AUTOMATIC POOL SUCTION
CLEANER VACUUM
FOR IN-GROUND & ABOVE-GROUND
SWIMMING POOL
ASSEMBLY AND USER'S GUIDE
DANGER
Read all safety warnings and instructions. Failure to follow the warnings
and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
ITEM: 75037
75037
Advertisement
Table of Contents
Related Manuals for XtremepowerUS 75037
Summary of Contents for XtremepowerUS 75037
- Page 1 AUTOMATIC POOL SUCTION ITEM: 75037 CLEANER VACUUM FOR IN-GROUND & ABOVE-GROUND SWIMMING POOL ASSEMBLY AND USER’S GUIDE 75037 DANGER Read all safety warnings and instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury.
-
Page 3: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS Legends and Symbols GENERAL SAFETY OVERVIEW (PRODUCT INFORMATION) PACKAGING CONTENTS INTRODUCTION DIMENSIONS SPECIFICATIONS ASSEMBLY STEP 1 STEP 2 STEP 3 STEP 4 STEP 5 STEP 6 STEP 7 STEP 8 STEP 9 OPERATION ADJUSTMENT TROUBLESHOOTING... -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS This guide provides instructions for installing / assembling and using the product. If you have any questions about the product, please contact XtremepowerUS. This guide contains important information about safely installing and operating this product. After installation, make sure to share this information with the owner/operator or leave it with them for their reference. -
Page 5: General Safety
IMPORTANT SAFETY INSTRUCTIONS GENERAL SAFETY DANGER Do Not Modify the Product: • Unauthorized modification may impair the function and/or safety of the product, potentially resulting in serious injury or damage. Avoid Entrapment: • The suction from the hose or cleaner can trap a swimmer underwater. Never allow anyone to enter the pool when the cleaner is in use. - Page 6 IMPORTANT SAFETY INSTRUCTIONS CAUTION Supervise Use Around the Pool: • Ensure that no one, especially children, uses or plays with the cleaner, hose, or suction ports. Educate pool users about the dangers associated with these components. Inspect the Pool Before Use: •...
-
Page 7: Overview (Product Information)
OVERVIEW (PRODUCT INFORMATION) OVERVIEW (PRODUCT INFORMATION) PACKAGING CONTENTS PARTS # ROLLER BUMPER STRAP 1 PC(S) PARTS # PARTS # DIVE FLOAT RESTRICTOR PLEATED SEAL 1 PC(S) PARTS # 1 PC(S) CLEANER ASSEMBLY 1 PC(S) PARTS # PARTS # PARTS # PARTS # EYEBALL DIVERTER HOSE CONE... -
Page 8: Introduction
OVERVIEW (PRODUCT INFORMATION) INTRODUCTION XtremepowerUS In-ground Pool Suction Cleaner Vacuum, the ultimate solution for effortless pool maintenance. Designed to clean inground pools from top to bottom automatically, this cleaner offers powerful suction to pick up everything from dirt and bugs to pebbles and twigs, allowing for more time spent enjoying the pool and less time cleaning it. -
Page 9: Specifications
OVERVIEW (PRODUCT INFORMATION) SPECIFICATIONS NO ELECTRICITY NEEDED, NO TOOLS REQUIRED POWER-FREE OPERATION UP TO 16 FT X 34 FT POOL COMPATIBILITY AT LEAST 3/4 HP POOL PUMP OR 1,600 GPH PUMP REQUIREMENTS 30 FT VACUUM HOSE INCLUDED ACCESSORIES IN-GROUND, ABOVE-GROUND SUITABLE POOL TYPE 1.5”... -
Page 10: Assembly
ASSEMBLY ASSEMBLY STEP 1 PARTS # PARTS # PARTS # PARTS #... -
Page 11: Step
ASSEMBLY STEP 2 PARTS # PARTS #... - Page 12 INSTALLATION INSTALLATION ASSEMBLY STEP 3 PARTS #...
- Page 13 ASSEMBLY STEP 4 PARTS # WEIGHT: 3 FT FROM SWIVEL HEAD PARTS # WEIGHT: 6 FT FROM SWIVEL HEAD PARTS # WEIGHT: 9 FT FROM SWIVEL HEAD POOL DEPTH PART # 14 WEIGHT PLACEMENT 4 FT OR LESS WEIGHT: 3 FT FROM SWIVEL HEAD 4 ~ 7 FT WEIGHT: 6 FT FROM SWIVEL HEAD 7 ~ 12 FT...
-
Page 14: Step 5
ASSEMBLY STEP 5 PARTS # PARTS # FEMALE CUFF MALE CUFF MALE CUFF FEMALE CUFF FEMALE CUFF PARTS # MALE CUFF... - Page 15 ASSEMBLY STEP 6 PARTS # COPING FILL HOSE WITH POOL WATER TO REMOVE AIR WATERLINE SUBMERGE HOSE INTO POOL BUBBLE SUBMERGE CLEANER & HOSE INTO POOL BUBBLE...
-
Page 16: Step 7
ASSEMBLY STEP 7 PARTS # PARTS # THE LAST MALE TO FEMALE HOSE THE LAST MALE CUFF THE FEMALE CUFF OF PARTS# 17 OF PARTS# 16 PARTS # THE LAST FEMALE CUFF END OF PARTS# 16 THE MALE CUFF END OF PARTS# 15 VALVE PARTS #... -
Page 17: Step 8
INSTALLATION ASSEMBLY STEP 8 FOR POOL SKIMMER CONNECTION COPING SKIMMER BASKET WATERLINE WEIR WATERLINE PARTS # SUCTION PORT SWIMMING POOL THE MALE CUFF END OF PARTS# 6... - Page 18 ASSEMBLY STEP 9 FOR DEDICATED POOL VACUUM / SUCTION LINE CONNECTION COPING WATERLINE POOL VACUUM / SUCTION / RETURN LINE...
-
Page 19: Operation
OPERATION OPERATION ADJUSTMENT After installation, turn on the pool pump and let it run for a few minutes to remove all air from the system. The cleaner should move at 8 to 12 FT per minute. Check the following adjustments: CAUTION Check the hose length with the pump on, as it contracts during operation. -
Page 20: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING Because of the individual characteristics of the pool, some additional adjustments may be required to get the best performance from the cleaner. GENERAL CHECKS • Bottom main drain: Close the drain. • Filter: Ensure it is clean. • Pump strainer basket: Clean if necessary. - Page 21 TROUBLESHOOTING CLEANER PULLS AIR OR REMAINS AT THE WATER'S SURFACE • Ensure the dive float mechanism operates freely and the dive float restrictor is installed. • Verify the automatic regulator valve is correctly installed and not clogged. • Maintain the water level at least 2 inches below the pool deck. •...
- Page 22 TROUBLESHOOTING REMOVING DEBRIS FROM THE FLAPPER • Turn the cleaner upside down and jiggle the flapper or flush with a hose to remove debris. • If debris persists: Remove the four lids in the foot pad, unscrew, and remove the foot pad. ▪...
-
Page 23: Maintenance
MAINTENANCE MAINTENANCE MAINTENANCE TIPS • Inspect the flapper to ensure it moves freely and is not obstructed by debris. • Replace the foot pad if it is excessively worn. • Store the hose flat and out of direct sunlight; do not coil the hose. •... -
Page 24: Replacement Parts
REPLACEMENT PARTS REPLACEMENT PARTS PARTS DIAGRAM ITEM REF. # DESCRIPTION ITEM REF. # DESCRIPTION 647325072 ABOVE BALANCE ASSEMBLY 647325014 ROLLER BUMPER STRAP 647325073 DIVE FLOAT RESTRICTOR 65748020052 CLEANER PIPE 647325024 STRAP FIXED SUPPORT 647325074 TEE ASSEMBLY 647325012 FLAPPER 647325021 EYEBALL DIVERTER 647325071 FLAPPER PLATE 647325001... -
Page 25: Disclaimer
DISCLAIMER DISCLAIMER PLEASE READ THE FOLLOWING CAREFULLY The manufacturer and/or distributor have provided the parts list and assembly diagram in this manual for reference purposes only. They do not make any representation or warranty to the buyer that they are qualified to make repairs to the product or replace any parts of the product. In fact, the manufacturer and/or distributor expressly state that all repairs and parts replacements should be undertaken by certified and licensed technicians, and not by the buyer.
