Summary of Contents for CAMPARK T200

  • Page 1 此页不印刷(本文件共24页) SIZE:90mm X 120mm 材质: 封面铜版纸 内页: 书纸 工艺: 封面过亚膜 PANTONE Black C 注意:不要随便删减空白页(特别是封面内页不能出现印刷内容)...
  • Page 2 T200 Trail Camera Instruction Manual...
  • Page 5 V20201102...
  • Page 6: Packing List

    (PIR, passive infrared sensor) switch on the camera, activating picture of video mode. 2.1 Features Of Wildlife Camera 1. CMOS sensor. 2. 30 Megapixels photo and 4K UHD video. 3. 6.1 cm (2.4’’) color TFT LCD: 320x240 pixels 4. 38 pcs IR LEDs. support@campark.net...
  • Page 7 3. Motion triggered security camera for domestic, office or public use. 4. Any internal and external surveillance. 3. STRUCTURE Understanding the camera structure helps to use this product more skillfully. 1.Side Indicator 2.IR LEDs 3.Lens 4.PIR Sensors 5.Solar energy 6.System Indicator 7.Main Indicator support@campark.net...
  • Page 8 1.Screen 9.OK 2.Power Switch 10.Battery Case 3.MENU 11.DC Power Input 4.Battery Ejection 12.Mount Screw 5.UP 13.Micphone 6.Down 14.Mini USB 7.Left 15.Locking hole for lock 8.Right support@campark.net...
  • Page 9 3. Using the mini USB connection (USB 2.0), the camera can be connected to a computer to download photos and videos. 4. Using the mode switch, the three operating modes:OFF,SETUP and ON can be selected. support@campark.net...
  • Page 10: Preparing The Camera

    5. Switch on the camera. 3 switches: power off (OFF) ,setup menu /SETUP mode (SETUP)and live mode (ON). 6. New memory card is recommended to be formatted when using (as below described). 7. Please note that the camera will power off when power is very low. support@campark.net...
  • Page 11: Assembly With Strap

    How to start: Push the release button to eject the battery case Load 8 new alkaline batteries Install the battery case Insert the SD card Switch to Setup SETUP Assembly With Strap support@campark.net...
  • Page 12: Using The Camera

    In Setup menu, short press to confirm selection and changes. In Playback mode,play video. In Playback mode, Scroll through the recorded files. In Setup menu, Scroll through the setup menu and Down adjust values. Battery Ejection Push to eject the battery case. support@campark.net...
  • Page 13 The camera will respond to the PIR sensors only. It will turn on and take photo or record videos when the PIR sensor is triggered, then return to standby afterwards. support@campark.net...
  • Page 14: Setup Menu

    MP4 format which can be played back on most video devices. Video Length Default 5 seconds, optional 5s-180s, Specify the duration of a video recording when the camera is triggered automatically. The recording period for videos is not limited in the SETUP mode. support@campark.net...
  • Page 15 It would affect the usage days of the batteries. On the opposite, if the shot lag is long, it would be a lower consumption of power to guarantee a long-time usage. support@campark.net...
  • Page 16 6:35 pm of the current day until 8:25 am of the following day. The camera will not be triggered and will not take any photos or videos outside of this period. Record Audio Turn on/off audio recording Side PIR Setup ON/OFF support@campark.net...
  • Page 17 Turn on/off button operation beep sound. Language Select the menu language. English / French / Spanish / Portuguese / German / Italian / Chinese available. Password Setting Setup a startup password to protect the camera. ON/OFF,default ON WIFI SSID WIFI name,default Campark-T200 support@campark.net...
  • Page 18 Format Format the memory card. Default Setting Cancel /OK Press OK to reset the camera settings to the default values. Version Check firmware version. MCU FW Update Firmware Update. support@campark.net...
  • Page 19 Beforeusingthewififunction,pleaeinstalltheAPPapplicationonthe smartphonedevice.PleasedownloadandinstalltheappfromGooglePlayor APPstorebysearching""HuntingCamera4K"APPforAndroidsystemand IOSsystem. Android support@campark.net...
  • Page 20 support@campark.net...
  • Page 21 support@campark.net...
  • Page 22 T200 support@campark.net...
  • Page 23 T200 T200 T200 support@campark.net...
  • Page 24 2020/09/05 10:10:16 280 82F CamPark-T200 support@campark.net...
  • Page 25 7.4.3APPconnection 2020/09/05 10:10:16 280 82F CamPark-T200 Display the resolution of the photo or video 4K P30 support@campark.net...
  • Page 26 3.Clicktheicon toenterthemenusetting,asshownbelowdiagram. Setting Mode Photo> ImageSize 5M> Sampling(validin'ON'mode) 1Photo> Resolution 4KP30> RecordTime(validin'ON'mode) 00:10> PIRInterval 00:30> PIRSensitivity Med> IRLED Auto> TimeLapse 0ff> TimingInterval support@campark.net...
  • Page 27 For this purpose, attach the camera at approx. 1m-2m height to a tree and align the camera to the desired direction. At 1 meter height above the ground, place the camera parallel to the ground. At 2 meters height above the ground, Tilt the camera down five degrees to the ground. support@campark.net...
  • Page 28 7.Enter ON / Live Mode The standard application of the T200 Camera is the ON / Live mode. In this mode , photos are either triggered by movement sensors or at intervals according to the respective setting. To set up the ON / Live mode , switch power switch to ON position. The...
  • Page 29: Technical Specification

    8.TECHNICAL SPECIFICATION Model T200 Image Sensor 30 MP CMOS sensor 30MP/24MP/20MP/16MP/12MP/8MP Photo Resolution /5MP/3MP Screen 2.4 inch LCD Screen Storage SD Card up to 128GB (NOT included) 4k P30/2K P30/1296 P30/1080 P30/ Video Resolution 720 P30/720 P30/480 P30/360 P30 Night Vision Range...
  • Page 30: Simple Troubleshooting

    LEDs and lens before using. 1 . Check If the memory of SD card is The camera does not take full, transfer images or videos to images or record videos your computer or delete some files in the Replay Mode. support@campark.net...
  • Page 31 Always remove the battery from the housing if the camera is not being used for some time and store the battery separately. On a day to day basis and over longer periods the batteries can be kept at a dry location out of the reach of children. support@campark.net...
  • Page 32 We will offer prompt and authoritative reply within 24 hours, and try our best to resolve your problem ASAP. More Safe Guarantee with CAMPARK! If you are not satisfied with our product. Please tell us about your thought. That will be much appreciated.
