SimLab XP-1 Instruction Manual page 8

Throttle configuration
This pedal is easy to setup, be it stock or after you have changed the springs. There
are two main options basically. The throttle spring can be adjusted to be more stiff
or soft. Unlock the blue knobs and tighten (clockwise) the adjustment knob (A) for
a stiffer throttle feel. To go softer, do the opposite. When you are happy with the
change, hold the adjustment knob (A) and tighten the locking knob (L) against it, this
locks your change in place.
L A
The same principle applies to the maximum travel of the pedal. On the bottom of
the pedal arm you will find two blue knobs as well. The inner one is the travel locking
knob (L), the outer one is the travel adjustment knob (A). Turning the adjustment
knob clockwise results in less travel, turning the adjustment knob anti-clockwise
results in more travel. By default, the pedal has been setup to provide a middle of the
road range of travel but you are free to experiment.
L
A
8
