DIGITAL CAMERA
SAMSUNG NX200
SERVICE
Manual
DIGITAL CAMERA
CONTENTS
1. Repair information
2. Product specifications
3. Disassembly and reassembly
4. PCB diagrams
5. Block diagram
6. Firmware update
7. Adjustment
8. Exploded view and parts list

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NX200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Samsung NX200

  • Page 1 DIGITAL CAMERA SAMSUNG NX200 SERVICE Manual DIGITAL CAMERA CONTENTS 1. Repair information 2. Product specifications 3. Disassembly and reassembly 4. PCB diagrams 5. Block diagram 6. Firmware update 7. Adjustment 8. Exploded view and parts list...
  • Page 2: Table Of Contents

    Contents 1. Repair information 1-1 Customer satisfaction statement ..........1-1 1-2 Warranty and repair service information ........1-1 1-3 Precaution for disassembly and reassembly ......1-4 2. Product specifications 2-1 Specifications ................2-1 2-2 Product comparison ..............2-2 2-3 Accessories information ............2-3 2-4 About the memory card ............
  • Page 3 Contents 5. Block diagram 6. Firmware update 6-1 Product reset ................6-1 6-2 F/W Upgrade by using user menu ..........6-3 6-3 Upgrade procedure by using C/S menu ........6-5 7. Adjustment 7-1 Basic guide for adjustment ............7-1 7-2 Tester Mode ................7-3 7-3 CIS TILT Adjustment ..............
  • Page 4: Repair Information

    In the event that a valid date of purchase is not available, the warranty period will be determined by the date of manufacture. The warranty period shall be decreased to three months from the original product manufactured date. Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 5: Limited Warranty

    Our liability under this warranty shall be limited to the following: a. In the event of a same malfunction problem within two months after repair service by Samsung authorized technician, we will repair or replace free of charge the component of the product which is found to be defective.
  • Page 6 Defect occurring after the expiration of the Warranty Period. b. Damage due to negligence, immersion in water, impact, loss and tampering. c. Repair or alteration performed by any party other than Samsung authorized technicians. d. Misuse or other improper use of the power button.
  • Page 7: Precaution For Disassembly And Reassembly

    Use an anti-static mat as well as an anti-static wrist strap to avoid ESD damage to PCB. The use wooden or plastic tweezers is recommended for manual placement. CONNECTOR Metal tip tweezer might make marks or damage. BARREL Always follow proper direction while assembling the components of the barrel. Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 8: Product Specifications

    DC 9.0 V, 1.5 A(100~240 V) Power Source • Rechargeable battery: BP1030 (1,030 mAh) Type • Charger: BC1030 Dimensions (W X H X D) 4.59X 2.46X 1.44in(without protrusions) Weight 7.77oz(without battery and memory card) Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 9: Product Comparison

    • Mode : Mode 1 / Mode 2 / Off • Mode : OIS mode1 / mode2 • Rechargeable battery: BP1310(1300 mAh) • Rechargeable battery: BP1030 (1,030 mAh) Power Source • Charger: BC1310 • Charger: BC1030 • AC adapter: AD9NX01 (optional) Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 10: Accessories Information

    AD44-00203A Packing items CHINA 3903-000611 EXP-D1 3903-000616 USA-D1 3903-000618 AC power cable 3903-000613 AUS-D1 3903-000612 3903-000617 3903-000610 Software CD-ROM AD46-00417A (User manual included) Varies from country to User manual Basic Operation country. Strap AD63-04468A Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 11 USB cable HDMI cable You can view high-definition photos and videos by connecting the camera to an HDMI-compatible monitor with the HDMI (HDMI type C) cable. Battery pack You can purchase additional battery packs. Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 12: About The Memory Card

    Approx. 37' 16'' Approx. 43' 14'' 320X240 Approx. 119' 57'' Approx. 145' 49'' * The recordable time may vary if you use the zoom. Several videos were recorded in succession to determine the total recording time. Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 13: About The Battery

    Approx. 110 min (Record videos at 1920X1080 Videos resolution and 30 FPS.) · The figures above are measured by Samsung’s standards. Your results may differ, depending on your actual usage. · Available shooting time differs depending on background, shooting interval, and use conditions.
  • Page 14: Disassembly And Reassembly

    6003-001703 3-44 M.SCREW(M1.7XL4/BLK) 6001-001291 T.SCREW(M1.7XL3/BLK) 6003-001637 3-46 SCREW1750 6003-001753 SCREW1750 6003-001753 3-48 SCREW1730 6003-001637 3-53 SCREW1750 6003-001753 3-53 SCREW1750 6003-001753 3-56 SCREW1750 6003-001753 3-57 SCREW1750 6003-001753 SCREW1750 6003-001753 3-61 SCREW1730 6003-001637 3-62 SCREW1750 6003-001753 Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 15: Disassembly

    3-2 Disassembly 1. Provide the general support. : Take the parts such as LCD, Back-Cover and Top to Samsung authorized service centers. 2. Provide the technical expertise support. : After replacing the parts such as Main PBA, CMOS, Shutter, CMOS, it is required to adjust these parts with equipments specified below.
  • Page 16 You'll have to apply a little force to remove it. 3. Removing the FPCB. Remove the FPCB from the connector as illustrated in "Fig A". Remove the FPCB from the connector. FPCB FPCB Fig. A Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 17 Disassembly and reassembly 4. Removing the ASSY COVER BACK. Remove the ASSY COVER BACK. ASSY COVER BACK 5. Removing the FPCB. Remove the FPCB from the connector as illustrated in "Fig A". Fig. A Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 18 Remove the 5 screws and LCD FPCB as illustrated in "Fig. A". T.SCREW Remove the FPCB from the connector. FPCB FPCB Fig. A 7. Removing the COVER-JACK and PLATE-JACK COVER-NX20. Remove the COVER-JACK and PLATE-JACK COVER-NX20. COVER-JACK PLATE-JACK COVER-NX20 Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 19: Removing The Lcd

    9. Removing the LCD. Remove the LCD FPCB through the groove of the BRACKET-LCD BASE in the direction of the arrow as illustrated in "Fig. A". Then remove the LCD. BRACKET-LCD BASE 그림 A Fig. A Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 20 FPCBs. Follow this order WIRE when removing the FPCB. WIRE Fig. C FPCB Fig. B 11. Removing the ASSY MAIN PCB. Remove the ASSY MAIN PCB. ASSY MAIN PCB Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 21: Removing The Screws

    Remove the screw as illustrated in "Fig. B". Fig. A M.SCREW(M1.7,L3,NI) PLATE-SPRING SHOE Fig. B 13. Removing the screws. Remove the 2 screws as illustrated in "Fig. A" and "Fig. B". M.SCREW(M1.7XL4/NI-Cr) M.SCREW(M1.7XL2.5/NI) Fig. B Fig. A Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 22 14. Removing the ASSY TOP and STRAP HOLDER R. (a) Remove the ASSY TOP. (b) Remove the STRAP HOLDER R. (a) ASSY TOP (b) STRAP HOLDER R 15. Removing the screw. Remove the screw as illustrated in "Fig.A" below. M.SCREW(M1.7,L3,NI) Fig. A Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 23 After removing the 2 screws, remove the FPCB as illustrated in "Fig. A". Remove the FPCB from the connector. 1. Open. FPCB 2. Remove. T.SCREW(M1.7,L3,NI) FPCB Fig. A 17. Removing the ASSY TOP-PCB. Remove the ASSY TOP-PCB. ASSY TOP-PCB 3-10 Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 24 CAUTION Be especially careful not to touch the surrounding circuitry and components when removing the solder from the ASSY PCB SUB. 19. Removing the screws. Remove the 6 screws. T.SCREW(M1.4,L2.5,B) T.SCREW(M1.4,L2.5,B) T.SCREW(M1.4,L2.5,B) M.SCREW(M1.7,L3.5,NI) Copyright© 1995-2011 SAMSUNG. All rights reserved. 3-11...
  • Page 25 (j) Remove the MIC ASSY. (a) PLATE-MODE DIAL (b) PLATE-POWER LEVER (i) ASSY PCB SUB (c) HOLDER-TOP (j) MIC ASSY (h) WINDOW-AF (g) HOT SHOE ASSY (d) KNOB MODE DIAL (e) MODE DIAL (f) HOT SHOE PLATE 3-12 Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 26: Technical Expertise Support - Disassembly

    (a) Remove the MOUNT INNER. (b) Remove the MOUNT PLATE. (c) Remove the PLATE MOUNT SPRING. (d) Remove the PIN LENS DETECT. (b) MOUNT PLATE (d) PIN LENS DETECT (c) PLATE MOUNT SPRING (a) MOUNT INNER Copyright© 1995-2011 SAMSUNG. All rights reserved. 3-13...
  • Page 27 Disassembly and reassembly 3. Removing the screw. Remove the 3 screws. M.SCREW(M1.7XL4/NI) 4. Removing the DECO RING. Remove the DECO RING. DECO RING 3-14 Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 28 5. Removing the screw. Remove the 2 screws. T.SCREW(M1.7,L3.5,BLK) 6. Removing the ASSY FRONT and HOLDER TRIPOD. (a) Remove the ASSY FRONT (b) Remove the HOLDER TRIPOD (a) ASSY FRONT (b) HOLDER TRIPOD Copyright© 1995-2011 SAMSUNG. All rights reserved. 3-15...
  • Page 29 Disassembly and reassembly 7. Removing the T/SHEET-THERMAL A and screws. (a) Remove the T/SHEET-THERMAL A . CAUTION Use care not to tear the T/SHEET-THERMAL A when removing. T/SHEET-THERMAL A 2 screws. (b) Remove the T.SCREW(M1.7,L3.5,BLK) 3-16 Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 30 Remove the GRIP-FRONT and 2 screw Fig. A T.SCREW(M1.7,L3.5,BLK) GRIP-FRONT 9. Removing the ASSY HOLDER-STRAP L / COVER-FRONT. (a) Remove the ASSY HOLDER-STRAP L. (b) Remove the COVER-FRONT from the CHAMBER-BATTERY. (a) ASSY HOLDER-STRAP L CHAMBER-BATTERY (b) COVER-FRONT Copyright© 1995-2011 SAMSUNG. All rights reserved. 3-17...
  • Page 31 10. Removing the ASSY CMOS. (a) Remove the 3 screws. (b) Remove the 3 SPRING-CS. (c) Remove the ASSY CMOS. (d) Remove the ASSY SHUTTER-NX200. (e) Remove the ASSY HOLDER-INNER MOUNT. (f) Remove the ASSY PCB SUB. (a) M.SCREW(HEXA M1.7,L4,BLK)
  • Page 32: Reassembly

    3-3-1 Technical expertise support - Reassembly 1. Installing the ASSY CMOS. (a) Install the ASSY PCB SUB. (b) Install the ASSY HOLDER-INNER MOUNT. (c) Install the ASSY SHUTTER-NX200. (d) Install the ASSY CMOS. (e) Install the 3 SPRING-CS. (f) Tighten the 3 screws.
  • Page 33 (a) ASSY HOLDER-STRAP L CHAMBER-BATTERY (b) COVER-FRONT 3. Tightening the screws and install the GRIP-FRONT. Install the GRIP-FRONT and Tightening the 2 screws as illustrated in "Fig. A". Fig. A (a) T.SCREW(M1.7,L3.5,BLK) (b) GRIP-FRONT 3-20 Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 34 After tightening the 2 screws and attach the T/SHEET-THERMAL A in the direction of the "Fig.A" arrow. (b) T/SHEET-THERMAL A Fig. A (a) T.SCREW(M1.7,L3.5,BLK) 5. Installing the ASSY FRONT and HOLDER TRIPOD. Install the ASSY FRONT and HOLDER TRIPOD. (b) ASSY FRONT (a) HOLDER TRIPOD Copyright© 1995-2011 SAMSUNG. All rights reserved. 3-21...
  • Page 35 Disassembly and reassembly 6. Tightening the screws. Tighten the 2 screws. T.SCREW(M1.7,L3.5,BLK) 7. Installing the DECO RING. Install the DECO RING. DECO RING 3-22 Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 36 (a) Install the PIN LENS DETECT. (b) Install the PLATE MOUNT SPRING. (c) Install the MOUNT PLATE. (d) Install the MOUNT INNER. (c) MOUNT PLATE (a) PIN LENS DETECT (b) PLATE MOUNT SPRING (d) MOUNT INNER Copyright© 1995-2011 SAMSUNG. All rights reserved. 3-23...
  • Page 37: General Support - Reassembly

    1. Installing the ASSY TOP. (a) Install the HOT SHOE ASSY. (b) Install the ASSY PCB SUB. (c) Install the MIC ASSY. (c) MIC ASSY (b) ASSY PCB SUB (a) HOT SHOE ASSY 3-24 Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 38 (d) Solder to the 9 specified locations by the blue circle. CAUTION Be especially careful not to touch the surrounding circuitry and components when soldering on the ASSY PCB SUB. (e) Install the WINDOW-AF. WINDOW-AF Copyright© 1995-2011 SAMSUNG. All rights reserved. 3-25...
  • Page 39 (i) Install the HOLDER-TOP (j) Install the PLATE-POWER LEVER (k) Install the PLATE-MODE DIAL (k) PLATE-MODE DIAL (j) PLATE-POWER LEVER (i) HOLDER-TOP M.SCREW(M1.7X5/NI) (f) HOT SHOE PLATE (h) KNOB MODE DIAL (g) MODE DIAL 3-26 Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 40 Disassembly and reassembly 2. Tightening the screws. Tighten the 6 screws. T.SCREW(M1.4,L2.5,B) T.SCREW(M1.4,L2.5,B) T.SCREW(M1.4,L2.5,B) M.SCREW(M1.7,L3.5,NI) 3. Installing the ASSY TOP-PCB. Install the ASSY TOP-PCB. ASSY TOP-PCB Copyright© 1995-2011 SAMSUNG. All rights reserved. 3-27...
  • Page 41 Fig. A 5. Tightening the screw and then installing the PLATE-SPRING SHOE. Tighten the screw as illustrated in "Fig. A" below and then install the PLATE-SPRING SHOE. (a) M.SCREW(M1.7,L3,NI) Fig. A (b) PLATE-SPRING SHOE 3-28 Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 42 (b) Install the ASSY TOP. (b) ASSY TOP (a) STRAP HOLDER R 7. Tightening the screws. Tighten the 3 screws as illustrated in "Fig. A", "Fig.B", "Fig.C". M.SCREW(M1.7XL4/NI-Cr) M.SCREW(M1.7XL2.5/NI) Fig. B Fig. A M.SCREW(M1.7,L3,NI) Fig. C Copyright© 1995-2011 SAMSUNG. All rights reserved. 3-29...
  • Page 43 (b) Install the WINDOW-CARD ACCESS-NX20. (c) Install the BUTTON-REC. (d) Install the ASSY-PCB KEY. (e) Install the BRACKET-LCD BASE/LCD. (e) BRACKET-LCD BASE/LCD (d) ASSY-PCB KEY (c) BUTTON-REC (b) WINDOW-CARD ACCESS-NX20 (a) BUTTON-FUNCTION COVER-BACK 3-30 Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 44 (a) Install the COVER-JACK. (b) Install the PLATE-JACK COVER-NX20. (b) PLATE-JACK COVER-NX20 (a) COVER-JACK (c) Connect the FPCB to the connector as illustrated in "Fig. A". Connect the FPCB to the connector. FPCB FPCB Fig. A Copyright© 1995-2011 SAMSUNG. All rights reserved. 3-31...
  • Page 45 11. Tightening the screws. Tighten the 5 screws. T.SCREW 12. Installing the LCD connector. Install the LCD connector as illustrated in "Fig. A". 1. Install. 2. The correct position is indicated properly here. Fig. A 3-32 Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 46 ③ The numbers Connect the wire. indicate the order to connect the FPCBs. WIRE WIRE Follow this order when connecting the FPCB. 2. Close. Fig. C FPCB 1. Connect. FPCB Fig. B Copyright© 1995-2011 SAMSUNG. All rights reserved. 3-33...
  • Page 47 Connect the FPCB to the connector as illustrated in "Fig. A". Connect the FPCB to the connector. FPCB FPCB Fig. A 16. Installing the ASSY BACK COVER. Install the ASSY BACK COVER. ASSY COVER BACK 3-34 Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 48 (a) Tighten the 2 screws on the left side. T.SCREW(M1.7X3.5/BLK) (b) Tighten the 2 screws on the right side and 3 screws on the bottom side of the camera body. M.SCREW(M1.7XL4/BLK) T.SCREW(M1.7XL3/BLK) M.SCREW(M1.7XL4/BLK) (c) Install the COVER-HOT SHOE. COVER-HOT SHOE Copyright© 1995-2011 SAMSUNG. All rights reserved. 3-35...
  • Page 49: Pcb Diagrams

    PCB diagrams 4. PCB diagrams 4-1 Main PCB(Top) Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 50: Main Pcb(Bottom)

    PCB diagrams 4-2 Main PCB(Bottom) BOTTOM Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 51: Cis Pcb(Top)

    PCB diagrams 4-3 CIS PCB(Top) 4-4 CIS PCB(Bottom) BOTTOM Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 52: Back Pcb(Top)

    PCB diagrams 4-5 Back PCB(Top) 4-6 Back PCB(Bottom) BOTTOM Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 53: Top Pcb(Top)

    PCB diagrams 4-7 Top PCB(Top) 4-8 Top PCB(Bottom) BOTTOM Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 54: Lens Det Pcb

    PCB diagrams 4-9 Lens DET PCB 4-10 Hot shoe PCB Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 55: Block Diagram

    Block diagram 5. Block diagram Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 56: Firmware Update

    2. Select the “Smart Auto mode” Fig. 6-2 3. Press these buttons in sequence : DOWN RIGHT EV+OK (Press OK button while pressing EV button.) UP button OK button EV+OK button RIGHT button DOWN button Fig. 6-3 Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 57 5. Select the mode “(1) FACTORY RESET “and press the OK button. Select OK button Fig. 4-4 Fig. 6-5 6. Power off the camera. 7. Turn the power of the camera on again to check whether it has been reset. Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 58: F/W Upgrade By Using User Menu

    Fig. 6-6 4. Press the Menu button. MENU button Fig. 6-7 5. Use the arrow keys to move tab “Settings 3”and select the “Firmware Update” item. (Press the OK button) OK button Select Fig. 6-8 Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 59 OK button Select Fig 6-10 8 . Then the FULL Firmware upgrade will start. (Green LED will flash) 9. When the FULL Firmware upgrade is complete, the camera will automatically be turned off. Fig 6-11 Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 60: Upgrade Procedure By Using C/S Menu

    2. Use AC adaptor or the fully recharged battery for power supply. Upgrade can only be made when the battery level is full(3 bars). 3. First turn on the power of the camera. Power ON Fig. 6-12 4. Select the “Smart Auto mode”. Fig. 6-13 Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 61 Fig. 6-14 6. Select the mode “1. FW UPDATE“and press the OK button. Select OK button Fig. 6-15 7. Select the mode “(1) BODY FW UPDATE“and press the OK button. Select OK button Fig. 6-16 Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 62 OK button Fig. 6-17 9 . Then the FULL Firmware upgrade will start. (Green LED will flash) 10. When the FULL Firmware upgrade is complete, the camera will automatically be turned off. Fig 6-18 Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 63: Adjustment

    7. Adjustment 7-1 Basic guide for adjustment ■ After replacing an electronic part, you must make changes for each adjustment item in the NX200. ■ The following table shows the necessary adjustment item for replacing each part. 1. After replacing an electronic part, you must make adjustments for each item by referring to the following table.
  • Page 64 SERIAL NUMBER WRITING ADJ nx200serial.adj 5. Order to adjustment - Follow these steps to begin the adjustment process. Input the CIS DOT Data → SHUTTER Adjustment → ISO sensitivity Adjustment→ AWB Adjustment → VFPN & DEFECT Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 65: Tester Mode

    (3) ZOOM TELE SET 4. LENS CONTROL (2) Fix the wide value of zoom lens. (4) MR SENSOR ADJUST (3) Fix the tele value of zoom lens. (5) LENS MOUNT INFO (6) LENS COMM SEVE Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 66: Cis Tilt Adjustment

    <Adjustment Result> FLANGE BACK Value of Mount & CMOS ASSY: 25.55mm(-35mm/+15mm) Value of CMOS sensor area: -30um/+30um * Caution : Adjusted 3 screw points of NX10/5/11 & NX100 & NX200 are different each other. Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 67: Input Cis Dot & Adjust The Shutter Speed

    (The installation will start. Please refer to the page 7-8 for installing module between the NX and PTP. Follow the installation screen directions.) 3. Download the “NX200 SHUTTER 2.5.ZIP” file to a directory on your PC and extract it. Fig. 7-5...
  • Page 68 Right click on “My Computer” and click the “Manage”, and then click the “Device Manager”. The Device Manager opens as shown in Figure below. Check the connection status of the “COM” to the “Device Manager”. PORT Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 69 The “FPS” button becomes enabled, turning its button color is blue. Cancel Fig. 7-10 Select the “Option” tab and click the “SCRIPT FILE OPEN”. Then click the “Open” to select the “shutter.txt”. (Location: NX200 SHUTTER 2.5 \ Script \ shutter.txt) Open Look in Name...
  • Page 70 - When the process is not successful, the “FAIL” message will be displayed. Fig. 7-14 Navigate to the directory you extracted to the NXCISTEMP_NX200.zip” file such as C:\ CIS DOT_SHUTTER SPEED\NX200\NX200  SHUTTER 2.5\files\Ch1. Check whether the CSV file is created at the destination directory or not.
  • Page 71 Adjustment <How to run “libusb-win32-filter-bin-1.1.14.3.exe”>    Fig. 7-15 Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 72: Iso & Awb Low Adjustment

    5. After completing the adjustment, camera turned off automatically. <Adjustment Result> You can see the adjustment result by using Log File saved on the memory card. You can also confirm the ADJUSTMENT RESULT on the Tester mode. 7-10 Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 73: Vfpn, Defect Pixel Adjustment

    <How to adjust> 1. Insert the SD card to the camera which contained adjustment data. - File name: nx200.vfpn.adj + info.tg 2. Put the lens mount cap on the lens mount. 3. After turning on the camera, it will be start automatically.
  • Page 74: Exploded View And Parts List

    Exploded view and parts list 8. Exploded view and parts list 8-1 BODY ASSEMBLY Loc. No Parts No. Description Q ty Available Remark AD61-04096A PLATE-SPRING SHOE AD63-06184A COVER-HOT SHOE Copyrightⓒ 1995-2011 SAMSUNG. All rights reserved.
  • Page 75 Exploded view and parts list 8-2 BODY ASSEMBLY 2-13 2-14 2-10 2-11 2-12 2-16 2-15 Copyrightⓒ 1995-2011 SAMSUNG. All rights reserved.
  • Page 76 FOR Onl y KOREA, USA, CHINA, SEUK 6003-001490 SCREW-TAPTYPE 2-10 AD97-21529A ASSY HOLDER-STRAP R 2-11 6001-002662 SCREW-MACHINE 2-12 6001-001510 SCREW-MACHINE 2-13 6001-002282 SCREW-MACHINE 2-14 AD63-06483A CUSHION SHIEL FOAM-A 2-15 AD63-06528A SHEET EMI 2-16 6003-001703 SCREW-TAPTYPE Copyrightⓒ 1995-2011 SAMSUNG. All rights reserved.
  • Page 77: Front Assembly

    Exploded view and parts list 8-3 FRONT ASSEMBLY 3-12 3-13 3-10 3-11 Copyrightⓒ 1995-2011 SAMSUNG. All rights reserved.
  • Page 78 FOR Onl y KOREA, USA, CHINA, SEUK AD61-05307A MOUNT-INNER FOR Onl y KOREA, USA, CHINA, SEUK AD61-05284A PLATE-MOUNT LENS FOR Onl y KOREA, USA, CHINA, SEUK 3-10 6001-002662 SCREW-MACHINE 3-11 AD67-01399A CAP-MOUNT 3-12 6001-001291 SCREW-MACHINE 3-13 AD62-00188A PAD GAP-CHAMBER Copyrightⓒ 1995-2011 SAMSUNG. All rights reserved.
  • Page 79: Chamber Assembly

    Exploded view and parts list 8-4 CHAMBER ASSEMBLY 4-20 4-17 4-16 4-14 4-10 4-19 4-18 4-15 4-16 4-11 4-16 4-13 4-12 4-21 Copyrightⓒ 1995-2011 SAMSUNG. All rights reserved.
  • Page 80 FOR Onl y KOREA, USA, CHINA, SEUK 4-16 6003-001641 SCREW-TAPTYPE 4-17 6003-001637 SCREW-TAPTYPE 4-18 AD63-06489A T/SHEET-THERMAL A 4-19 AD63-06484A CUSHION SHIELD FOAM B 4-20 AD63-06483A CUSHION SHIELD FOAM A 4-21 AD97-21708A ASSY COVER-BATTERY_BK FOR Onl y KOREA, USA, CHINA, SEUK Copyrightⓒ 1995-2011 SAMSUNG. All rights reserved.
  • Page 81: Inner Mount Holder Assy

    5-10 AD61-04713A PLATE-IF PIN 5-11 6003-001679 SCREW-TAPTYPE 5-12 AD92-01756A ASSY PCB SUB 5-13 6003-001641 SCREW-TAPTYPE 5-14 AD63-06305A SHEET-ABSORB A 5-15 AD63-06306A SHEET-ABSORB B 5-16 AD97-21550A ASSY HOLDER-INNER MOUNT FOR Onl y KOREA,USA, CHINA, SEUK Copyrightⓒ 1995-2011 SAMSUNG. All rights reserved.
  • Page 82: Top Cover Assembly

    Exploded view and parts list 8-6 TOP COVER ASSEMBLY 6-35 6-32 6-33 6-19 6-31 6-34 6-30 6-26 6-36 6-10 6-25 6-18 6-20 6-23 6-14 6-21 6-22 6-15 6-24 6-16 6-28 6-17 6-27 6-11 6-29 6-12 6-13 Copyrightⓒ 1995-2011 SAMSUNG. All rights reserved.
  • Page 83 6-28 6001-002282 SCREW-MACHINE 6-29 AD97-21572A ASSY-LEVER POWER SUB 6-30 AD92-01752A ASSY TOP PCB 6-31 3001-002568 SPEAKER 6-32 3003-001159 MIC-CONDENSOR 6-33 AD73-00367A RUBBER-MIC 6-34 AD61-05276A HOLDER-SPEAKER MIC 6-35 AD97-21551A ASSY-COMMAND DIAL 6-36 6003-001706 SCREW-TAPTYPE 8-10 Copyrightⓒ 1995-2011 SAMSUNG. All rights reserved.
  • Page 84: Back Cover Assebly

    Exploded view and parts list 8-7 BACK COVER ASSEBLY 7-18 7-14 7-15 7-17 7-12 7-14 7-113 7-10 7-11 7-16 7-14 8-11 Copyrightⓒ 1995-2011 SAMSUNG. All rights reserved.
  • Page 85 7-10 AD63-06507A T/SHEET-EMI A 7-11 AD63-06508A T/SHEET-EMI B 7-12 AD07-00139A OLED AM 7-13 AD41-01776A 7-14 6003-001637 SCREW-TAPTYPE 7-15 AD66-00944A SHAFT JACK COVER 7-16 AD63-06488A T/SHEET-THERMAL B 7-17 AD63-06278A cushion oled 7-18 AD64-03407A WINDOW_OLED-NX20 8-12 Copyrightⓒ 1995-2011 SAMSUNG. All rights reserved.
  • Page 86: Packing Items

    3903-000618 AC CODE CABLE_USA-D1 3903-000613 AC CODE CABLE_UK 3903-000612 AC CODE CABLE_AUS-D1 3903-000617 AC CODE CABLE_BRA 3903-000610 AC CODE CABLE_ARG AD43-00202A NX BATTERY(BP1030) AD44-00203A NX CHARGER(BC1030) AD39-00190A USB_CABLE_5PIN AD39-00191A AV CABLE_5PIN AD63-04468A STRAP_NX10 8-13 Copyrightⓒ 1995-2011 SAMSUNG. All rights reserved.
