OVERVIEW OF THIS MACHINE １． Thank you very much for selecting our Automatic Screw Feeder “NJR Series”. This machine can line up screws (Type M2 - M5) and supplies them one by one to an automatic machine to help streamline screw tightening. -
Page 3: Operating Precautions
OPERATING PRECAUTIONS ３． This manual contains safety alert symbols and signal words to help prevent injuries to the user or damage to property. ◎ Indications This indicates there is a chance of death, serious injury or fire WARNING if the instructions are not followed. This indicates there is a chance of personal injury or damage to property CAUTION if the instructions are not followed. - Page 4 WARNING Do not disassemble the AC adapter as there is a risk of electric shock, fire or malfunction. Do not damage, alter or change the power cord. Do not place heavy objects on the cord. Do not pull hard on the cord or twist the cord as it could be damaged, thereby causing a risk of fire or electric shock.
- Page 5 CAUTION Use only the AC adpater supplied with this machine otherwise it may result in a fire or electric shock. Do not install this machine in an unstable location otherwise it may fall causing damage or injury. Always operate the machine with the upper cover in place, otherwise it may result in injury. Do not allow any foreign material to enter the machine while in operation.
- Page 6 CAUTION ！ Note：About the screws stock limit If too much screws are placed into the storage chamber of the feeder, it may affect the process of screw feeding, or cause the machine to be overloaded and malfunction. Please refer to the diagram below and carefully adjust the screw level to be 2 ～ 3mm below upper edge of the rail. (When the scoop plates are at the lowest point.) ○...
-
Page 7: Names Of Machine Parts
４． NAMES OF MACHINE PARTS Rail front-rear position lock Screw bin lid Shutter (in front of screw screw passage plate) Passage plate Bit guide assembly Passage plate Holding plate lock screw （Screw guide1） Bin scooping plate Sensor Screw bin Power switch Bin scooping plate Brush... -
Page 8: Adjustments And Checks Before Use
５． ADJUSTMENTS AND CHECKS BEFORE USE Confirming the Machine’s Model Number ５ ． Before using this machine, verify that the model matches the screw size to be used. To confirm the model number, remove the escaper cover and note the labels attached to the rail assembly and escaper. The identification label marking is in RR** form. - Page 9 Checking and Adjusting the Brush ５ ２ ． Turn off the power switch before performing any check/adjustment procedure. The switch shown below is in the off position. Check the height of the brush. Ensure that the brush check/ adjustment procedure is completed while the brush is placed in Brush a horizontal position as shown at right.
- Page 10 Checking and Adjusting the Passage Plate ５ ３ ． Pssage plate retaining screw Drop few screws into the rail groove. Slide the screws to the passage Passage plate Up-down plate section and check or adjust the passage plate height. Check that the clear- adjustment ance between the passage plate upper end and the screw heads is not greater Passage plate...
- Page 11 If the holding plate (screw guide 1) height needs to be adjusted, proceed as directed below. Tilt this machine or operate it so that the screws are delivered to the escaper section. If there is no clearance between the holding plate (screw guide 1) and screw heads, the screws cannot move. The screws can move while the shutter is open with an adequate clearance provided between the holding plate (screw guide 1) and screw heads.
- Page 12 If the escaper operates in such a manner that the applied screws are not readily retained by the escaper, perform the following check/adjustment procedure. ●Check that the clearance between the rail and escaper is properly adjusted. Rail front-rear The clearance should ideally be as small as possible. Fine adjustments are needed position lock screw ...
-
Page 13: Operating Instructions
６． OPERATING INSTRUCTIONS Loading the Screws - １． ６ Open the screw bin lid. While the bin scooping plates are at the lowest Rail Approx. 3 mm position, you turn off the power, and pour in the screws until they are piled Screw bin up to about 3 mm below the rail upper surface. - Page 14 Operational features This machine is equipped with an overload protection circuit. If a movable section is overloaded during a this machine operation , for instance, when a trapped screw or other article, or excessive screw is caught up inside the screw bins, the overload protection circuit will activate. Function descriptions and remedies Under normal conditions, the drive motor in this machine rotates in normal direction to feed the loaded screws continuously to the escaper section, thereby allowing you to obtain the screws successively.
- Page 15 This machine is equipped with an external output signal cable. The incorporated signal cable enables you to obtain a signal that indicates whether a screw is present in the escaper section screw エスケーパネジ取出し部にネジが 有るか 無いか の信号を取出せます。 removal area. ネジ締めロボット、 汎用カウンター等との接続にご利用ください。 This signal wire shall be used with automativ assembly machines Signal cable [ 仕様...
- Page 16 Installation with Robotic System Fixing method When installed with a robotic assembly, the screw feeder shall be fastened by lower edges of the cover. (Please refer to diagram on the right side) Fastening screws on bottom edge of the cover can be used for this purpose as well. In addition, if the rubber supports shall be replaced with fastening assemblies When using the fastening screw hole in the lower part of the feeder shown in the figure on the right, please keep length of the screws less than 8mm going...
-
Page 17: Maintenance
７． MAINTENANCE Before performing any maintenance, turn off the power switch CAUTION and remove all the loaded screws from this machine. ７- １． Cleaning the Rail and Rail Guide Wall When the rail groove is soiled, the screw feeding speed may become lower. If such a situation is encountered, wipe the rail groove clean with a thin, clean cloth moistened with alcohol. - Page 18 ７- ２． Installing the Rail Assembly and Escaper Components After cleaning, reassemble the rail section by reversing the rail removal procedure. Be sure to lodge the escaper drive gear pin in the escaper rail groove as shown on right. Escaper rail groove Escaper Sensors Lodge the escaper drive gear...
-
Page 19: Replacing Parts
8. REPLACING PARTS Rail front-rear position lock screw ●Replacing the rail assembly The rail assembly of this machine can easily be replaced. Escaper If the loaded screws do not smoothly feed after cleaning or if you intend to use a different screw diameter, replace the rail assembly. - Page 20 ●Replacing the brush If the ends of the brush bristles are worn out so that improperly oriented screws cannot be swept away, please replace the brush. To replace the brush, position it as shown. You can adjust its position by rotating the timing shaft. Remove the brush assembly mounting screws and then the brush assembly.
- Page 21 Adjustments to be made after rail assembly/escaper replacement ① .Adjust the clearance between the rail assembly and escaper. ---> Adjust the rail assembly mounting position (front-rear adjustment). The clearance should be minimized. Fine adjustments are needed particularly when the applied screws have a small diameter. For the adjustment procedure, see page 11.
- Page 22 ③ .Adjust the clearance between the rail lateral surface and escaper screw receiver. --> Adjust the escaper screw receiver mounting position (left-right adjustment). Position the escaper screw receiver so that a clearance of about 0.1 to 0.3 mm is provided between the rail lateral surface and escaper screw receiver.
- Page 23 ⑤ .Adjust the positional relationship between the rail groove and escaper groove. ---> Adjust the rail bracket stopper mounting position (left-right adjustment). Position the rail bracket stopper so that the escaper groove is aligned with the rail groove when the escaper moves to receive a screw from the rail.
-
Page 24: Troubleshooting
９． TROUBLESHOOTING CAUTION Before taking any action, please turn OFF the power switch. Problem Cause Remedy -No power is supplied. -Ensure that the AC adapter is properly connected The machine does not to a power source. start when power -The screw in the removal section has not -Remove the screw from the removal section. - Page 25 Problem Cause Remedy -The clearance between the holding plate -Shift the holding plate (screw guide 1) upward. The screws on the rail (screw guide 1) and screw heads is Use the machine in a tilted position. do not feed smoothly. insufficient.
- Page 26 Problem Cause Remedy -The timer setting control is improperly -Readjust the timer setting control. The bin scooping adjusted. plates fail to stop moving when there is a screw in the pick-up section. -The screw is not detected by the sensor in -Readjust the sensor bracket assembly.
-
Page 27: Specifications
１０． SPECIFICATIONS NOTES Exclusive adapter Input ：AC100～240V 50/60Hz -Measure the shank diameter of the screw to be used and then check （Switching type） Output ：DC15V whether it matches the rail groove reference dimension. -Within The range of screw size and length below,there may be instances of Dimension 134W X 274D X 139H (mm) unique screw shape or structure not compatible with this machine unit. - Page 28 Screw nominal Exchange Kit Rail model Escaper model Passage plate Type Model number diameter number number number model number NJR-2320 φ2.0 RR20SET RR20 W2320 NJR-2323 φ2.3 RR23SET RR23 W2323 NJR-23 NJR-2326 φ2.6 RR26SET RR26 W2326 NJR-2330 φ3.0 RR30SET RR30 W2330 NJR-4535 φ3.5 RR35SET...
-
Page 29: External Dimensions
１１． EXTERNAL DIMENSIONS Screw Dimension diameter (to the center of the screw) Power switch Signal line out DC jack [unit : mm] - ２８-... -
Page 30: Warranty
１２． WARRANTY For users within Japan,the product is warranted for a period of six months after the date of delivery. Such warranty will not be ap- plicable to purchases or users outside of Japan.If any troubles should occur, however, contact your local dealer. The solutions to the following situations may be implemented at a reasonable charge without regard to the warranty period. - Page 31 Fax +81-191-24-3145 Fax +81-191-24-3145 「Quicher」 「OHTAKE」 「OHTAKE ・ ROOT KOGYO」 is a trademark or registerd trademark of OHTAKE ・ ROOT KOGYO CO.,LTD.] 「Quicher( クイッチャー）」 「OHTAKE」 「OHTAKE ・ ROOT KOGYO」 は、 株式会社 大武 ・ ルート工業の商標又は登録商標です。 The specification and the design of a product may be changed without a preliminary announcement for improvement.
