  • Page 1 ® BRACKET PRO SERIE® 92 - FL4 OPERATING GUIDE SAFETY AND FLEXIBILITY WHERE IT MATTERS MOST...
  • Page 2: Copyrights

    - Sapphire is a trademark of Eitan Medical Ltd. ® For any issues with your Technimount product, its components, or for any technical questions during the installation, operation, or maintenance, please contact Technical Support at techsupport@technimount.com. Contact Information Technimount E.M.S. Holding Inc.
  • Page 3: Table Of Contents

    ..2.5. Operate the Bracket Pro Serie 92 - FL4 IV pole .....................12 3. Perform the Daily Safety Checks ........................13 ..3.1. Required Tools ................................13 ..3.2. Daily Safety Checks ..............................13 ..3.3. Illustrated Inspections Points ............................15 © 2023 Technimount E.M.S. Holding Inc. OG-BP92FL4-202307EN-01 | Page iii of iii...
  • Page 4: Safety Guidelines

    - Perform the safety checks, as described in the operating guide. Failing to follow the recommended guidelines could cause premature damage to the product. CAUTION - Safe Handling and Operation Improper use of the Technimount product may damage the equipment or cause injury to the patients or EMS personnel. CAUTION - Safe Practice - Always pay close attention to the condition of the safety mechanisms to prevent undue risk to the equipment, patients, and EMS personnel.
  • Page 5: Operate The Bracket Pro Serie 92 - Fl4

    NOTE: Always perform the Safety checks before using the Bracket Pro Serie 92 - FL4. Refer to the "Daily Safety Checks" on page 13 before each use. NOTE: Technimount continually seeks advancements in product design and quality. While this operating guide contains the most updated product information available at the time of printing, it may contain minor differences from the current version.
  • Page 6: Install The Infusion Pump In The Bracket Pro Serie 92 - Fl4

    3. Angle the pump and lean it against the front fold of the pump holder, aligning the cavities with the inserts at the bottom of the pump holder (Figure 4 A). © 2023 Technimount E.M.S. Holding Inc. OG-BP92FL4-202307EN-01 | Page 6 of 16...
  • Page 7 8. Plug the infusion pumps. Refer to the medical device manufacturer documentation for proper installation, use and operation. The installation of the infusion pumps in the Bracket Pro Serie 92 - FL4 is complete. © 2023 Technimount E.M.S. Holding Inc. OG-BP92FL4-202307EN-01 | Page 7 of 16...
  • Page 8: Remove The Infusion Pump From The Bracket Pro Serie 92 - Fl4

    6. Repeat steps 1 to 5 to remove other pumps if needed. Figure 6: Removing the infusion pump(s) The removal of the infusion pumps from the Bracket Pro Serie 92 - FL4 is complete. © 2023 Technimount E.M.S. Holding Inc. OG-BP92FL4-202307EN-01 | Page 8 of 16...
  • Page 9: Install The Bracket Pro Serie 92 - Fl4 On A Micro Base

    ® 2.3. Install the Bracket Pro Serie 92 - FL4 on a Micro Base NOTE: Only a Technimount bracket with an anti-rotation micro disc or micro bottom disc can be installed on a Micro Base. 1. Align the anti-rotation micro disc (bottom mount) or micro disc (rear mount) with the Micro Base opening (Figure 7).
  • Page 10 The installation of the Bracket Pro Serie 92 - FL4 on a Micro Base is complete (Figure 8). (Bottom mount) (Rear mount) Figure 8: Bracket Pro Serie 92 - FL4 installed on a Micro Base (bottom and rear mounts shown) © 2023 Technimount E.M.S. Holding Inc. OG-BP92FL4-202307EN-01 | Page 10 of 16...
  • Page 11: Remove The Bracket Pro Serie 92 - Fl4 From The Micro Base

    Figure 9: Removing the Bracket Pro Serie 92 - FL4 from the Micro Base (bottom and rear mounts shown) The removal of the Bracket Pro Serie 92 - FL4 from the Micro Base is complete. © 2023 Technimount E.M.S. Holding Inc. OG-BP92FL4-202307EN-01 | Page 11 of 16...
  • Page 12: Operate The Bracket Pro Serie 92 - Fl4 Iv Pole

    Pull and hold the quick release knob of the IV pole, then raise or lower the IV pole or remove it completely (Figure 10). 1. IV pole (down) 3. IV pole (up) 2. Quick release knob Figure 10: Bracket Pro Serie 92 - FL4 IV pole © 2023 Technimount E.M.S. Holding Inc. OG-BP92FL4-202307EN-01 | Page 12 of 16...
  • Page 13: Perform The Daily Safety Checks

    3. Perform the Daily Safety Checks Daily safety checks on Technimount products are recommended to keep them in good condition and avoid failure or injury to the patient or EMS personnel. EMS personnel should perform the daily safety checks at the beginning of each work shift.
  • Page 14 Daily Safety Checks completed on (dd/mm/yyyy), by Comments and observations: © 2023 Technimount E.M.S. Holding Inc. OG-BP92FL4-202307EN-01 | Page 14 of 16...
  • Page 15: Illustrated Inspections Points

    4. Top of pump holder 10. Anti-rotation micro disc 5. Inserts for pump 11. Micro disc Figure 11: Bracket Pro Serie 92 - FL4 Inspection points (front and back of bracket shown) © 2023 Technimount E.M.S. Holding Inc. OG-BP92FL4-202307EN-01 | Page 15 of 16...
  • Page 16 Critical Care Transport (CCT) teams for ground and air ambulances. Safety is at the core of our values, all Technimount systems are tested in compliance with the highest industry standards for impact resistance. Technimount EMS is committed to developing innovative solutions as healthcare practices evolve.
