With a capsule diameter of just 3mm, the HSP-49 provides a
super low profile combined with premium performance audio
output. This premium grade omnidirectional condenser headworn
mic offers a lightweight single ear design. It features an adjustable
length 0.7mm flexible boom and distinctive ear loop that hooks
over either ear without any adjustment. The HSP-49 eliminates the
frustration from trying to achieve a secure and comfortable fit.
The HSP-49 comes with two screw-on replaceable audio cables,
acoustically transparent windscreens and a MIPRO wireless
bodypack adapter. Additional optional adapters are available for
use with Shure, AudioTechnica, AKG, Sennheiser, ElectroVoice,
Lectrosonics, Sony and other belt packs. Optional Red Dot (RD)
adapters have a built-in 15dB pad for use with MIPRO,
AudioTechnica, AKG, ElectroVoice and Shure belt packs.
The HSP-49 is available in black, cocoa brown or beige and ships
in a hard shell case. This comfortable single ear headworn mic
is a perfect solution for Houses of Worship, Theaters, Lecturers,
Broadcast, Corporate A/V, and other applications where intelligible
sound and low visibility are required.
HSP-49 Specifications:
Element
Polar Pattern
Frequency Response
Sensitivity
Output Impedance
SPL max
Operating Voltage
Cable
Capsule Diameter
Color
Wireless Body Pack Adapter
XLR Adapter
Accessories
Weight
(microphone, 1 cable and 1 T5 connector)
AVLEX CORPORATION www.avlex.com 6655 Troost Avenue Kansas City, MO 64131
HSP-49 Single Ear Premium
Headworn Microphone
Premium back electret condenser, 3.0mm diameter
Omni-directional
20Hz-20KHz
-35±3dB 1V/Pa @ 1KHz
2000 Ohms±30%
140dB (155dB with optional Red Dot adapter)
0.8V-5V D.C
Kevlar coated; 1.2m (47.25")
3.0mm
Black, Cocoa Brown or Beige
Included adapter: T5 Mipro
Optional adapters: T1 & T1RD AudioTechnica,
T2 & T2RD AKG, T3 Sennheiser, T4 & T4RD Shure,
T5RD Mipro, T8 and T8RD Electro Voice, T9 Sony,
T14 Lemo and T15 Lectrosonics
Optional adapter : MJ-53 for wired use
Spare audio cable and windscreens
12.39g (0.437 ounces)
The HSP-49 features an adjustable length
boom and a distinctive flexible ear-hook
made with a self-adjusting soft spring
polymer that eliminates the frustration of
getting a secure and comfortable fit
regardless of who is using it!
Fax (816) 581-9104 Toll Free: 877-447-9216
