- Page 1 Uputstvo za upotrebu (EN) DELL laptop Vostro 3400 (NOT21816) Tehnoteka je online destinacija za upoređivanje cena i karakteristika bele tehnike, potrošačke elektronike i IT uređaja kod trgovinskih lanaca i internet prodavnica u Srbiji. Naša stranica vam omogućava da istražite najnovije informacije, detaljne karakteristike i konkurentne cene proizvoda.
- Page 2 Vostro 3400 Setup and specifications guide Regulatory Model: P132G Regulatory Type: P132G003 / P132G004 August 2021 Rev. A03...
- Page 3 A WARNING indicates a potential for property damage, personal injury, or death. © 2020-2021 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other trademarks may be trademarks of their respective owners.
- Page 4 A WARNING indicates a potential for property damage, personal injury, or death. © 2020-2021 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other trademarks may be trademarks of their respective owners.
-
Page 5: Table Of Contents
Contents Chapter 1: Set up your computer....................6 Chapter 2: Create a USB recovery drive for Windows..............8 Chapter 3: Chassis overview......................9 Display view..................................9 Left view....................................10 Right view.................................... 10 Palmrest view..................................11 Bottom view..................................12 Keyboard shortcuts................................12 Chapter 4: Technical specifications..................... - Page 6 Updating the BIOS from the F12 One-Time boot menu..................37 Updating the BIOS in Windows ............................ 38 Updating BIOS on systems with BitLocker enabled....................38 Updating the Dell BIOS in Linux and Ubuntu environments................39 System and setup password............................39 Assigning a system setup password........................39 Deleting or changing an existing system setup password.................40...
-
Page 7: Chapter 1: Set Up Your Computer
To conserve battery power, the battery might enter power saving mode. 2. Finish Windows system setup. Follow the on-screen instructions to complete the setup. When setting up, Dell recommends that you: ● Connect to a network for Windows updates. NOTE: If connecting to a secured wireless network, enter the password for the wireless network access when prompted. - Page 8 Table 1. Locate Dell apps (continued) Dell apps Details SupportAssist Proactively checks the health of your computer’s hardware and software. NOTE: Renew or upgrade your warranty by clicking the warranty expiry date in SupportAssist. Dell Update Updates your computer with critical fixes and important device drivers as they become available.
-
Page 9: Chapter 2: Create A Usb Recovery Drive For Windows
A message appears, indicating that all data in the USB flash drive will be deleted. 7. Click Create. 8. Click Finish. For more information about reinstalling Windows using the USB recovery drive, see the Troubleshooting section of your product's Service Manual at www.dell.com/support/manuals. Create a USB recovery drive for Windows... -
Page 10: Chapter 3: Chassis Overview
Chassis overview Display view 1. Camera 2. Camera Status Light 3. Microphone 4. LCD Panel Chassis overview... -
Page 11: Left View
Left view 1. DC-in port 2. Power LED 3. USB 3.2 Gen 1 Type-C (optional) 4. HDMI 1.4 port NOTE: The maximum resolution supported by HDMI port is 1920x1080 @60Hz (24 bit) 5. Network Port 6. USB 3.2 Gen 1 Type-A 7. -
Page 12: Palmrest View
Palmrest view 1. Power button with optional finger print reader 2. Keyboard 3. Touchpad Chassis overview... -
Page 13: Bottom View
Bottom view 1. Speakers 2. Service Tag 3. Air Vents Keyboard shortcuts NOTE: Keyboard characters may differ depending on the keyboard language configuration. Keys that are used for shortcuts remain the same across all language configurations. Table 2. List of keyboard shortcuts Keys Primary behavior Fn + F1... - Page 14 Table 2. List of keyboard shortcuts (continued) Keys Primary behavior Fn + F7 Increase brightness Fn + F8 Switch to external display Fn + F10 Print screen Fn + F11 Home Fn + 12 Fn + Ctrl Open application menu Chassis overview...
-
Page 15: Chapter 4: Technical Specifications
Technical specifications NOTE: Offerings may vary by region. The following specifications are only those required by law to ship with your computer. For more information about the configuration of your computer, go to Help and Support in your Windows operating system and select the option to view information about your computer. Specifications of Vostro 3400 Processors Table 3. -
Page 16: Operating System
Operating system Your Vostro 3400 supports the following operating systems: ● Windows 11 Home, 64-bit ● Windows 11 Pro, 64-bit ● Windows 11 Pro National Academic, 64-bit ● Windows 11 Home National Academic, 64-bit ● Windows 10 Home, 64-bit ● Windows 10 Pro, 64-bit Memory Table 5. -
Page 17: Ports And Connectors
Ports and connectors Table 7. External ports and connectors Description Values External: Network One Flip-down RJ 45 10/100/1000 Mbps ● Two USB 3.2 Gen 1 Type-A port ● One USB 2.0 Type-A port ● One USB 3.2 Gen 1 Type-C port (optional) Audio ●... -
Page 18: Video
Table 9. Audio specifications (continued) Description Values configuration. For best results, use Dell recommended audio accessories Speakers Internal-speaker amplifier Supported Supported External volume controls Keyboard shortcut controls Keyboard shortcut controls Speaker Output Average Speaker Output Peak 2.5 W 2.5 W... -
Page 19: Camera
Camera Table 12. Camera specifications Standard Webcam Description Values Number of cameras Type HD RGB camera Location Front Camera Sensor type CMOS sensor technology Resolution: Still image 0.92 megapixel Video HD (720p @ 30 fps) Diagonal viewing angle 78.6 degrees Touchpad The following table lists the touchpad specifications of your Vostro 3400. -
Page 20: Media-Card Reader
Table 14. Ethernet specifications (continued) Description Values Transfer rate e.g. 10/100/1000 Mbps Wireless module Table 15. Wireless module specifications Description Values Model number Intel 9462 Qualcomm QCA9377 Realtek RTL8723DE (DW1810) Transfer rate Up to 433 Mbps Up to 433 Mbps Up to 150 Mbps Frequency bands supported 2.4 GHz/5 GHz 2.4 GHz/5 GHz... -
Page 21: Battery
Control the charging time, duration, start and end time, and so on using the Dell Power Manager application. For more information on the Dell Power Manager see, Me and My Dell on www.dell.com/... -
Page 22: Keyboard
Keyboard Table 19. Keyboard specifications Description Values Type ● Standard keyboard ● White backlight keyboard Layout QWERTY Number of keys ● United States and Canada: 81 keys ● United Kingdom: 82 keys ● Japan: 85 keys Size X=18.70 mm key pitch Y=18.05 mm key pitch Shortcut keys Some keys on your keyboard have two symbols on them. -
Page 23: Fingerprint Reader
Table 21. Display specifications (continued) Decsription Values Dimensions (active area): Height 173.99 mm (6.85 in.) 173.99 mm (6.85 in.) Width 309.35 mm (12.17 in.) 309.35 mm (12.17 in.) Diagonal 355.60 mm (14.00 in.) 355.60 mm (14.00 in.) Native resolution 1366 x 768 1920 x 1080 Megapixels 1.049... -
Page 24: Security Software
Standard Security Software Table 24. Security Software specifications Specifications Dell Client Command Suite Optional Dell Data Security and Management Software Dell Client Command Suite Dell BIOS Verification Optional Dell Endpoint Security and Management Software VMware Carbon Black Endpoint Standard VMware Carbon Black Endpoint Standard + Secureworks Threat Detection and Response... -
Page 25: Chapter 5: Software
Downloading Windows drivers Steps 1. Turn on the . 2. Go to Dell.com/support. 3. Click Product Support, enter the Service Tag of your , and then click Submit. NOTE: If you do not have the Service Tag, use the auto detect feature or manually browse for your model. -
Page 26: Chapter 6: System Setup
Boot menu Press <F12> when the Dell logo appears to initiate a one-time boot menu with a list of the valid boot devices for the system. Diagnostics and BIOS Setup options are also included in this menu. The devices listed on the boot menu depend on the bootable devices in the system. -
Page 27: Boot Sequence
Boot sequence enables you to bypass the System Setup–defined boot device order and boot directly to a specific device (for example: optical drive or hard drive). During the Power-on Self-Test (POST), when the Dell logo appears, you can: ● Access System Setup by pressing F2 key ●... -
Page 28: Boot Options
Table 26. Overview Option Description ○ Processor ID ○ Processor L2 Cache ○ Processor L3 Cache ○ Microcode Version ○ Intel Hyper-Threading Capable ○ 64-Bit Technology ● Memory Configuration ○ Memory Installed ○ Memory Available ○ Memory Speed ○ Memory Channel Mode ○... -
Page 29: System Configuration
System configuration Table 28. System configuration Option Description Date/Time The options are: ● Date ● Time NOTE: Legacy Boot mode is not supported on this platform. Network Controller Configurator Integrated NIC: 1. Disabled 2. Enabled 3. Enabled with PXE Enable UEFI Network Stack: 1. -
Page 30: Video
Video Table 29. Video Option Description LCD Brightness Set the screen brightness when running on battery power. ● 0 - 100 Brightness on AC power Set the screen brightness when running on AC power. ● 0 - 100 EcoPower Enable EcoPower - Enable to increase battery life and reduce the display brightness when appropriate. -
Page 31: Passwords
Table 30. Security (continued) Option Description PPI Bypass for Enable Allows the user to enable or disable TPM Physical Presence Interface (PPI). The controls are as Commands follows: ● On ● Off PPI Bypass for Disabled Allows the user to enable or disable TPM Physical Presence Interface (PPI). The controls are as Commands follows: ●... - Page 32 Table 31. Passwords (continued) Option Description password has to be set first if the admin password has to be used with system password and/or hard drive password. Password Configuration Allows the user to set the maximum number of characters for Admin and System oasswords: ●...
-
Page 33: Secure Boot
Secure Boot Table 32. Secure Boot Option Description Secure Boot Secure Boot helps ensure the system boots using only validated boot software. Enable Secure Boot—By default, this option is disabled. NOTE: The system has to be in UEFI boot mode to enable Enable Secure Boot. -
Page 34: Power Management
Table 34. Performance (continued) Option Description C-States Control This feature allows you to enable or disable the ability of the CPU to enter and exit low-power states. Enable C-state control This option is enabled by default. This feature allows the system to dynamically detect high usage of discrete graphics and adjust system parameters for higher performance during that time period. -
Page 35: Wireless
Table 35. Power Management (continued) Option Description The user will see the days of the week listed with fields to select the time. Battery Charge Allows the user to set the preferred battery charging plan for the system: Configuration The options are: ●... -
Page 36: Maintenance
Table 37. POST behavior (continued) Option Description Warnings and Errors Allows the user to configure in what circumstances would the system stop the boot process upon encountering errors: ● Prompt on Warning Errors — System will wait for user input when errors or warnings are detected. -
Page 37: System Logs
Steps 1. Go to www.dell.com/support. 2. Click Product support. In the Search support box, enter the Service Tag of your computer, and then click Search. NOTE: If you do not have the Service Tag, use the SupportAssist feature to automatically identify your computer. You can also use the product ID or manually browse for your computer model. -
Page 38: Updating The Bios In Linux And Ubuntu
One-Time boot menu on the computer. Most of the Dell computers built after 2012 have this capability, and you can confirm by booting your computer to the F12 One-Time Boot Menu to see if BIOS FLASH UPDATE is listed as a boot option for your computer. If the option is listed, then the BIOS supports this BIOS update option. -
Page 39: Updating The Bios In Windows
Windows. Steps 1. Restart the computer. 2. Go to Dell.com/support. ● Enter the Service Tag or Express Service Code and click Submit. ● Click Detect Product and follow the instructions on screen. 3. If you are unable to detect or find the Service Tag, click Choose from all products. -
Page 40: Updating The Dell Bios In Linux And Ubuntu Environments
If the recovery key is not known, this can result in data loss or an unnecessary operating system reinstall. For more information about this subject, see Knowledge Article: Updating the BIOS on Dell Systems With BitLocker Enabled Updating the Dell BIOS in Linux and Ubuntu environments... -
Page 41: Deleting Or Changing An Existing System Setup Password
Deleting or changing an existing system setup password Prerequisites Ensure that the Password Status is Unlocked (in the System Setup) before attempting to delete or change the existing System and Setup password. You cannot delete or change an existing System or Setup password, if the Password Status is Locked. -
Page 42: Chapter 7: Getting Help And Contacting Dell
Getting help and contacting Dell Self-help resources You can get information and help on Dell products and services using these self-help resources: Table 41. Self-help resources Self-help resources Resource location Information about Dell products and services www.dell.com My Dell Tips... - Page 43 Ovaj dokument je originalno proizveden i objavljen od strane proizvođača, brenda Dell, i preuzet je sa njihove zvanične stranice. S obzirom na ovu činjenicu, Tehnoteka ističe da ne preuzima odgovornost za tačnost, celovitost ili pouzdanost informacija, podataka, mišljenja, saveta ili izjava sadržanih u ovom dokumentu.
