Felix printers FELIX Pro 3 Installation Manual

Hide thumbs Also See for FELIX Pro 3:

Advertisement

Quick Links

Download this manual
All manuals and user guides at all-guides.com
Touchscreen installation
FELIX Pro 3
www.FELIXprinters.com/support
support@felixprinters.com
Zeemanlaan 15
3401MV IJsselstein
The Netherlands

Advertisement

loading
Need help?

Need help?

Do you have a question about the FELIX Pro 3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Felix printers FELIX Pro 3

Summary of Contents for Felix printers FELIX Pro 3

  • Page 1 All manuals and user guides at all-guides.com Touchscreen installation FELIX Pro 3 www.FELIXprinters.com/support support@felixprinters.com Zeemanlaan 15 3401MV IJsselstein The Netherlands...

  • Page 2: Table Of Contents

    All manuals and user guides at all-guides.com Introduction Thank you for choosing FELIXprinters! Kind regards, FELIXprinters 1 Contents CONTENTS ............1 ......7 OUCHSCREEN INSTALLATION INSTALLATION OF THE TOUCHSCREEN ....2 FIRMWARE UPDATE ..........10 ............2 ..........16 EBCAM ALIBRATION Touchscreen installation FELIX Pro...

  • Page 3: Installation Of The Touchscreen

    All manuals and user guides at all-guides.com 2 Installation of the touchscreen Webcam Follow these steps to install your new touchscreen, first remove the top cover of the machine. This installation guide also goes over the webcam, if you don’t have that you can skip to 2.2. Touchscreen installation FELIX Pro Page...
  • Page 4 All manuals and user guides at all-guides.com First place the webcam cable through the slot. Plug the cable into the webcam. Touchscreen installation FELIX Pro Page...
  • Page 5 All manuals and user guides at all-guides.com Put in the cable guide. Screw the T-slot into the frame and tighten it to secure the webcam. Touchscreen installation FELIX Pro Page...
  • Page 6 All manuals and user guides at all-guides.com Move the head to the left to make sure it doesn’t hit the webcam. Touchscreen installation FELIX Pro Page...
  • Page 7 All manuals and user guides at all-guides.com Tie wrap the cable as shown, then cut of the remaining part of the tie wrap. Touchscreen installation FELIX Pro Page...

  • Page 8: Touchscreen Installation

    All manuals and user guides at all-guides.com Touchscreen installation Remove this cable it’s not used anymore. Place the same USB to LCD cable in this port. Touchscreen installation FELIX Pro Page...
  • Page 9 All manuals and user guides at all-guides.com Place the top cover on the machine and guide the cables through. Place the cables into the screen as shown. Touchscreen installation FELIX Pro Page...
  • Page 10 All manuals and user guides at all-guides.com Now slide the screen in be careful not to pinch the cables. After this step you’re done and can turn on the machine, but remember to install the touchscreen firmware for the machine see how to below. Touchscreen installation FELIX Pro Page...

  • Page 11: Firmware Update

    All manuals and user guides at all-guides.com 3 Firmware update Navigate to the firmware upload button in the drop down menu. Touchscreen installation FELIX Pro Page...
  • Page 12 All manuals and user guides at all-guides.com Make sure it’s set to Arduino DUE programming port. Touchscreen installation FELIX Pro Page...
  • Page 13 All manuals and user guides at all-guides.com Select the .bin file for your machine you can download them from our site. Touchscreen installation FELIX Pro Page...
  • Page 14 All manuals and user guides at all-guides.com The machine will now begin it’s update routine this will take a couple of minutes the controller will disconnect during the process and will reconnect when it is done. When this is done we need to clear the old settings, see instructions below. Navigate to the console tab Touchscreen installation FELIX Pro Page...
  • Page 15 All manuals and user guides at all-guides.com Send the gcode M502 this will reset the internal memory of the machine. Touchscreen installation FELIX Pro Page...
  • Page 16 All manuals and user guides at all-guides.com Send the gcode M500 this will save the reset. After this we will need to calibrate the machine again, we will start with the bed leveling. Touchscreen installation FELIX Pro Page...

  • Page 17: Calibration

    All manuals and user guides at all-guides.com Calibration. Do the printer calibrations in order bed leveling > z calibration > XY calibration. Bed leveling: This tilts the bed in the software so the distance between nozzle and bed is the same everywhere. When to do this?: Touchscreen installation FELIX Pro Page...
  • Page 18 All manuals and user guides at all-guides.com After unboxing/moving printer. When you see first layer printed lines are deviating from width across the print surface. We already leveled the bed in the previous step so you don’t need to do this, we do need to calibrate the Z and the XY. XY and Z Nozzle calibration: These calibrations align the printheads with respect to each other to get an optimal dual head print.
  • Page 19 Help us to improve our products and services. It only takes a few minutes! www.felixprinters.com/survey (a small reward is waiting for you) Manuals & tutorials FELIX Community www.felixprinters.com/support www.felixprinters.com/community V2 - 2019 Quick Start Manual FELIX Pro 3 www.felixprinters.com/support Zeemanlaan 15 support@felixprinters.com 3401MV IJsselstein Touchscreen installation FELIX Pro The Netherlands Page...
