UniCarriers J1B1 Operator's Manual

Platinum bx series cushion & pneumatic tire 36v & 48v 4-wheel ac powered electric 3,000-8,000 lb. capacities
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
R
OPERATOR'S MANUAL
MODELS J1B1/T1B2
Platinum BX Series Cushion & Pneumatic Tire
36V & 48V 4-Wheel AC Powered Electric
3,000-8,000 lb. Capacities
OPERATOR
Printing: October 2015 (01)
Publication No.: 0M1UC-M1B12
Printed in Marengo IL USA
