Automatic Screw Feeder
ＱＵＩＣＨＥＲ
NEJIKURA
ＮＳＲＩ Type
(SR-80 ・ NJ-80 ・ NJ-80F)
Operation Manual
Operation Manual
Read these instructions for the proper use of this machine.
・ Read these instructions for the proper use of this machine.
After having read these instructions, keep them in a convenient place so you
・ After having read these instructions, keep them in a convenient
or the operator can refer to them whenever necessary.
place so you or the operator can refer to them whenever necessary.
ATTENTION : www.ohtake-root.co.jp is the only web site associated with our company.
We do not have any branches in China.
www.ohtake-root.co.jp
www.ohtake-root.co.jp
Automatic Screw Hopper
Floor Type
HP
自動ネジ補給機
ONF1MA01
NSIR MAE01
c
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for OHTAKE Nejikura SR-80
Summary of Contents for OHTAKE Nejikura SR-80
- Page 1 ATTENTION : www.ohtake-root.co.jp is the only web site associated with our company. We do not have any branches in China.
-
Page 2: Table Of Contents
Contents 1. OVERVIEW OF THIS MACHINE -------------------- 1 6. TROUBLESHOOTING---------------------------------- 9 2. BEFORE USE -------------------------------------------- 1 7. SPECIFICATIONS ------------------------------------- 11 Input：AC１００V ５０/６０Hz 3. OPERATING PRECAUTIONS ----------------------- 2 8. EXTERNAL DIMENSIONS -------------------------- 12 Output：DC12V 500mA 4. NAMES OF MACHINE PARTS ---------------------- 5 9. WARRANTY -------------------------------------------- 15 （linear type）... -
Page 3: Operating Precautions
３．OPERATING PRECAUTIONS This manual contains safety alert symbols and signal words to help prevent injuries to the user or damage to property. ◎ Indications This indicates there is a chance of death, serious injury or fire if the instructions WARNING are not followed. - Page 4 WARNING Never touch the rotating drum while the power is on. Never reach into the inlet and outlet. It may lead to injury or serious accident. Do not remove the upper fixing cover. If the screw falls onto the rotating drum, the "screw" locks and breaks. Do not disassemble the AC adapter as there is a risk of electric shock, fire or malfunction.
- Page 5 CAUTION Properly adjust the amount of screws replenished from the machine to the automatic screw feeder. If the replenishment is excessive, the automatic screw feeder may stop. Refer to 5-1 for adjustment. Adjustment of screw sensor and 5-2. Adjustment of rotating drum operation time. Use only the AC adpater supplied with this machine otherwise it may result in a fire or electric shock.
-
Page 6: Names Of Machine Parts
4. NAMES OF MACHINE PARTS DC input jack Screw storage cover Rotor Upper cover Screw gate adjusting plate ねじ蔵 NJI KURA SR‑80 Proecision Screw Hopper Remaining screw sensor ② ③ ④ ① Power Auto/Manual Manual Screw Lamp Sensor Time HIGHT ⑤ ⑥ Height adjuster (only for SR-80, NJ-80 / NJ-80F is a rubber foot) (This illustration above is for SR-80 . - Page 7 Switch Function ① Power：Power source switch (red LED turns on) ② Auto：A changeover switch for the automatic and manual modes (green LED turns on when it is in the automatic mode and off in manual mode.) ③ Manual：A switch to supply the screws with the manual mode. When it is in the manual mode, press the blue switch to supply the screws to Automatic Screw Feeder.
-
Page 8: How To Use And Adjust
5. HOW TO USE ADJUST 1. Adjusting screw sensor. Scooper To keep an appropriate amount of screws in Automatic Screw Feeder, ad- just the screw sensor. (See illustration 2.) ねじ蔵 NJI KURA SR‑80 How to adjust Proecision Screw Hopper 1) Empty all the screw in Automatic Screw Feeder and turn on power switch. 2) Turn on Auto/Manual Changeover Switch of Nejikura and identify that the green lamp turned on. - Page 9 3. Minor adjustment 1) After the adjustments of screw sensor and rotating time specified in paragraphs 1 and 2, fill Nejikura with the screws. 2) Operate the unit and check how it works. Adjust the screw sensor and timer if it is necessary.
-
Page 10: Troubleshooting
6. TROUBLESHOOTING Please check the following items, if problems occurred during operation. If the problem is still not resolved, please consult your dealer. Before you conduct the corrective action, be sure to turn off power source switch. CAUTION SYMPTOM CAUSE CORRECTIVE ACTION ・Please confirm that AC100-240V is supplied The switch lamp does not light... - Page 11 SYMPTOM CAUSE CORRECTIVE ACTION ・Turn on the Auto switch (LED lamp lights). ・Auto switch is off (LED lamp is The machine does not supply off) screws even if the number of ・Clean the sensor. ・The screw detection sensor is screws in the automatic screw dirty.
-
Page 12: Specifications
7. SPECIFICATIONS Power Nejikura Type Corresponding Automatic Screw Feeder Input：AC１００～２４０V ５０/６０Hz AC adapter SR-80 NSB/NSR/NSBI/NSRI Series Output：DC１５V １A （Switching type） NJ-80 NJ/NJR Series NJ-80,NJ-80F: 142（W）×191（D）×188（H） （mm） Dimensions SR-80: 142（W）×191（D）×189～198（H） （mm） NJ-80F FM-36/FME-36 Series Weight Approx. ２．９Kg Operation Manual 1 copy Note) AC Adapter 1 unit Screw retaining cover 1 unit ●... -
Page 13: External Dimensions
8. EXTERNAL DIMENSIONS NJ-80 with NJR Unit：mm - 12 -... - Page 14 SR-80 with NSR Unit：mm - 13 -...
- Page 15 NJ-80F with FM-36 Unit：mm - 14 -...
-
Page 16: Warranty
9. WARRANTY For users within Japan, the effective term of warranty is 6 months after delivery. Such warranty will not be applicable to purchases or users outside of Japan. If any troubles should occur, please contact your dealer. After the warranty period, repair services will be provided. In the following cases, the customer shall be responsible for parts and labor regardless of the terms of warranty: ... -
Page 17: How To Setup With Fm-36
10. HOW TO SETUP NEJIKURA(NJ-80F) WITH FM-36 Note) SR-80 & NJ-80 doesn’t need the stand. FM-36 screw holes - M2.6 3 screws- NJ-80F Accessory - Screws to fix the stand - Put Nejikura on the stand. NJ-80F Accessory - Stand - Fix the stand to FM-36 with three screws. - Page 18 Fax +81-191-24-3145 Fax +81-191-24-3145 「Quicher」 「OHTAKE」 「OHTAKE ・ ROOT KOGYO」 are trademarks or/and registered trademarks of OHTAKE ・ ROOT KOGYO CO.LTD.] 「Quicher( クイッチャー）」 「OHTAKE」 「OHTAKE ・ ROOT KOGYO」 は、 株式会社 大武 ・ ルート工業の商標又は登録商標です。 The specifications and/or design may be altered, without notice, whenever there are changes or improvements.
