Parapet Ladder
Safety-Dock
Instruction Manual
2-Piece Commercial Ladder Safety-Dock
3-Piece Parapet Ladder Safety-Dock
Keep these instructions for future reference.
Read and understand these instructions
before using this product.
The Parapet Ladder Safety-Dock is OSHA Compliant and can
be installed on both parapet and flat roofs. If installing on flat
roofs, see installation for Commercial Ladder Safety-Dock.
Scan QR code for flat roof installation.

Tools Required

Drill
14" drill bit for metal or masonry
Socket bits
Wrench set
Reciprocating saw and metal blade
2 - Piece Commercial Ladder Safety-Dock
Part ID: 71069 - Box Contents:
Parapet Ladder Safety-Dock with chains
"L" bracket and 2 carriage bolts, washers & nuts
Safety-Handles and mounting hardware
3 - 17" threaded rods with 6 nuts & washers and
3 fender washers, Brace and fasteners
3 - Piece Parapet Ladder
Part ID-71070 - Box 1 & 2 Contents:
Parapet Ladder Safety-Dock with chains
"L" bracket and 2 carriage bolts
Safety-Handles and mounting hardware
3 - 17" threaded rods with 6 nuts & washers
and 3 fender washers, Brace and fasteners
Parapet Safety-Ladder and 4 mounting bolts & nuts
2 Ladder feet and 2 self-tapping screws
NOTE:
The 2-Piece Ladder Safety-Dock is designed for a 6" to
13" wide parapet. By flipping the "L" Bracket, it can work
on up to a 15" wide parapet. However, the 3-Piece Lad-
der Safety-Dock (with ladder) only works on parapets 6"
to 13" wide. Please call office for additional information.
Part ID: 71069
Part ID: 71070
Box 1
2-Piece Commercial
Ladder Safety-Dock
404-344-0000 • www.tiedown.com
605 Stonehill Drive SW, Atlanta, GA 30336
Extension
Ladder
WARNING: This product can expose you to chemicals including Nickel, which is known to the
State of California to cause cancer. For more information go to: www.P65Warnings.ca.gov
WARNING: This product can expose you to chemicals including Nickel, which is known t
State of California to cause cancer. For more information go to: www.P65Warnings.ca.go
WARNING: This product can expose you to
chemicals including Nickel, which is known to
the State of California to cause cancer. For more
information go to: www.P65Warnings.ca.gov
WARNING: This product can expose you
to chemicals including Nickel, which is
known to the State of California to
cause cancer. For more information
go to: www.P65Warnings.ca.gov
sales@tiedown.com
WARNING: This product can expose you
to chemicals including Nickel, which is
known to the State of California to
cause cancer. For more information
Parapet Ladder
Safety-Dock
Parapet
Wall
Roof
Surface
Box 2
3-Piece Parapet Ladder
Safety-Dock.
Instruction Sheet #08378
E1837, Rev. 5/25/21
