TIE DOWN TranzVolt G2 Safety And Operating Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
TranzVolt G2
Safety & Operating Manual
TranzVolt G2 with
Collapsible Roofing
Platform
NOTE: Two (2) DeWalt Brand 20V batteries or Two (2) Milwaukee Brand 18V batteries
are required depending on your model TranzVolt. Batteries not included.
WARNING: This product can expose you to chemicals including Nickel, which is known to the
State of California to cause cancer. For more information go to: www.P65Warnings.ca.gov
WARNING: This product can expose you to chemicals including Nickel, which is known to the
State of California to cause cancer. For more information go to: www.P65Warnings.ca.gov
WARNING: This product can expose you to
chemicals including Nickel, which is known to
CRITICAL SAFETY INFORMATION: The greatest exposure to serious bodily injury and or death may occur when the
the State of California to cause cancer. For more
information go to: www.P65Warnings.ca.gov
TranzVolt track sections are located within 10 ft. (left or right or underneath) overhead electric power lines. If a minimum
safe distance (10 ft.) from electrical wires cannot be maintained, contact the local utility company and have the electric
WARNING: This product can expose you
wire unenergized and grounded or guarded effectively by insulating or other means.
to chemicals including Nickel, which is
known to the State of California to
cause cancer. For more information
A COMPETENT PERSON must be present during any setup, during any repositioning, and during any tear-down
go to: www.P65Warnings.ca.gov
operations of the TranzVolt track sections when the TranzVolt is to be located near electric power lines. A COMPETENT
PERSON must read and understand the Owner's Manual for setup, operating instructions, and tear down instructions in
WARNING: This product can expose you
order to ensure that all personnel authorized to set up, operate, and tear-down the TranzVolt are made aware of ALL
to chemicals including Nickel, which is
SAFETY WARNINGS as well as the operating instructions. ALWAYS USE APPROVED ROOF TOP FALL PROTECTION when
known to the State of California to
setting up, operating, and taking down the TranzVolt.
cause cancer. For more information
go to: www.P65Warnings.ca.gov
US Patent Pending
TranzVolt G2 with
Solar Tilt Back
Platform
404-344-0000 • www.tiedown.com
605 Stonehill Drive SW, Atlanta, GA 30336
sales@tiedown.com
TranzVolt G2
Operations
Manual
Solar Tilt Back
Platform Assembly
Instructions
Collapsible Roofing
Platform Instructions
Instruction #08427 (E1930, Rev. 10/28/22)
https://www.tiedow
tranzvolt_g2_asse
https://www.tiedow
tranzvolt_g2_asse
https://www.tiedo
tranzvolt_solar_in
https://www.tiedow
tranzvolt_g2_asse
https://www.tiedow
tranzvolt_solar_in
https://www.tiedo
tranzvolt_roofing
https://www.tiedow
tranzvolt_solar_in
https://www.tiedow
tranzvolt_roofing p
https://www.tiedow
tranzvolt_roofing

Advertisement

loading
Need help?

Need help?

Do you have a question about the TranzVolt G2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TIE DOWN TranzVolt G2

Summary of Contents for TIE DOWN TranzVolt G2

  • Page 1 US Patent Pending TranzVolt G2 Safety & Operating Manual https://www.tiedow tranzvolt_g2_asse TranzVolt G2 https://www.tiedow tranzvolt_g2_asse Operations https://www.tiedo Manual tranzvolt_solar_in TranzVolt G2 with Collapsible Roofing Platform https://www.tiedow tranzvolt_g2_asse https://www.tiedow tranzvolt_solar_in https://www.tiedo tranzvolt_roofing TranzVolt G2 with Solar Tilt Back https://www.tiedow Solar Tilt Back...

  • Page 2: Table Of Contents

    605 Stonehill Drive SW, Atlanta, Georgia 30336 800-241-1806 • 404-344-0000 • www.tiedown.com ISO 9001:2015 Certification Intellectual property of TIE DOWN Inc. ©2019 TIE DOWN, Inc. Instruction #08315 (E1546 Rev. 10/28/22) TIE DOWN Safety Products Division • 800-241-1806 • 404-344-0000 • www.tiedown.com E1930, 10/28/22...
  • Page 3 Part ID: 40676 Kit Includes: Top cap and platform base Kit Includes: Tilt back platform & mounting hardware Contact Tie Down @ 404-344-000 if missing any product. TIE DOWN Safety Products Division • 800-241-1806 • 404-344-0000 • www.tiedown.com E1930, 10/28/22...

  • Page 4: Tranzvolt G2 Safety Warning

    Your attention helps avoid dangers and the ensures reliability and lifetime of the TranzVolt G2 Hoist. Installation Instructions Disclaimer The TranzVolt G2 instructions must always be available, read and applied to any person who installs/operates the TranzVolt G2 while: • Operating the Equipment.
  • Page 5 • Tighten both flange nuts. • Repeat for opposite side roller bracket NOTE: Under normal working conditions’ parts will wear out. TIE DOWN sells replacement parts in kits only and will not sell U-Bolt individual pieces or parts. Most common hardware described is available at your local hardware store.
  • Page 6 • Place a 3/4” platform bolt from the inside of the ladder through the roller bracket. Fig. 6-3 Fig. 6-4 • Tighten with 3/8” keeper nut. • Repeat of opposite side roller bracket. Fig. 6-5 TIE DOWN Safety Products Division • 800-241-1806 • 404-344-0000 • www.tiedown.com E1930, 10/28/22...

  • Page 7: Splice Plates

    2nd to the end rung on the track section. The TranzVolt laddervator track assembly is now ready to be lifted into its work location. Fig. 7-3 TIE DOWN Safety Products Division • 800-241-1806 • 404-344-0000 • www.tiedown.com E1930, 10/28/22...
  • Page 8 2x4 on the side of the roof top. NEVER ALLOW ANYTHING TO WRAP AROUND THE FRONT OF NEVER ALLOW ANYTHING TO WRAP THE TRACK SECTION AROUND THE FRONT OF THE TRACK SECTION TIE DOWN Safety Products Division • 800-241-1806 • 404-344-0000 • www.tiedown.com E1930, 10/28/22...
  • Page 9 2x4 on the side of the roof top. NEVER ALLOW ANYTHING TO WRAP AROUND THE FRONT OF NEVER ALLOW ANYTHING TO THE TRACK SECTION WRAP AROUND THE FRONT OF THE TRACK SECTION TIE DOWN Safety Products Division • 800-241-1806 • 404-344-0000 • www.tiedown.com E1930, 10/28/22...
  • Page 10 9’-0” 19th and 21st Extension Required* 40’ 44’ 10’-0” 24th and 25th Extension Required* 42’ 44’(max) 10’-6” 25th and 27th Extension Required* Support Brace Assembly Instructions https://www.tiedown.com/pdf/e134.pdf TIE DOWN Safety Products Division • 800-241-1806 • 404-344-0000 • www.tiedown.com E1930, 10/28/22...
  • Page 11 • If the power box if properly aligned with the track sides it should roll freely up and down the assembled tracks. • Lower the power box down resting against the stop rollers. Fig. 11-2 Fig. 11-4 Fig. 11-3 TIE DOWN Safety Products Division • 800-241-1806 • 404-344-0000 • www.tiedown.com E1930, 10/28/22...

  • Page 12: Platform Frame Installation

    • If the platform frame is properly aligned with the track sides, the platform frame will freely roll up and down the assembled tracks. Fig. 12-2 Fig. 12-3 TIE DOWN Safety Products Division • 800-241-1806 • 404-344-0000 • www.tiedown.com E1930, 10/28/22...
  • Page 13 • Locate the 4 - quick release pins from the hardware supplied. • Insert a release pin in each of the four mounting hole located on each corner of the top of the carriage frame. See Fig. 13-4. TIE DOWN Safety Products Division • 800-241-1806 • 404-344-0000 • www.tiedown.com E1930, 10/28/22...

  • Page 14: Synthetic Cable Installation

    TranzVolt (located on the right side of the spool) is visible and Front Cable Spool positioned towards to top of the power box. Fig. 14-3 Fig. 14-3 TIE DOWN Safety Products Division • 800-241-1806 • 404-344-0000 • www.tiedown.com E1930, 10/28/22...
  • Page 15 • Repeat the up and down process for a second time. at least 2 times The synthetic cable should be fully wound and ready to load the platform. Fig. 15-3 TIE DOWN Safety Products Division • 800-241-1806 • 404-344-0000 • www.tiedown.com E1930, 10/28/22...
  • Page 16 Platform Instructions Release Rear Release Pin https://www.tiedown.com/pdf/ tranzvolt_g2_assembly_e1930.pdf https://www.tiedown.com/pdf/ tranzvolt_solar_inst_e1939.pdf Side Arm Solar Tilt Back Rear Platform Assembly Release Instructions https://www.tiedown.com/pdf/ Side Arm tranzvolt_roofing platform_inst_e1938.pdf Panel Rest TIE DOWN Safety Products Division • 800-241-1806 • 404-344-0000 • www.tiedown.com E1930, 10/28/22...
  • Page 17 The unit will begin to climb the track Lower Home Position very slowly until it bumps the top cap or the HOME bu on is Track Stop Brackets pressed again. TIE DOWN Safety Products Division • 800-241-1806 • 404-344-0000 • www.tiedown.com E1930, 10/28/22...

  • Page 18: Safety Warnings

    MUST BE REMOVED BEFORE TRANSPORTING. WARNING BATTERIES MUST BE REMOVED WHEN NOT IN USE. Leaving the batteries in the TranzVolt power box could result in permanently dead batteries. TIE DOWN Safety Products Division • 800-241-1806 • 404-344-0000 • www.tiedown.com E1930, 10/28/22...
  • Page 19 TRANZVOLT G2 LADDERVATOR PRODUCT LINE LIMITED WARRANTY Tie Down will repair or replace, free of charge, any part, or parts of the TranzVolt G2 Laddervator that are defective in material or workmanship or both. The limited warranty is in effect for two (2) years for the TranzVolt G2 electrical power box and six (6) months for all other TranzVolt G2 equipment.

  • Page 20: 605 Stonehill Drive Sw, Atlanta, Georgia 30336

    Safety Products Division 605 Stonehill Drive SW, Atlanta, Georgia 30336 800-241-1806 • 404-344-0000 • www.tiedown.com ISO 9001:2015 Certification Intellectual property of TIE DOWN Inc. ©2022 TIE DOWN, Inc. Instruction #08427 (E1930 Rev. 10/28/22)
