Avlex HS-02a Manual

With a capsule diameter of just over 4 mm, the HS-02a provides
a low profile combined with high-performance audio. This
Standard grade omnidirectional condenser headworn mic
offers a lightweight dual ear design with a flexible adjustable
boom that can be worn on the left or right. The dual ear hooks
provide a very secure, inconspicuous and comfortable fit that
allows maximum freedom of movement with or without
glasses. The ear hooks feature a unique 'ratcheted' swivel
design that enables the user to wear the boom on either side of
the head and allows the ear hooks to fold flat when not in use.
The HS-02a comes with two screw-on replaceable audio cables,
acoustically transparent windscreens and a MIPRO wireless
bodypack adapter. Additional optional adapters are available
for use with Shure, AudioTechnica, AKG, Sennheiser, Electro
Voice, Lectrosonics, Sony and other belt packs. Optional Red
Dot, (RD), adapters have a built in 15dB pad for use with MIPRO,
AudioTechnica, AKG, Electro Voice and Shure belt packs.
The HS-02a is available in black or beige. This comfortable dual
ear headworn mic is a perfect solution for Houses of Worship,
Theater, Lecturers, Broadcast, Corporate A/V, and other
applications where premium intelligible sound and low visibility
are required. All mics come with a reversible name card.
HS-02a Specifications:
Element
Polar Pattern
Frequency Response
Sensitivity
Output Impedance
SPL max
Operating Voltage
Cable
Capsule Diameter
Color
Wireless Body Pack
Adapter
XLR Adapter
Accessories
Weight
AVLEX CORPORATION www.avlex.com 6208 Baum Drive, Suite 2, Knoxville, TN 37919 Fax (816) 581-9104 Toll Free: 877-447-9216
HS-02a Dual Ear Premium
Headworn Microphone
Standard grade back electret condenser
Omni-directional
20Hz-20KHz
-42±3dB 1V/Pa @ 1KHz
1100 Ohms±30%
126dB (155dB with optional Red Dot adapter)
2 V (0.1V-5V) D.C.
Kevlar coated; 1.3m (47.25")
4.6 mm O.D.
Black or Beige
Included adapter: T5 Mipro
Optional adapters: T1 & T1RD AudioTechnica,
T2 & T2RD AKG, T3 Sennheiser, T4 & T4RD Shure,
T5RD Mipro, T8 and T8RD Electro Voice, T9 Sony,
T14 Lemo and T15 Lectrosonics
Optional adapter : MJ-53 for wired use
Spare audio cable and windscreens, cable clips
21g (0.74 ounces)
