Summary of Contents for CAMPARK T90

  • Page 1 此页不印刷(本文件共36页) SIZE:115mm X 165mm 材质: 封面铜版纸 内页: 书纸 工艺: 封面过亚膜 PANTONE Black C 注意:不要随便删减空白页(特别是封面内页不能出现印刷内容)...
  • Page 2 Trail Camera Instruction Manual...
  • Page 4: Table Of Contents

    CONTENT INSTALLATION STEPS ------------------------------------ 1. PACKING LIST-------------------------------------------- 2. INTRODUCTION----------------------------------------- 2.1. Parameter Of Wildlife Camera---------------------- 2.2. Features Of Wildlife Camera------------------------ 3. STRUCTURE--------------------------------------------- 4. PREPARING THE CAMERA----------------------------- 5. USING THE CAMERA AND SETUP MENU-------------- 5.1 Using The Camera----------------------------------- 5.2 Setup Menu----------------------------------------- 5.3 WIFI APP connection-------------------------------- 5.3.1 Connect the Bluetooth-------------------------- 5.3.2 WIFI connection--------------------------------- 5.3.3 APP connection---------------------------------...
  • Page 5 V20201105...
  • Page 6 Steps: There are two ways to mount the Campark trail camera: using the provided adjustable web belt, or the tripod socket. 1. Using the Adjustable Mounting Belt Push one end of the belt through the brackets on the back of the camera.
  • Page 7 3.Fix the bracket to the chassis with the removed nut. 4.Fix the camera to the bracket. 5.Assembly is complete. They can be made stronger by turning the swivel screws on the bracket. 6.Use wall anchors and screws to fix the camera on the wal (plank, etc.). support@campark.net...
  • Page 8: Packing List

    (PIR, passive infrared sensor) switch on the camera, activating picture of video mode. 2.1 Parameter Of Wildlife Camera 1. CMOS sensor. 2. 24 Megapixels photo and 4K Lite video. 3. 6.1 cm (2.4’’) color TFT LCD: 320x240 pixels 4. 38 pcs IR LEDs. support@campark.net...
  • Page 9: Features Of Wildlife Camera

    3. Motion triggered security camera for domestic, office or public use. 4. Any internal and external surveillance. 3. STRUCTURE Understanding the camera structure helps to use this product more skillfully. 1.Side Indicator 2.IR LEDs 3.Lens 4.PIR Sensors 5.Solar energy 6.System Indicator 7.Main Indicator support@campark.net...
  • Page 10 1.Screen 9.OK 2.Power Switch 10.Battery Case 3.MENU 11.DC Power Input 4.Battery Ejection 12.Mount Screw 5.UP 13.Micphone 6.Down 14.Mini USB 7.Left 15.Locking hole for lock 8.Right support@campark.net...
  • Page 11 3. Using the mini USB connection (USB 2.0), the camera can be connected to a computer to download photos and videos. 4. Using the mode switch, the three operating modes:OFF,SETUP and ON can be selected. support@campark.net...
  • Page 12: Preparing The Camera

    5. Switch on the camera. 3 switches: power off (OFF) ,setup menu /SETUP mode (SETUP)and live mode (ON). 6. New memory card is recommended to be formatted when using (as below described). 7. Please note that the camera will power off when power is very low. support@campark.net...
  • Page 13: How To Start

    How to start: Push the release button to eject the battery case Load 8 new alkaline batteries Install the battery case Insert the SD card Switch to Setup SETUP support@campark.net...
  • Page 14: Using The Camera And Setup Menu

    Short press to adjust when setting multiple digits in Left Key the menu. Short press to adjust when setting multiple digits in the menu. Right Key In Video or Photo mode,short press to enter playback mode. Battery Ejection Push to eject the battery case. support@campark.net...
  • Page 15 The camera will respond to the PIR sensors only. It will turn on and take photo or record videos when the PIR sensor is triggered, then return to standby afterwards. support@campark.net...
  • Page 16: Setup Menu

    AVI format which can be played back on most video devices. Video Length Default 5 seconds, optional 3s-180s, Specify the duration of a video recording when the camera is triggered automatically. The recording period for videos is not limited in the SETUP mode. support@campark.net...
  • Page 17 It would affect the usage days of the batteries. On the opposite, if the shot lag is long, it would be a lower consumption of power to guarantee a long-time usage. support@campark.net...
  • Page 18 6:35 pm of the current day until 8:25 am of the following day. The camera will not be triggered and will not take any photos or videos outside of this period. Audio recording Turn on/off audio recording Side PIR Setup ON/OFF support@campark.net...
  • Page 19 Select the menu language. English / French / Spanish / Portuguese / German / Italian / Chinese available. Password Setting Setup a startup password to protect the camera Only four-digit password. WIFI SSID ON/OFF,default ON WIFI name default Campark-T90 support@campark.net...
  • Page 20 Setup the time so the camera will automatically turn off WiFi when it is not connected to a smart phone within the preset time. Format memory card Format the memory card. Reset settings Cancel /OK Press OK to reset the camera settings to the default values. Version Check firmware version. support@campark.net...
  • Page 21: Wifi App Connection

    Android system and IOS system. Android 5.3.1 Connect the Bluetooth Slide the camera mode switch to the test or ON position, turn on the phone, and tap the app to enter the main interface of the app, as shown in the figure below. support@campark.net...
  • Page 22 5. Tap the corresponding Bluetooth device, the APP will connect with the camera Bluetooth. The phone will pop up the "Connect, please wait..." window. If the camera Bluetooth is successfully matched with the mobile phone's Bluetooth, the device WIFI will be turned on automatically. support@campark.net...
  • Page 23: Wifi Connection

    E. Return back to APP after the WiFi successful connection. And then the APP would automatically connect with camera.or click” Step Two Connect Wifi” to manually connect. WIFI wait for connection SSID:Hunting Cam Password:12345678 WIFI connected SSID:Hunting Cam Password:12345678 support@campark.net...
  • Page 24: App Connection

    Display the resolution of the photo or video. amera battery level display. Switch to video mode. Switch to photo mode. Connect the camera to video mode or taking photo mode under the control of Mobile phone. Mobile phone review pictures or video in the camera. support@campark.net...
  • Page 25 A. Click on the photo file to zoom in and view, and download or delete the file. B. Click on the video file to download , Multi-select video or photo files, then download or delete. 3. Click the icon to enter the menu setting, as shown below diagram. 2.25MB 3.85MB 1.75MB support@campark.net...
  • Page 26: Install The Camera In The Field

    For this purpose, attach the camera at approx. 1m-2m height to a tree and align the camera to the desired direction. At 1 meter height above the ground, place the camera parallel to the ground. At 2 meters height above the ground, Tilt the camera down five degrees to the ground. support@campark.net...
  • Page 27: Enter On / Live Mode

    7.Enter ON / Live Mode The standard application of the T90 Camera is the ON / Live mode. In this mode , photos are either triggered by movement sensors or at intervals according to the respective setting. To set up the ON / Live mode , switch power switch to ON position. The...
  • Page 28: Technical Specification

    IR LEDs 38 * 850nm IR LEDs Detection Angle 120° Media Format AVI / JPG Interface Mini USB Standby Time Approx 6 Months (With 8 new battery) 8 x LR6 1.5V Alkaline battery Power Supply External DC 6V / 2A support@campark.net...
  • Page 29: Simple Trouble Shooting

    LEDs and lens before using. 1 . Check If the memory of SD card is The camera does not take full, transfer images or videos to images or record videos your computer or delete some files in the Replay Mode. support@campark.net...
  • Page 30 If using batteries to power the camera and the camera is not being used for some time, please remove the batteries from the housing and store the battery separately in a dry place and out of the reach of children. support@campark.net...
  • Page 31 We will offer prompt and authoritative reply within 24 hours, and try our best to resolve your problem ASAP. More Safe Guarantee with CAMPARK! If you are not satisfied with our product. Please tell us about your thought. That will be much appreciated.
