GUT172
Operator's Manual
Warning: Please read and thoroughly understand all instructions before operating. Failure to follow
safety rules and other basic safety precautions may result in serious personal injury. Keep these
instructions in a safe and easily accessible place so that they can be referred to when needed. Retain
these instructions to assist in future servicing.
superhandyus.com
© SuperHandy All Rights Reserved | Version 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GUT172 and is the answer not in the manual?

Questions and answers

Related Manuals for Super Handy GUT172

Summary of Contents for Super Handy GUT172

  • Page 1 Compact Power Wheelchair | GUT172 Operator’s Manual Warning: Please read and thoroughly understand all instructions before operating. Failure to follow safety rules and other basic safety precautions may result in serious personal injury. Keep these instructions in a safe and easily accessible place so that they can be referred to when needed. Retain these instructions to assist in future servicing.

  • Page 2: Table Of Contents

    1. INTRODUCTION --------------------------------------------------------------------------------------------------------------------------- 2 2. SAFETY ----------------------------------------------------------------------------------------------------------------------------------- 2-5 2.1 BEFORE DRIVING ---------------------------------------------------------------------------------------------------------------------- 2 2.2 WHILE DRIVING --------------------------------------------------------------------------------------------------------------------- 2-4 2.3 EMI ------------------------------------------------------------------------------------------------------------------------------------- 4-5 3. TECHNICAL SPECIFICTIONS ----------------------------------------------------------------------------------------------------------- 6 4. COMPONENTS AND FEATURES ------------------------------------------------------------------------------------------------------- 7 5. ASSEMBLY ----------------------------------------------------------------------------------------------------------------------------- 8-10 5.1 CONNECT BATTERY CABLE ------------------------------------------------------------------------------------------------------- 8 5.2 ASSEMBLE SEAT ------------------------------------------------------------------------------------------------------------------ 8-9 5.3 CONNECT POWER CABLE -------------------------------------------------------------------------------------------------------- 10 6.

  • Page 3: Introduction

    1. INTRODUCTION Please carefully read this owner’s manual before using the power wheelchair. Improper use of the power wheelchair could result in harm, injury or traffic accidents. This owner’s manual includes operating instructions for every aspect of the power wheelchair, including assembly instruc- tions and how to deal with possible accidents.
  • Page 4 2.2.2 Do not move your body out of the power wheelchair while moving • Such action may cause you to lose balance and risk injury from falling. • Pay attention that your clothes do not tangle in the wheels. 2.2.3 Do not use your power wheelchair under any of the circumstances below. •...

  • Page 5: Emi

    ATTENTION • Avoid putting all of your weight on the footrest. This may cause the power wheelchair to tip. possibly resulting in injury. • Do not turn the power switch to OFF while driving as this will lead to an emergency stop and possible risk of accident and injury.

  • Page 6: Electromagnetic Interference (Emi) From Radio Wave Sources

    2.3.1 ELECTROMAGNETIC INTERFERENCE (EMI) FROM RADIO WAVE SOURCES Powered power wheelchair may be susceptible to electromagnetic interference (EMI), which is interfering electromagnetic energy (EM) emitted from sources such as radio stations, TV stations, amateur radio (HAM) transmitters, two-way radios, and cellular phones. The interference (from radio wave sources) can cause the power wheelchair to release its brakes, move by itself, or move in unintended directions.

  • Page 7: Technical Specifictions

    3. TECHNICAL SPECIFICTIONS SKU# GUT172 Max. Weight Capacity 300 lbs / 136 kgs Max. Drive Speed 4.0 MPH / 6.4 km/h Max. Reverse Speed 1.6 MPH / 2.5 km/h Max. Range 6.7 miles / 10.7 km Climbing Angle 6° (10.5%) Turning Radius 19.5"...

  • Page 8: Components And Features

    4. COMPONENTS AND FEATURES Backrest Joystick Armrest Controller Adjustment Bolts Seat Frame Separation Handle Base Cover Drive Wheel Footrest Front Castor Fig. 01...

  • Page 9: Assembly

    5. ASSEMBLY 5.1 CONNECT BATTERY CABLE • Loosen and remove the two knobs on the base cover. Lift up the base cover to remove. (Fig.02) Fig. 02 Fig. 03 • Connect the battery pack. Refit the base cover and tighten the two knobs to secure. (Fig.03) 5.2 ASSEMBLE SEAT Fig.
  • Page 10 • Insert the arms in to the seat. Set the arms to the Fig. 05 required width then secure by turning the armrest knobs clockwise. (Fig.05) • Set the arms to the required height, then secure by Fig. 06 turning the armrest knobs clockwise. (Fig.06) •...

  • Page 11: Connect Power Cable

    5.3 CONNECT POWER CABLE • Plug the cable from the joystick remote in to the port at the center of the powerchair base. (Fig.08) 6. DISASSEMBLE The powerchair can be quickly and easily separated into 4 sections: seat assembly, front section, and rear section (with or without batteries) and the battery pack.

  • Page 12: Disconnector Battery Connector

    6.4 DISCONNECTOR BATTERY Fig. 11 CONNECTOR • Disconnect the batteries connector and lift up the battery pack to remove. (Fig.11) Fig. 12 6.5 SEPARATE CHASSIS • Lift up the yellow handle to separate the chassis. This can be done with or without the batteries installed. (Fig.12) 7.

  • Page 13: How To Operate Your Power Wheelchair

    7.1.1 Battery Indicator • The battery gauge shows you that the power wheelchair is switched on. It also indicates the operating status of the power wheelchair. • When the powerchair is turned on, the battery gauge will light up from left to right with red, orange, and green lights indicating: •...

  • Page 14: How To Adjust The Seat

    7.2.2 JOYSTICK depth adjustment Fig. 16 Your power wheelchair may be equipped with an adjustable joystick. This function enables you to move the joystick from the armrest to the desired position. (Fig.16) 7.2.3 BRAKING Electro-magnetic brake: Release the speed control lever completely, and the electromagnetic brake will be activated automatically, and the power wheelchair will stop.
  • Page 15 7.3.3 To adjust the height of armrests Fig. 19 (Fig.19) Armrest Armrest • Loose knob on handle. • Move armrest to required position. • Tighten knob. 7.3.4 To remove the seat Bolt Bolt • Turn the power OFF. • Make sure the wheelchair is not in freewheel mode. •...

  • Page 16: How To Adjust The Footrest

    7.4 HOW TO ADJUST THE FOOTREST Fig. 22 7.4.1 To adjust the footrest height (Fig.22) • Remove the screw and nut. • Adjust footboard to one (1) of three (3) mounting Bolt positions. • Reinstall the screw and nut. Make sure the screw locking.

  • Page 17: Drving The Powerchair

    7.7 DRVING THE POWERCHAIR • You must exercise awareness, caution, care, and common sense when operating your powerchair. Always keep in mind your own limitations and substance use. • Users may encounter difficult manoeuvring situations such as narrow doorways, travelling up and down ramps, cornering, and travelling on uneven terrain.

  • Page 18: Battery Charging And Care

    8. BATTERY CHARGING AND CARE 8.1 BATTERY Use proper batteries • The Power wheelchair uses two long- lasting, 12 volt, deep-cycle batteries. These batteries are sealed and maintenance free. Since they are sealed, there is no need to check the electrolyte (fluid) level. Deep-cycle batteries are designed to handle a longer and deeper discharge.

  • Page 19: Cleaning The Battery

    SUGGESTION How to maximize your battery’s efficiency and service life • Fully charge any new battery before its initial. • Be sure to charge the battery fully every time. Battery life will be seriously diminished if the battery is repeatedly used without being fully charged.

  • Page 20: Inspection And Maintenance

    9. INSPECTION AND MAINTENANCE 9.1 INSPECTION Initial adjustments should be made to suit personal body structure and preference. Thereafter, follow these checks and maintenance procedures. Item Initially Weekly Monthly Periodically General (Mechanical Troubleshooting) • Power wheelchair rolls straight ○ ○ (no excessive drag or pull to one side).

  • Page 21: Regular Checking Record

    9.2 REGULAR CHECKING RECORD To make sure your power wheelchair is correctly serviced, take it to your dealer for regular maintenance checks. The initial inspection should be made after the first month’s use, thereafter every six months. Your dealer may charge a fee for this. Year Year Service Dates...

  • Page 22: Storage

    ATTENTION Before doing any maintenance, turn the power switch to OFF and remove the charger cords. SUGGESTION • Do not splash water onto the power wheelchair as this could cause the electronic system to malfunction. • Do not use petrol, solvents or aerosols as these may deform or damage the base covers. •...

  • Page 23: Trouble Shooting

    10. TROUBLE SHOOTING 10.1 TROUBLE SHOOTING Symptom Possible cause Solution Limited driving distance. 1. Batteries not fully charged. 1. Charge batteries overnight or ensure 10 hours 2. Batteries weak won’t hold charge. of charge between uses. Make sure setting on charger is correct.
  • Page 24 10.2 Error Indication • If there is an error with the system when it is powered up, then the status indicator will flash red; the number of flashes will indicate the type of error. • The table below describes the error indication, and a few possible actions that can be taken to rectify the problem. The actions listed are not in any particular order and suggestions only;...

  • Page 25: Warranty

    10.3 POWERCHAIR INDIFICATION NUMBER Fig. 26 (Fig.26) To ensure the correct after sales service and warranty service support, please record the power wheelchair identification number found on the rear right-hand side of the frame. Identification Number Identification Number 11. WARRANTY Twelve (12) months for workmanship of the product, except for wearing parts.
  • Page 28 Thank you for your most recent purchase. Great Circle USA Follow us on social media Support Line: 1-866-493-0524 @SuperHandy help@greatcircleus.com www.superhandyus.com Size: 210x285mm 157克双铜 REV 07/12/24...
