Summary of Contents for XtremepowerUS 75058
- Page 1 2-WHEEL SUCTION ITEM: 75058 POOL CLEANER INSTALLATION AND USER’S GUIDE 75058 DANGER Read all safety warnings and instructions. Failure to follow the warnings and instructions may result in serious injury. Save all warnings and instructions for future reference.
-
Page 3: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS Legends and Symbols GENERAL SAFETY OVERVIEW (PRODUCT INFORMATION) PACKAGE CONTENTS PRODUCT DIMENSIONS INSTALLATION STEP 1: PRIOR TO INSTALLATION STEP 2: CONNECTING HOSES AND HOSE FLOAT STEP 3: POOL SKIMMER / SUCTION CONNECTION UTILIZING THE PROGRAMMABLE FEATURE MAINTENANCE ROUTINE MAINTENANCE... -
Page 4: Important Safety Instructions
NOTICE: This label indicates important special instructions that are not directly related to hazards. USE OF NON-XTREMEPOWERUS REPLACEMENT PARTS VOIDS WARRANTY ATTENTION INSTALLER: This manual contains vital information regarding the installation, operation, and safe use of this product. It is essential to provide this manual to the end user of the product. Failure to read and follow all instructions could lead to severe injuries. -
Page 5: General Safety
IMPORTANT SAFETY INSTRUCTIONS GENERAL SAFETY READ BEFORE USE WARNING • The pool cleaner is for adult use only; children should not operate it. • Store the pool cleaner out of reach of children and away from pets. DANGER • Cover dedicated suction ports (vac port or automatic pool cleaner port) when not in use. •... -
Page 6: Overview (Product Information)
OVERVIEW (PRODUCT INFORMATION) OVERVIEW (PRODUCT INFORMATION) PACKAGE CONTENTS PARTS # PARTS # CONTROL VALVE ADAPTER FLOW CONTROL VALVE 1 SET(S) 1 PC(S) PARTS # HEAD CLEANER 1 PC(S) PARTS # PARTS # PARTS # LEADER HOSE FLOW GAUGE HOSE FLOAT 1 PC(S) 1 PC(S) 2 PC(S) -
Page 7: Product Dimensions
OVERVIEW (PRODUCT INFORMATION) PRODUCT DIMENSIONS 11.75” 5.88” 6.25” 9” 9” 7.75” 1.5” 10” 9.25”... -
Page 8: Installation
INSTALLATION INSTALLATION STEP 1: PRIOR TO INSTALLATION Before Installation • Thoroughly review the operating manual to prevent injury, operational issues, or damage. • This cleaner is not designed for the initial cleanup after pool construction or at the season's start. •... -
Page 9: Step 2: Connecting Hoses And Hose Float
INSTALLATION STEP 2: CONNECTING HOSES AND HOSE FLOAT • Attach the female cuff of Parts# 3 to the cleaner's swivel. (Figure 1) • Insert the male cuff of Parts# 3 into the female cuff of Parts# 8. (Figure 1) Figure PARTS # PARTS # FEMALE CUFF... - Page 10 INSTALLATION STEP 2: CONNECTING HOSES AND HOSE FLOAT (CONTINUED) • Place two Parts# 5 on the leader hose at specified distances. (Figure 2) 1ST Parts# 5: Directly at the cleaner's swivel area on Parts# 3. ▪ 2ND Parts# 5: 28” from 1ST Parts # 5. ▪...
- Page 11 INSTALLATION STEP 2: CONNECTING HOSES AND HOSE FLOAT (CONTINUED) • Connect Parts# 2 as needed from the skimmer or suction port to the farthest pool point, plus one extra Parts# 2. (Figure 3) SWIMMIG POOL SHAPE Figure SHAPE A SHAPE B THE FARTHEST THE FARTHEST POOL POINT...
- Page 12 INSTALLATION STEP 2: CONNECTING HOSES AND HOSE FLOAT (CONTINUED) • Connect the female cuff of Parts# 8 to the first male cuff end of Parts# 2. (Figure 4) • Connect the last female cuff end of Parts# 2 to the male cuff end of Parts# 7. (Figure 4) Figure PARTS # PARTS #...
-
Page 13: Step 3: Pool Skimmer / Suction Connection
INSTALLATION STEP 3: POOL SKIMMER / SUCTION CONNECTION For Pool Skimmer Connection • Ensure the pool pump is off and remove air from the cleaner and hose. • Remove the skimmer lid and the skimmer basket. (Figure 5) • Skimmer suction level test: (Figure 6) Connect the male cuff end of Parts# 4 to the female cuff end of Parts# 6. - Page 14 STEP 3: POOL SKIMMER / SUCTION CONNECTION (CONTINUED) For Pool Skimmer Connection (Continued) • Skimmer suction port connection: Turn off the pool pump, and detach Parts# 4 from Parts# 6, then replace it with Parts# 7. ▪ (Figure 7) Use the return jet to fill the vacuum hose with water. ▪...
- Page 15 INSTALLATION STEP 3: POOL SKIMMER / SUCTION CONNECTION (CONTINUED) For Dedicated Vacuum Line Connection • Ensure the pool pump is off and remove air from the cleaner and hose. • Skimmer suction level test: Connect the male cuff end of Parts# 4 to the female cuff end of Parts# 6. (Figure 9) ▪...
- Page 16 INSTALLATION STEP 3: POOL SKIMMER / SUCTION CONNECTION (CONTINUED) • For Dedicated Vacuum Line Connection (Continued) • Suction port connection: Turn off the pool pump, and detach Parts# 4 from Parts# 6, then replace it with Parts# 7. ▪ (Figure 11) Use the return jet to fill the vacuum hose with water.
-
Page 17: Utilizing The Programmable Feature
INSTALLATION UTILIZING THE PROGRAMMABLE FEATURE • The Compass Programmable Pool Cleaner is pre-programmed for efficient operation in most pools but can be reprogrammed to meet specific needs. This feature is ideal for pools with unique characteristics or larger sizes, allowing adjustments to enhance coverage and performance. •... -
Page 18: Maintenance
MAINTENANCE MAINTENANCE ROUTINE MAINTENANCE Hose Storage Storage: Keep the hose straight after removal to avoid coiling, which can hinder performance. Pre-Chemical Treatment Removal • Remove the cleaner and hose before adding chemicals to the pool. Post super chlorination, wait at least 4 hours before reinstallation. -
Page 19: Replacing Tires
MAINTENANCE REPLACING TIRES To Replace Tires: (Figure 15) • Power Off & Remove: Ensure the pool pump is off and lift the cleaner from the pool. • Detach Hose: Disconnect the cleaner from the hose. • Remove Bump: refer to chapter “MAINTENANCE” -> section “ADJUSTING TIRE BUMPER HEIGHT”. - Page 20 MAINTENANCE Figure...
-
Page 21: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING Cleaner Movement Issues (No Movement or Slow): • Ensure the main drain is closed. • Clean the pool filter and empty the pump strainer basket. • Check for sufficient flow through the Flow Control Valve. For dedicated vacuum lines, adjust valves at the pool pad for optimal flow. -
Page 22: Disclaimer
DISCLAIMER DISCLAIMER PLEASE READ THE FOLLOWING CAREFULLY The manufacturer and/or distributor have provided the parts list and assembly diagram in this manual for reference purposes only. They do not make any representation or warranty to the buyer that they are qualified to make repairs to the product or replace any parts of the product. In fact, the manufacturer and/or distributor expressly state that all repairs and parts replacements should be undertaken by certified and licensed technicians, and not by the buyer.
