DIGITAL CAMERA
SAMSUNG NX1000
SERVICE
Manual
DIGITAL CAMERA
CONTENTS
1. Repair information
2. Product specifications
3. Disassembly and reassembly
4. PCB diagrams
5. Block diagram
6. Firmware update
7. Adjustment
8. Exploded view and parts list

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NX1000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Samsung NX1000

Summary of Contents for Samsung NX1000

  • Page 1 DIGITAL CAMERA SAMSUNG NX1000 SERVICE Manual DIGITAL CAMERA CONTENTS 1. Repair information 2. Product specifications 3. Disassembly and reassembly 4. PCB diagrams 5. Block diagram 6. Firmware update 7. Adjustment 8. Exploded view and parts list...

  • Page 2: Table Of Contents

    Contents 1. Repair information 1-1 Customer satisfaction statement ..........1-1 1-2 Warranty and repair service information ........1-1 1-3 Precaution for disassembly and reassembly ....... 1-4 2. Product specifications 2-1 Specifications ................2-1 2-2 Product comparison ..............2-2 2-3 Accessories information ............2-3 2-4 About the memory card ..............
  • Page 3 Contents 7. Adjustment 7-1 Adjustment process guide ............7-1 7-2 Adjustmnet menu function description ........7-2 7-3 CIS tilt adjustment ..............7-4 7-4 CIS Dot input & shutter speed adjustment program installation ... 7-5 7-5 CIS dot input & shutter speed adjustment ........7-6 7-6 ISO &...

  • Page 4: Repair Information

    In the event that a valid date of purchase is not available, the warranty period will be determined by the date of manufacture. The warranty period shall be decreased to three months from the original product manufactured date. Copyright© 1995-2011 SAMSUNG. All rights reserved.
  • Page 5 Our liability under this warranty shall be limited to the following: a. In the event of a same malfunction problem within two months after repair service by Samsung authorized technician, we will repair or replace free of charge the component of the product which is found to be defective.
  • Page 6 Defect occurring after the expiration of the Warranty Period. b. Damage due to negligence, immersion in water, impact, loss and tampering. c. Repair or alteration performed by any party other than Samsung authorized technicians. d. Misuse or other improper use of the power button.

  • Page 7: Precaution For Disassembly And Reassembly

    Use an anti-static mat as well as an anti-static wrist strap to avoid ESD damage to PCB. The use wooden or plastic tweezers is recommended for manual placement. CONNECTOR Metal tip tweezer might make marks or damage. BARREL Always follow proper direction while assembling the components of the barrel. Copyright© 1995-2011 SAMSUNG. All rights reserved.

  • Page 8: Product Specifications

    Power Source • Rechargeable battery: BP1030 (1,030 mAh) Type • Charger: BC1030 Dimensions (W X H X D) 4.49 X 2.46 X 1.48 in (without protrusions) Weight 7.83 oz (without battery and memory card) Copyright© 1995-2012 SAMSUNG. All rights reserved.

  • Page 9: Product Comparison

    • Mode : Mode 1 / Mode 2 / Off • Mode : Mode 1 / Mode 2 / Off • Rechargeable battery: BP1030 (1,030 mAh) • Rechargeable battery: BP1030 (1,030 mAh) Power Source • Charger: BC1030 • Charger: BC1030 Copyright© 1995-2012 SAMSUNG. All rights reserved.

  • Page 10: Accessories Information

    3903-000612 AC CODE CABLE_BRA 3903-000617 AC CODE CABLE_CHINA 3903-000611 AC CODE CABLE_ARG 3903-000610 Software CD-ROM AD46-00438A (User manual included) NX1000_QG_ENG(SEA) AD68-07366A User manual Basic Operation NX1000_QG_SPA(SEA) AD68-07367A BLACK AD63-07021A Strap PINK AD63-07021C WHITE AD63-07021B Copyright© 1995-2012 SAMSUNG. All rights reserved.
  • Page 11 BLACK AD63-07021A Strap PINK AD63-07021C You can additionally purchase the straps. WHITE AD63-07021B Battery pack AD43-00202A You can purchase additional battery packs. Quick battery charger AD69-03600A You can purchase an optional quick battery charger. Copyright© 1995-2012 SAMSUNG. All rights reserved.

  • Page 12: About The Memory Card

    Approx. 91' 00" 640X480(30FPS) Approx. 236' 16" Approx. 287' 12" For Sharing(30 FPS) * The recordable time may vary if you use the zoom. Several videos were recorded in succession to determine the total recording time. Copyright© 1995-2012 SAMSUNG. All rights reserved.

  • Page 13: About The Battery

    Charging time(when the camera is switched off) Approx. 140 min Battery life Shooting mode Average time / Number of photos Photos Approx. 160 min/Approx. 320 photos Approx. 160 min Videos (Record videos at 1920X1080 resolution and 30 FPS.) Copyright© 1995-2012 SAMSUNG. All rights reserved.

  • Page 14: Disassembly And Reassembly

    3-1 Disassembly 1. Provide the general support. : Take the parts such as LCD, Back-Cover and Top to Samsung authorized service centers. 2. Provide the technical expertise support. : After replacing the parts such as Main PBA, CMOS, Shutter, CMOS, it is required to adjust these parts with equipments specified below.
  • Page 15 Slightly wiggle it to widen the gap. You’ll have to apply a little force to remove it. Fig. 3-2 3) Remove the FPCB from the connector as illustrated in Fig. A. Remove the FPCB from the connector. FPCB 2. Remove. FPCB 1. Open. Fig. A Fig. 3-3 Copyright© 1995-2012 SAMSUNG. All rights reserved.

  • Page 16: Assy Cover Back

    6) Remove the FPCB from the connector as illustrated in Fig. B. SCREW-TAPTYPE (M1.4 x L3 / NI) 6003-001660 Remove the FPCB from the connector. 1. Open. 2. Remove. FPCB FPCB Fig. B Fig. 3-5 Copyright© 1995-2012 SAMSUNG. All rights reserved.

  • Page 17: Cover Back

    ③ BUTTON FUNCTION ④ BUTTON REC ⑤ WINDOW ACCESS_NX200 ② ASSY PLATE LCD / LCD ① ASSY WHEELKEY / FPC BACK INTERFACE ③ BUTTON FUNCTION ④ BUTTON REC ⑤WINDOW ACCESS_NX200 COVER BACK Fig. 3-7 Copyright© 1995-2012 SAMSUNG. All rights reserved.
  • Page 18 ① ASSY PLATE LCD ② LCD ③ CUSHON LCD ① ASSY PLATE LCD ② LCD ③ CUSHON LCD Fig. 3-8 10) Remove the FPC BACK INTERFACE from the ASSY WHEELKEY. ASSY WHEELKEY FPC BACK INTERFACE Fig. 3-9 Copyright© 1995-2012 SAMSUNG. All rights reserved.
  • Page 19 FPCB Fig. C Remove the FPCB. 1. Close 2. Remove. SCREW-TAPTYPE (M1.4 x L4 / NI) 6003-001739 FPCB FPCB Fig. D Fig. 3-10 13) Remove the ASSY MAIN PCB. ASSY MAIN PCB Fig. 3-11 Copyright© 1995-2012 SAMSUNG. All rights reserved.
  • Page 20 Fig. E Fig. F Fig. 3-12 16) Remove the ASSY-SPK DRS and HOLDER TRIPOD as illustrated in Fig. G Fig. Remove the ASSY-SPK DRS. Remove the HOLDER TRIPOD. Fig. G Fig. H Fig. 3-13 Copyright© 1995-2012 SAMSUNG. All rights reserved.
  • Page 21 19) Remove the screw as illustrated in Fig. J. Fig. I SCREW-MACHINE (M1.7 x L3 / NI) 6001-002282 PLATE-SPRING SHOE Fig. J Fig. 3-14 20) Remove the ASSY COVER TOP. ASSY TOP Fig. 3-15 Copyright© 1995-2012 SAMSUNG. All rights reserved.
  • Page 22 SCREW-MACHINE (M1.7 x L3.5 / NI) 6001-001914 SCREW-TAPTYPE (M1.4 x L4 / NI) 6003-001739 SCREW-TAPTYPE (M1.4 x L4 / NI) 6003-001739 Remove the FPCB from the connector. 1. Open. 2. Remove. FPCB FPCB Fig. L Fig. 3-17 Copyright© 1995-2012 SAMSUNG. All rights reserved.
  • Page 23 25) Remove the 11 solders specified by the blue circle. CAUTION Be especially careful not to touch the surrounding circuitry and components when removing the solder from the ASSY PCB SUB. Fig. 3-19 Copyright© 1995-2012 SAMSUNG. All rights reserved. 3-10...
  • Page 24 ⑩ ASSY FPCB HOT SHOE ② DECORATION WIFI ⑨ CUSHION MIC ③ PLATE LEVER POWER ④ PLATE MODE DIAL ⑧ ASSY HOT SHOE ⑥ LEVER POWER ⑤ KNOB MODE DIAL ⑦ PLATE HOT SHOE Fig. 3-21 Copyright© 1995-2012 SAMSUNG. All rights reserved. 3-11...

  • Page 25: General Support - Disassembly

    ③ PLATE MOUNT SPRING ④ SHAFT LENS DETECT ⑤ SPRING LENS DETECT PIN ① PLATE MOUNT LENS ③ PLATE MOUNT SPRING ⑤ SPRING LENS DETECT PIN ④ SHAFT LENS DETECT ② MOUNT-INNER Fig. 3-23 Copyright© 1995-2012 SAMSUNG. All rights reserved. 3-12...
  • Page 26 ④ SPING (Refer to Fig. CAUTION Take care not to misplace it when removing the BLACK RING. ② BLACK RING Fig. M ④ SPRING ③ BUTTON LENS UNLOCK ① DECO RING FRONT Fig. N Fig. 3-25 Copyright© 1995-2012 SAMSUNG. All rights reserved. 3-13...
  • Page 27 SCREW-TAPTYPE (M1.7 x L3.5 / BLK) 6003-001641 Fig. 3-26 6) Lift up the HOLDER INNER MOUNT in the direction of the green arrow. 7) Remove the ASSY COVER FRONT. HOLDER INNER MOUNT ASSY COVER FRONT Fig. 3-27 Copyright© 1995-2012 SAMSUNG. All rights reserved. 3-14...
  • Page 28 6003-001739 Fig. O Fig. P Fig. 3-28 9) Remove the following parts in the order indicated below. ① GRIP FRONT ② HOLDER STRAP L ② HOLDER STRAP L ① GRIP FRONT Fig. 3-29 Copyright© 1995-2012 SAMSUNG. All rights reserved. 3-15...
  • Page 29 SCREW-MACHINE (M1.7 x L4 / BLK) ① 6001-002279 ② ASSY CMOS SCREW-SPECIAL (M1.4 x L4.7 / WHT) ③ 6009-001410 ④ ASSY -SHUTTER ⑤ ASSY-INNER MOUNT HOLDER ⑥ SPRING-CS HOLDER MOUNT ⑦ ASSY LENS DETECT PCB Fig. 3-30 Copyright© 1995-2012 SAMSUNG. All rights reserved. 3-16...

  • Page 30: Reassembly

    SCREW-MACHINE (M1.7 x L4 / BLK) ⑦ 6001-002279 ⑥ ASSY CMOS SCREW-SPECIAL (M1.4 x L4.7 / WHT) ⑤ 6009-001410 ④ ASSY -SHUTTER ③ ASSY-INNER MOUNT HOLDER ② SPRING-CS HOLDER MOUNT ① ASSY LENS DETECT PCB Fig. 3-31 Copyright© 1995-2012 SAMSUNG. All rights reserved. 3-17...
  • Page 31 Fig. 3-32 3) Tighten the 3 screws as illustrated in Fig. A Fig. B. SCREW-TAPTYPE (M1.4 x L4 / NI) SCREW-TAPTYPE (M1.4 x L4 / NI) 6003-001739 6003-001739 Fig. A Fig. B Fig. 3-33 Copyright© 1995-2012 SAMSUNG. All rights reserved. 3-18...
  • Page 32 4) Lay the HOLDER INNER MOUNT over the ASSY COVER FRONT in the direction of the green arrow. 5) Install the ASSY COVER FRONT. HOLDER INNER MOUNT ASSY COVER FRONT Fig. 3-34 6) Tighten the 2 screws. SCREW-TAPTYPE (M1.7 x L3.5 / BLK) 6003-001641 Fig. 3-35 Copyright© 1995-2012 SAMSUNG. All rights reserved. 3-19...
  • Page 33 ③ BLACK RING Fig. C ② BUTTON LENS UNLOCK ① SPRING ④ DECO RING FRONT Fig. E Fig. D Fig. 3-36 8) Tighten the 3 screws. SCREW-MACHINE (M1.4 x L4 / NI) 6001-002159 Fig. 3-37 Copyright© 1995-2012 SAMSUNG. All rights reserved. 3-20...
  • Page 34 ① SPRING LENS DETECT PIN ② SHAFT LENS DETECT ④ MOUNT-INNER Fig. 3-38 10) Tighten the 4 screws. SCREW-MACHINE (M1.7 x L5 / NI-Cr) 6001-002662 SCREW-MACHINE (M1.7 x L5 / NI) 6001-002662 Fig. 3-39 Copyright© 1995-2012 SAMSUNG. All rights reserved. 3-21...

  • Page 35: General Support - Reassembly

    ⑩ BUTTON WIFI ② CUSHION MIC ⑨ DECORATION WIFI ⑧ PLATE LEVER POWER ⑦ PLATE MODE DIAL ③ ASSY HOT SHOE ④ PLATE HOT SHOE ⑤ LEVER POWER ⑥ KNOB MODE DIAL Fig. 3-40 Copyright© 1995-2012 SAMSUNG. All rights reserved. 3-22...
  • Page 36 Fig. 3-41 3) Solder to the 11 specified locations by the blue circle. CAUTION Be especially careful not to touch the surrounding circuitry and components when soldering on the ASSY PCB SUB. Fig. 3-42 Copyright© 1995-2012 SAMSUNG. All rights reserved. 3-23...
  • Page 37 SCREW-MACHINE (M1.7 x L3.5 / NI) 6001-001914 SCREW-TAPTYPE (M1.4 x L4 / NI) 6003-001739 SCREW-TAPTYPE (M1.4 x L4 / NI) 6003-001739 Connect the FPCB from the connector. 1. Connect. 2. Close. FPCB FPCB Fig. F Fig. 3-44 Copyright© 1995-2012 SAMSUNG. All rights reserved. 3-24...
  • Page 38 Disassembly and reassembly 7) Tighten the screw as illustrated in Fig. G. SCREW-MACHINE (M1.7 x L3 / NI) 6001-002282 Fig. G Fig. 3-45 8) Install the ASSY COVER TOP. ASSY TOP Fig. 3-46 Copyright© 1995-2012 SAMSUNG. All rights reserved. 3-25...
  • Page 39 12) Install the following parts in the order as illustrated in Fig. J ① CUSHON LCD ② LCD ③ ASSY PLATE LCD ③ ASSY PLATE LCD ASSY WHEELKEY ② LCD FPC BACK INTERFACE ① CUSHON LCD Fig. I Fig. J Fig. 3-48 Copyright© 1995-2012 SAMSUNG. All rights reserved. 3-26...
  • Page 40 ⑤ ASSY WHEELKEY / FPC BACK INTERFACE ④ ASSY PLATE LCD / LCD ⑤ ASSY WHEELKEY / FPC BACK INTERFACE ③ BUTTON FUNCTION ② BUTTON REC ① WINDOW ACCESS_NX200 COVER BACK Fig. 3-49 Copyright© 1995-2012 SAMSUNG. All rights reserved. 3-27...
  • Page 41 15) Tighten the 5 screws. 16) Connect the FPCB as illustrated in Fig. L. SCREW-TAPTYPE (M1.4 x L3 / NI) 6003-001660 Connect the FPCB from the connector. 1. Connect. 2. Close. FPCB FPCB Fig. L Fig. 3-51 Copyright© 1995-2012 SAMSUNG. All rights reserved. 3-28...
  • Page 42 SCREW-MACHINE (M1.4 x L4 / NI) 6001-002159 SCREW-TAPTYPE (M1.4 x L3 / NI) 6003-001660 Connect the FPCB Connect the WIRE 2. Close. 1. Connect. 2. Close. 1. Connect. WIRE WIRE FPCB FPCB Fig. O Fig. P Fig. 3-53 Copyright© 1995-2012 SAMSUNG. All rights reserved. 3-29...
  • Page 43 FPCBs. Follow this order when connecting the FPCB. FPCB FPCB FPCB Fig. Q Connect the FPCB. 1. Connect. 2. Close. SCREW-TAPTYPE (M1.4 x L4 / NI) 6003-001739 FPCB FPCB Fig. R Fig. 3-55 Copyright© 1995-2012 SAMSUNG. All rights reserved. 3-30...
  • Page 44 2. Close. FPCB FPCB Fig. S Fig. 3-56 25) Connect the FPCB as illustrated in Fig. T. Connect the FPCB from the connector. FPCB 1. Connect. FPCB FPCB 2. Close. Fig. T Fig. 3-57 Copyright© 1995-2012 SAMSUNG. All rights reserved. 3-31...
  • Page 45 27) Tighten the 2 screws on the left side. / 1 screw on the right side / 4 screws on the bottom side. SCREW-MACHINE (M1.4 x L4 / BLK) SCREW-MACHINE (M1.4 x L4 / BLK) 6001-002152 6001-002152 SCREW-MACHINE (M1.4 x L4 / BLK) 6001-002152 Fig. 3-59 Copyright© 1995-2012 SAMSUNG. All rights reserved. 3-32...

  • Page 46: Pcb Diagrams

    PCB diagrams 4. PCB diagrams 4-1 MAIN PCB BOTTOM 4-2 TOP PCB BOTTOM Copyright© 1995-2012 SAMSUNG. All rights reserved.

  • Page 47: Cis Pcb

    PCB diagrams 4-3 CIS PCB BOTTOM 4-4 DRS PCB BOTTOM Copyright© 1995-2012 SAMSUNG. All rights reserved.

  • Page 48: Hotshoe Fpcb

    PCB diagrams 4-5 HOTSHOE FPCB BOTTOM 4-6 BACK IF FPCB Copyright© 1995-2012 SAMSUNG. All rights reserved.

  • Page 49: Block Diagram

    DISPLAY BLOCK Audio IO전원(A/D포함): 3.3V Codec(2ch) X-tal X-tal TX/RX UART Switch I2S Ch2 32.768KHz 26MHz Match ARM9 JTAG/ SRP JTAG Wi-Fi INTERFACE AUDIO INTERFACE USER INTERFACE 외부 스피커 출력 검토 Ext. Mic 음성신호 MCLK (8.2MHz) Copyright© 1995-2012 SAMSUNG. All rights reserved.

  • Page 50: Firmware Update

    OK button Down button OK button Right button +OK (Press and hold the Del( ) button and OK buttons simultaneously.) Up button OK button w, r Right button +OK button Down button Fig. 6-3 Copyright© 1995-2012 SAMSUNG. All rights reserved.
  • Page 51 6. Turn off the camera. Power off Fig. 6-6 7. Turn on the camera by turning the power switch to the right. Then Check the initialization setting to insure that it is successfully initialized. Fig. 6-7 Copyright© 1995-2012 SAMSUNG. All rights reserved.

  • Page 52: Firmware Update By Using User Menu

    4. Press the menu button. MENU button Fig. 6-9 5. Use the arrow keys to move tab “Settings 3”and select the “Device Information” item. (Press the OK button) Select OK button Select Fig. 6-10 Copyright© 1995-2012 SAMSUNG. All rights reserved.
  • Page 53 Select Fig 6-11 9. Press the OK button to begin the body firmware. Body firmware may take up to 2 to 3 minutes. Once it is complete, camera will turn off automatically. Fig 6-12 Copyright© 1995-2012 SAMSUNG. All rights reserved.

  • Page 54: Firmware Update By Using Cs Menu

    * Update can only be made when the battery level is full(3 bars). 3. Turn on the camera by turning the power switch to the right. Power ON Fig. 6-13 4. Select the smart auto by turning the mode dial to the right. Fig. 6-14 Copyright© 1995-2012 SAMSUNG. All rights reserved.
  • Page 55 Down button Fig. 6-15 6. Select the FW UPDATE and press the OK button. Select OK button Fig. 6-16 7.Select the BODY FW UPDATE and press the OK button. Select OK button Fig. 6-17 Copyright© 1995-2012 SAMSUNG. All rights reserved.
  • Page 56 8. Press the OK button to select the body firmware update.(Green LED will flash) OK button Fig. 6-18 9.Press the OK button to begin the firmware update. It may take up to 2 to 3 minutes. Once it is complete, camera will turn off automatically. Fig. 6-19 Copyright© 1995-2012 SAMSUNG. All rights reserved.

  • Page 57: How To Recover The Main Pcb

    - It is used to short out the TP on MAIN PCB. 3. The latest firmware files such as nx1000.bin, nx1000.Rom. - You can download the latest firmware file from the K-zone or Samsung website. 4. Five recovery 5 files such as dnloader.bin, ONBL1.bin, ONBL2.bin, update.bin and rom.txt.

  • Page 58: Adjustment

    - Light Source Box 2 : LSB-1/10 (5500K, Lv. 16) 3. It is required to go through the process of adjustment completion after all the adjustment process is complete. Confirm with the process completion message. (Please refer to 7-9 adjustment completion report.) Copyright© 1995-2012 SAMSUNG. All rights reserved.

  • Page 59: Adjustmnet Menu Function Description

    OK button Down button OK button Right button +OK button (Press and hold the Del( ) button and OK buttons simultaneously.) Up button OK button w, r Right button +OK button Down button Fig. 7-3 Copyright© 1995-2012 SAMSUNG. All rights reserved.

  • Page 60: Lens Control

    (2) Set the wide value of zoom lens (5) LENS MOUNT INFO (3) Set the telephoto(tele) value of zoom lens. (6) LENS COMM SEVE * Do not move the lens during the LENS CONTROL process. Copyright© 1995-2012 SAMSUNG. All rights reserved.

  • Page 61: Cis Tilt Adjustment

    0.0 ±0.01 RightDown 0.0 ±0.01 * Screw : NX100, NX210, NX1000 Star(T6), NX 10/5/11 hexagon Fig. 7-6 2. Tilt specification after installing the product measured the value of tilt after installing the product. Confirm if it is within the below specification.

  • Page 62: Cis Dot Input & Shutter Speed Adjustment Program Installation

    <Program installation manuel> 1. Extract the NX_SHUTTER_ADJ.zip file provided. 2. ZIP file contains the below files. Fig. 7-7 3. Extract the NXCISTEMP_NX200.zip to the C:\ directory. It contains the below files. NX200 Fig. 7-8 Copyright© 1995-2012 SAMSUNG. All rights reserved.

  • Page 63: Cis Dot Input & Shutter Speed Adjustment

    Cancel Fig. 7-9 5. Install the libusb_win32-filter0bin-1.1.14.3.exe file. - This step is required to communicate NX1000 and PC. (Install only one time.) 7-5 CIS dot input & shutter speed adjustment ■ Adjust the CIS Dot Input and Shutter Speed Adjustment.
  • Page 64 It will attempt to download the “CIS DOT” file via FTP server. - Press the OK button to continue. Downloading CIS DOT data... It helps you make connection to an FTP server. Downloading CIS DOT data is complate. Fig. 7-14 Copyright© 1995-2012 SAMSUNG. All rights reserved.
  • Page 65 Go to Option → Open SCRIPT FILE. Then select the shutter.txt from the Dot Input_Shutter ADJ folder. Dot Input_Shutter ADJ folder. - Press the open button. Cancel Fig. 7-16 Input the serial number in the gray tap above the start button. Fig. 7-17 Copyright© 1995-2012 SAMSUNG. All rights reserved.
  • Page 66 Dot data does not exist. Fig. 7-18 Once the process is completed, the completion message will be displayed.  - Repeat the above process when the FAIL message is displayed. 0070067 0070067 Fig. 7-19 Copyright© 1995-2012 SAMSUNG. All rights reserved.

  • Page 67: Iso & Awb Low Adjustment

    2. Attach the master lens to the camera body and insert the SD card into the camera. 3. Attach the camera to the 3200K light box as illustrated in the image below. When turning on the camera, the process will proceed automatically. Light source box Camera Fig. 7-20 7-10 Copyright© 1995-2012 SAMSUNG. All rights reserved.

  • Page 68: Vfpn & Cmos Defect Adjustment

    - Camera temperature should be more than degree to proceed the VFPN adjustment. - Camera may heat up during the operation due to the camera being on for extended periods of time. Make sure to set the correct temperature. Copyright© 1995-2012 SAMSUNG. All rights reserved. 7-11...

  • Page 69: Color Shading Adjustment

    Press the OK button to proceed the process. - Once the process is complete, “CS ADJUSTMENT OK!! POWER OFF” message will be displayed on the LCD. Finally the camera is automatically turned off. Light source box Camera Fig. 7-21 7-12 Copyright© 1995-2012 SAMSUNG. All rights reserved.

  • Page 70: Adjustment Completion Report

    - LCD screen will display the error message. Then repeat the adjustment process as indicated on screen. In this occasion, repeat the ISO adjustment process. Flash Check [MEM_CHK] ADJUST_ISO_SENSTIVITY_ PROCESS_MARK 170 <= 0 <= 170 Fig. 7-22 Copyright© 1995-2012 SAMSUNG. All rights reserved. 7-13...

  • Page 71: Exploded View And Parts List

    BLACK AD61-06096B PLATE-SPRING SHOE_SL WHITE/PINK AD63-06184A COVER HOT SHOE_BK BLACK AD63-06184C COVER HOT SHOE_WT WHITE AD63-06184D COVER HOT SHOE_BK PINK AD68-07395A LABEL-FCC_EXP AD99-04065A TOTAL ASSY_BK BLACK AD99-04053B TOTAL ASSY_WT WHITE AD99-04080A TOTAL ASSY_PK PINK Copyrightⓒ 1995-2011 SAMSUNG. All rights reserved.

  • Page 72: Body Assembly

    AD97-22685C ASSY FRONT_PK PINK AD97-21624A ASSY-SHUTTER AD66-01033A DAMPER-SHUTTER 6009-001410 SCREW-MACHINE (M1.4 X L4.7/WH) AD61-05757A HOLDER TRIPOD 6001-002152 SCREW-MACHINE (M1.4 X L4/BK)_BK BLACK 6001-002159 SCREW-MACHINE (M1.4 X L4/BK)_WT WHITE 6001-002159 SCREW-MACHINE (M1.4 X L4/BK)_PK PINK Copyrightⓒ 1995-2011 SAMSUNG. All rights reserved.
  • Page 73 AD41-01882A DRS_IF_FPC AD97-22688A ASSY TOP_BK BLACK AD97-22688B ASSY TOP_WT WHITE AD97-22688C ASSY TOP_PK PINK 6001-002282 SCREW-MACHINE (M1.7 X L3/NI) AD97-22686A ASSY BACK AD90-05104A BODY ASSY_BK BLACK AD90-05104B BODY ASSY_WT WHITE AD90-05104C BODY ASSY_PK PINK Copyrightⓒ 1995-2011 SAMSUNG. All rights reserved.

  • Page 74: Front Assembly

    Exploded view and parts list 8-3 FRONT ASSEMBLY Copyrightⓒ 1995-2011 SAMSUNG. All rights reserved.
  • Page 75 SPRING LENS DETECT PIN AD61-05314A PLATE MOUNT SPRING AD61-05307A MOUNT-INNER AD61-05284A PLATE MOUNT LENS 6001-002662 SCREW-MACHINE (M1.7 X L5/Ni-Cr) AD67-01399A CAP MOUNT AD97-22685A ASSY FRONT_BK BLACK AD97-22685B ASSY FRONT_WT WHITE AD97-22685C ASSY FRONT_PK PINK Copyrightⓒ 1995-2011 SAMSUNG. All rights reserved.

  • Page 76: Back Cover Assembly

    WHITE AD92-01959A ASSY WHEELKEY_PK PINK AD92-01902A FPC BACK INTERFACE 6003-001660 SCREW-TAPTYPE (M1.4 X L3 / NI) AD81-10117A WINDOW LCD AD97-22681A ASSY COVER BACK_BK BLACK AD97-22681B ASSY COVER BACK_WT WHITE AD97-22681C ASSY COVER BACK_PK PINK Copyrightⓒ 1995-2011 SAMSUNG. All rights reserved.

  • Page 77: Back Sub Cover Assembly

    AD64-03728B BUTTON REC_SL WHITE/PINK AD64-03727A BUTTON FN_BK BLACK AD64-03727B BUTTON FN_WT WHITE AD64-03727C BUTTON FN_PK PINK AD97-22681A ASSY COVER BACK SUB_BK BLACK AD97-22681B ASSY COVER BACK SUB_WT WHITE AD97-22681C ASSY COVER BACK SUB_PK PINK Copyrightⓒ 1995-2011 SAMSUNG. All rights reserved.

  • Page 78: Inner Mount Holder Assy

    PLATE IF PIN 6003-001679 SCREW-TAPTYPE (M1.7 X L2.5 / NI) AD92-01756A ASSY LENS DETECT PCB 6003-001641 SCREW-TAPTYPE(M1.7 X L3.5 / BLK) AD63-06305A SHEET ABSORB A AD63-06306A SHEET ABSORB B AD97-22689A ASSY HOLDER INNER MOUNT Copyrightⓒ 1995-2011 SAMSUNG. All rights reserved.

  • Page 79: Top Sub Cover Assembly

    Exploded view and parts list 8-7 TOP SUB COVER ASSEMBLY Copyrightⓒ 1995-2011 SAMSUNG. All rights reserved.
  • Page 80 PLATE LEVER POWER AD81-10062A BADGE NX_BK AD81-10062B BADGE NX_WT AD81-10062C BADGE NX_PK AD63-07095A T/SHEET MIC AD97-22680A ASSY COVER TOP SUB_BK BLACK AD97-22680B ASSY COVER TOP SUB_WT WHITE AD97-22680C ASSY COVER TOP SUB_PK PINK 8-10 Copyrightⓒ 1995-2011 SAMSUNG. All rights reserved.

  • Page 81: Top Cover Assembly

    Exploded view and parts list 8-8 TOP COVER ASSEMBLY 8-11 8-11 Copyrightⓒ 1995-2011 SAMSUNG. All rights reserved.
  • Page 82 HOLDER STRAP R 6003-001739 SCREW-TAPTYPE (M1.4X L4 / NI) AD92-01896A ASSY PCB TOP 6003-001739 SCREW-TAPTYPE (M1.4X L4 / NI) AD81-10119A CUSHION-AF LED AD97-22688A ASSY TOP_BK BLACK AD97-22688B ASSY TOP_WT WHITE AD97-22688C ASSY TOP_PK PINK 8-12 Copyrightⓒ 1995-2011 SAMSUNG. All rights reserved.

  • Page 83: Chamber Assebly

    6107-001538 SPRING AD66-01036A LEVER BATTERY LOCK 6044-001137 RING-E 6107-003085 SPRING AD61-05741A PLATE CHAMBER AD63-02351A SHIELD FOAM AD61-05754A HOLDER STRAP L AD63-06991A GRIP FRONT_BK BLACK AD63-06991B GRIP FRONT_WT WHITE AD63-06991C GRIP FRONT_PK PINK 8-13 8-13 Copyrightⓒ 1995-2011 SAMSUNG. All rights reserved.
  • Page 84 COVER DUMMY BATTERY_BK BLACK AD63-06180C COVER DUMMY BATTERY_SL WHITE/PINK AD61-05742A PLATE OCVER BATTERY AD66-00943A SHAFT BATTERY COVER 6107-002994 SPRING AD64-03730A WINDOW AF AD97-22683A ASSY COVER-BATTERY AD97-22679A ASSY-CHAMBER_BK BLACK AD97-22679B ASSY-CHAMBER_WT WHITE AD97-22679C ASSY-CHAMBER_PK PINK 8-14 Copyrightⓒ 1995-2011 SAMSUNG. All rights reserved.

  • Page 85: Holder Cmos Assebly

    AD92-01933A ASSY PCB CIS AD63-06276A CUSHION CMOS AD61-05740A HOLDER OLPF AD67-02217A RUBBER CMOS AD97-21669A ASSY-PZT AD97-21628A ASSY PLATE PZT 6001-002159 SCREW-MACHINE (M1.4 X L4 / NI) AD41-01765B CIS FPCB AD97-22687A ASSY CMOS 8-15 8-15 Copyrightⓒ 1995-2011 SAMSUNG. All rights reserved.
  • Page 86 Exploded view and parts list 8-11 HOLDER CMOS ASSEBLY Loc. No Parts No. Description Q ty Available Remark AD61-05765A HOLDER SPEAKER 3001-002641 SPEAKER AD92-01904A DRS PCB 6003-001660 SCREEW TAP M1.4 X L3.0 AD97-22693A ASSY-SPK DRS 8-16 Copyrightⓒ 1995-2011 SAMSUNG. All rights reserved.

  • Page 87: Holder Mount Assebly

    SHAFT GUIDE CMOS B AD97-22601A HOLDER MOUNT ASSY 8-13 PLATE LCD ASSEBLY Loc. No Parts No. Description Q ty Available Remark AD61-05747A PLATE LCD AD63-06508A T/SHEET EMI B AD97-22674A ASSY PLATE LCD 8-17 8-17 Copyrightⓒ 1995-2011 SAMSUNG. All rights reserved.

  • Page 88: Pcb Sub Assebly

    Parts No. Description Q ty Available Remark AD41-01881A FPCB:NX1000_BACK_FI_FPCB 3708-002577 CONNECTOR-45P 3708-002856 CONNECOTR-10P 8-15 HOTSHOE FPCB ASSEBLY Loc. No Parts No. Description Q ty Available Remark AD94-00360A HOT SHOE FPCB 3003-001159 MIC-CONDENSOR AD67-02416A RUBBER-MIC 8-18 Copyrightⓒ 1995-2011 SAMSUNG. All rights reserved.

  • Page 89: Packing Items

    AC CODE CABLE_UK 3903-000612 AC CODE CABLE_AUS-D1 3903-000617 AC CODE CABLE_BRA 3903-000611 AC CODE CABLE_CHINA 3903-000610 AC CODE CABLE_ARG AD46-00438A Software CD-ROM AD68-07366A NX1000_QG_ENG(SEA) AD68-07367A NX1000_QG_SPA(SEA) AD63-07021A Strap_BK AD63-07021C Strap_PK AD63-07021B Strap_WT 8-19 8-19 Copyrightⓒ 1995-2011 SAMSUNG. All rights reserved.
  • Page 90 E.Asia, W.Asia, China, Japan https://gspn2.samsungcsportal.com N.America, S.America https://gspn3.samsungcsportal.com © 2012 SAMSUNG Electronics Co.,Ltd This Service Manual is a property of Samsung Electronics Co.,Ltd. All rights reserved. Any unauthorized use of Manual can be punished under Printed in Korea applicable International and/or domestic law.
