Bayou Classic 700-727 Assembly Instructions Manual

2.5 gallon fryer workstation
Hide thumbs Also See for 700-727:

Advertisement

Quick Links

MODEL #
700-727
2.5 GALLON BAYOU
ASSEMBLY INSTRUCTIONS
PARTS INCLUDED
Side Work Surface
LP Cylinder Retainer
Fryer Cradle
Lid Handle
Hose & Regulator Assembly
with Gas Inlet Cover attached
Fryer Body
HARDWARE PACK
Includes hardware and tools necessary for proper assembly.
An adjustable wrench (not provided) may also be useful.
Replacement Silicone Drain Gasket (not shown)
5mm Allen Wrench
Regulator Hook
10mm/17mm Wrench
(26x) M6 x 10 Round Head Socket Bolt
F
(10x) M6 x 70 Round Head Socket Bolt
G
(10x) M6 x 12 Socket Head Bolt
H
(4x) M6 Nut
I
(10x) M6 Flat Washer
J
Cotter Pin
K
Clevis Pin, 8mm diameter x 9mm Long
WORKSTATION
(2x) Vertical Cart
(2x) Horizontal
Support
Cart Support
Oil Tank Bracket
Cart Base
®
Leg Support
Cap
(2x) Locking
Caster
Left Front
(2x) Caster
Gas Inlet Tube
Fryer Basket
Thermometer
Drain Valve
G
I
B
FRYER
Cutting Board
Right Rear
Left Rear
Drain Rack
Right Front
(4x) Cart Legs
Side Handle
with Bezels
Exhaust Pipe
J
H
F
K
Pan Lid
Food Pan

Advertisement

loading
Need help?

Need help?

Do you have a question about the 700-727 and is the answer not in the manual?

Questions and answers

Summary of Contents for Bayou Classic 700-727

  • Page 1 MODEL # 700-727 2.5 GALLON BAYOU FRYER ® WORKSTATION ASSEMBLY INSTRUCTIONS PARTS INCLUDED Cutting Board Leg Support (2x) Vertical Cart (2x) Horizontal Support Cart Support Pan Lid Side Work Surface (2x) Locking Caster Right Rear Left Rear LP Cylinder Retainer...
  • Page 2 ASSEMBLY INSTRUCTIONS Assemble this appliance according to these instructions: 1. Remove and carefully inspect the contents of this box to ensure all parts are included. Please contact Barbour International, Inc. if any parts appear damaged or missing. Proof of purchase will be required. 2.
  • Page 3 5. Return the assembly to an upright position and lock the Locking Casters to provide stability for the remaining steps. 6. Attach the Vertical Cart Supports using . (Figure 5) 7. Place the Fryer Cradle onto the right side of the cart between the Vertical Cart Supports and the Right Legs. Secure the Fryer Cradle in place using .
  • Page 4 10. Attach Side Handle to the Cart. The attachment hardware is already screwed into the handle with the bezels in place. Remove the bolts and use them to attach the Side Handle with Bezels from the inside of the Work Surface. (Figure 10) (Figure 10) View from underside of Work Surface...
  • Page 5 13. Attach Exhaust Pipe to the LEFT opening on back of the appliance using , and . (Figure 12) 14. Attach Gas Inlet Tube to the RIGHT opening on back of the appliance using , and . (Figure 13) LEFT RIGHT REAR REAR...
  • Page 6 16. Test Thermometer BEFORE installing it into the appliance. While wearing a protective glove, hold the thermometer by the dial and insert the stem into boiling water. The needle should quickly move around the dial and register approximately 212°F/100°C (plus or minus 5°F/2.78°C). This indicates whether or not the temperature reading is accurate.
  • Page 7 19. Lock basket handle into place by inserting the bent ends into the loops of the basket. Then, with some pressure, carefully force the handle bars around the lock at the top. (Figure 21) When operating, the baskets will hook onto the metal rod at the back interior of the appliance. (Figure 22) (Figure 21) (Figure 22) 20.
  • Page 8 Contact Barbour International, Inc. for all replacement parts. After appliance has been fully assembled, refer to the FRYER OWNER’S MANUAL (A) that accompanies the Bayou® Fryer for complete instructions regarding set-up, testing, operation, and maintenance. Barbour International, Inc. 101 Cypress Way, Brandon, MS 39042 1-800-736-8028 (English Only) Monday - Friday •...
