With a capsule diameter of just 3.5 mm, the
HS-28 provides a super low profile combined
with excellent audio output. This omnidirectional
condenser headworn mic offers a lightweight
single ear design with a flexible boom and hassle
free earhook design that takes the guesswork and
frustration out of achieving a secure and
comfortable fit.
The HS-28 comes with small, medium and large
interchangeable ear hooks, two screw-on
replaceable audio cables, acoustically transparent
windscreens and a MIPRO wireless bodypack
adapter. Additional optional adapters are
available for use with Shure, AudioTechnica,
AKG, Sennheiser, Electro Voice, Lectrosonics,
Sony and other belt packs. Optional Red Dot
(RD) adapters have a built-in 15dB pad for use
with MIPRO, AudioTechnica, AKG,
Electro Voice and Shure belt packs.
The HS-28 is available in black, cocoa brown or
beige and ships in a leatherette case. This
comfortable single ear headworn mic is a perfect
solution for Houses of Worship, Theaters,
Lecturers, Broadcast, Corporate
A/V, and other applications where intelligible
sound and low visibility are required.
HSP-29 Specifications:
Element
Polar Pattern
Frequency Response
Sensitivity
Output Impedance
SPL max
Operating Voltage
Cable
Capsule Diameter
Color
Wireless Body Pack Adapter
XLR Adapter
Accessories
Weight
www.avlex.com
AVLEX CORPORATION
HS-28 Single Ear
Headworn Microphone
Back electret condenser, 3.5mm diameter
Omni-directional
20Hz-20KHz
-45±3dB 1V/Pa @ 1KHz
2000 Ohms±30%
140dB (155dB with optional Red Dot adapter)
0.8V-5V D.C
Kevlar coated; 1.2m (47.25")
3.5mm
Black, Cocoa Brown or Beige
Included adapter: T5 Mipro
Optional adapters: T1 & T1RD AudioTechnica,
T2 & T2RD AKG, T3 Sennheiser, T4 & T4RD Shure,
T5RD Mipro, T8 and T8RD Electro Voice, T9 Sony,
T14 Lemo and T15 Lectrosonics
Optional adapter : MJ-53 for wired use
Spare audio cable and windscreens
13g (0.46 ounces)
6655 Troost Avenue Kansas City, MO 64131
The HSP-28 includes three
interchangeable ear hooks
that take the frustration
out of getting a secure and
comfortable fit on either
ear every time.
Fax (816) 581-9104 Toll Free: 877-447-9216
