- Page 1 ® BRACKET PRO SERIE® 221 OPERATING GUIDE SAFETY AND FLEXIBILITY WHERE IT MATTERS MOST...
-
Page 2: Trademarks
® ® - Plum 360™ is a trademark of ICU Medical Inc. For any issues with your Technimount product, its components, or for any technical questions during the installation, operation, or maintenance, please contact Technical Support at techsupport@technimount.com. Contact Information Technimount E.M.S. -
Page 3: Table Of Contents
..2.2. Remove the Plum 360 from the Bracket Pro Serie 221 ..................8 3. Perform the Daily Safety Checks ........................9 ..3.1. Required Tools ................................9 ..3.2. Daily Safety Checks ..............................9 ..3.3. Illustrated Inspection Points ............................11 © 2023 Technimount E.M.S. Holding Inc. OG-BP221-202308EN-01 | Page iii of iii... -
Page 4: Safety Guidelines
CAUTION - Safe Handling and Operation - Improper use of the Technimount product may damage the device or cause injury to the patients or EMS personnel. - If any serious incident occurs with the mounting system, immediately stop using the product, report this incident to Technical Support at technicalsupport@technimount.com... -
Page 5: Operate The Bracket Pro Serie 221
NOTE: Always perform the Safety checks before using the Bracket Pro Serie 221. Refer to the "Daily Safety Checks" on page 9 before each use. NOTE: Technimount continually seeks advancements in product design and quality. While this operating guide contains the most updated product information available at the time of printing, it may contain minor differences from the current version. -
Page 6: Install The Plum 360 In The Bracket Pro Serie 221
1. If the bracket is closed (locked), pull the 2 quick release mechanism knobs to disengage the top, then lift the top upwards until it has reached its final position (Figure 3). Figure 3: Unlocking/Opening the Bracket Pro Serie 221 © 2023 Technimount E.M.S. Holding Inc. OG-BP221-202308EN-01 | Page 6 of 12... - Page 7 Figure 5: Plum 360 installed in the Bracket Pro Serie 221 The installation of the PLUM 360 in the Bracket Pro Serie 221 is complete. © 2023 Technimount E.M.S. Holding Inc. OG-BP221-202308EN-01 | Page 7 of 12...
-
Page 8: Remove The Plum 360 From The Bracket Pro Serie 221
4. Lift to remove the pump from the bracket (Figure 7 B and Figure 7 C), then set it aside. Figure 7: Plum 360 removed from the Bracket Pro Serie 221 The removal of the PLUM 360 in the Bracket Pro Serie 221 is complete. © 2023 Technimount E.M.S. Holding Inc. OG-BP221-202308EN-01 | Page 8 of 12... -
Page 9: Perform The Daily Safety Checks
3. Perform the Daily Safety Checks Daily safety checks on Technimount products are recommended to keep them in good condition and avoid failure or injury to the patient or EMS personnel. EMS personnel should perform the daily safety checks at the beginning of each work shift. - Page 10 - Visually inspect the (4) feet to ensure there is no damage or chemical attack, loose parts and that the hardware is in good condition. Daily safety checks completed on (dd/mm/yyyy), by Comments and observations: © 2023 Technimount E.M.S. Holding Inc. OG-BP221-202308EN-01 | Page 10 of 12...
-
Page 11: Illustrated Inspection Points
Figure 8: Bracket Pro Serie 221 with bottom mount inspection points (front and bottom illustrated) 1. Quick release mechanism (2X) 3. Anti-rotation micro disc 2. Foot (4X) Figure 9: Bracket Pro Serie 221 with rear mount inspection points (front and rear illustrated) © 2023 Technimount E.M.S. Holding Inc. OG-BP221-202308EN-01 | Page 11 of 12... - Page 12 Critical Care Transport (CCT) teams for ground and air ambulances. Safety is at the core of our values, all Technimount systems are tested in compliance with the highest industry standards for impact resistance. Technimount EMS is committed to developing innovative solutions as healthcare practices evolve.
