The Nauti Step Dock Ladder requires a three step
installation process.
Step 1 Mounting the base/housing to the dock using
the "The Mounting Template" instructions.
Step 2 Assembling the Nauti Steps Ladder.
Step 3 Securing the Nauti Steps Ladder to the base/housing
Nauti Steps Models
Spring Assisted Dock Ladder
# of Steps
4
5
Nauti Steps Mounting Template
6
7
Step 1 Mounting Base/Housing
8
* From the dock surface to the bottom of the last step.
Due to the variation in dock styles and materials, it is
strongly recommended that a dock installer or
professional installs the Nauti Steps.
Additionally, due to the weight and structural tension
applied to the ladder base, additional support must be
installed for safe and secure mounting.
ATTENTION
To ensure proper installation and stability, Tie Down
recommends using mounting kit #43132. The Nauti Steps
Mounting Kit includes two long brackets and four short
brackets. The brackets can be adapted for aluminum or
wood docks. Installation requires 3/8" hardware; however,
due to variations in dock styles, "under dock" mounting
hardware is not included.
Failure to follow all warnings and instructions may result in product
failure, property damage, serious bodily injury, and/or death.
WARNING: This product can expose you to chemicals including Nickel, which is known to the
State of California to cause cancer. For more information go to: www.P65Warnings.ca.gov
Fig. 1
Depth/Hight*
Part ID:
34"
#43124
43"
#43125
52"
#43126
61"
#43127
70"
#43128
25.75"
This template must be printed on 11" x 17" paper at 100% scale with
Double-check your printer settings to ensure no re-sizing occurs d
Note: Verify the dimensions for accuracy before using this t
Maximum Weight Capacity 300 lbs.
14.0"
Instruction #08472 (A2069 - Rev. 2/20/2025)
404-344-0000 • www.tiedown.com
605 Stonehill Drive SW, Atlanta, GA 30336
sales@tiedown.com
4.25"
Online
Nauti Steps
A2069
A2069
Assembly Instructions
Online
A2072
Nauti Steps
A2072
Mounting Template
and Base Installation
A2076-4
A2076-4
Nauti Steps
Nauti St
Nauti S
h ps://
h ps://
Nauti St
Nauti S
h ps://
h ps://
h ps://
h ps://
Nauti Steps
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for TIE DOWN NautiSteps
Summary of Contents for TIE DOWN NautiSteps
- Page 1 Additionally, due to the weight and structural tension applied to the ladder base, additional support must be installed for safe and secure mounting. ATTENTION Online To ensure proper installation and stability, Tie Down Nauti Steps Nauti St A2069 Nauti S A2069 recommends using mounting kit #43132.
- Page 2 8 - Step Model #43128 A2076-8 Parts Diagram Parts Diagram h ps://www.tiedown.com/pdf/a2076-5.pdf h ps://www.tiedown.com/pdf/a2076-6.pdf h ps://www.tiedown.com/pdf/a2076-8.pdf h ps://www.tiedown.c h ps://www.tiedown.com/pdf/a2076-7.pdf A2076-6 h ps://www.tiedown.com/pdf/a TIE DOWN Marine Products Division A2076-6 A2069 Rev. 3/21/25 800-241-1806 • 404-344-0000 • www.tiedown.com A2076-7 A2076-6 h ps://www.tiedown.com/pdf/a A2076-8 A2076-8...
- Page 3 Nuts/Washers Outside 1/2” Washers Hex Nuts 1/4” Nylock Nuts Right Frame - 5/16” Nylock Nuts/Washers Outside 1st Step Hex Nuts TIE DOWN Marine Products Division 800-241-1806 • 404-344-0000 • www.tiedown.com A2069, Rev. 3/21/25...
- Page 4 1/2” Washers Lower Left Frame 1/4” Nylock Nuts Left Frame Left Frame 1/2” Washers Fig. 4-3 1/4” Nylock Nuts 1st Step 1st Step Right Frame TIE DOWN Marine Products Division A2069 Rev. 3/21/25 800-241-1806 • 404-344-0000 • www.tiedown.com Left Frame...
- Page 5 Full tightening will occur during the final assembly. 1/2” Washers Right Frame 1/2” Washers 1/4” Nylock Nuts Left Frame 1/2” Washers 1/4” Nylock Nuts 1st Step 1st Step Fig. 5-2 TIE DOWN Marine Products Division 800-241-1806 • 404-344-0000 • www.tiedown.com A2069, Rev. 3/21/25...
- Page 6 • Follow the simple illustration is shown right in Fig. 6-3. • Do not fully tighten the step screws at this stage, final tightening will occur during the final assembly process. Fig. 6-3 TIE DOWN Marine Products Division A2069 Rev. 3/21/25 800-241-1806 • 404-344-0000 • www.tiedown.com...
- Page 7 ATTENTION Nauti Step Dock Ladder Final Assembly Step 3 To ensure proper installation and stability, Tie Down NOTE: Before any further assembly takes place, recommends using mounting kit #43132. The Nauti Steps the base/housing must be fully secured to the dock.
- Page 8 3/8” Washers & Nylock Nuts 3/8” Washers & Nylock Nuts 3/8” x 3” Carriage Bolts 3/8” x 3” Carriage Bolts 3/8” x 3” Carriage Bolts Fig. 8-3 Fig. 8-4 TIE DOWN Marine Products Division A2069 Rev. 3/21/25 800-241-1806 • 404-344-0000 • www.tiedown.com...
- Page 9 • Slide the safety pin completely through until it passes out the opposite side of the housing Dock E Fig. 9-2 to ensure a secure lock. Dock Edge TIE DOWN Marine Products Division 800-241-1806 • 404-344-0000 • www.tiedown.com A2069, Rev. 3/21/25...
- Page 10 2.25” 1.5” .425” 3.25” 2.5” .425” 2.75” 1.375” Nauti Steps .25” Short Bracket 2.25” Part ID: 43133-1 4.5” Dock Surface/Ladder Side Under Dock Mounting Example Ladder Side TIE DOWN Marine Products Division A2069 Rev. 3/21/25 800-241-1806 • 404-344-0000 • www.tiedown.com...
- Page 11 (2 brackets included) 14.0” 12.5” 5.0” 2.25” .42” 5.0” Nauti Steps 5.0” Long Bracket Part ID: 47886 .25” Dock Surface/Ladder Side Under Dock Mounting Example Ladder Side TIE DOWN Marine Products Division 800-241-1806 • 404-344-0000 • www.tiedown.com A2069, Rev. 3/21/25...
-
