Pulsar 510 JETPACK Instruction Manual

510 JETPACK VAPORIZER
INSTRUCTION MANUAL
SPECS
Battery Capacity: 500 mAh
Device Dimensions: 1.0" x 4.8" (25.4 mm * 121.9 mm)
Voltage: 1.8-3.8 V
Charging: USB-C
Max Cart Size: 12 mm x 62 mm
Resistance: ≥0.8 -1.2
CHARGING
Ensure that the device is powered off and the cartridge is removed prior to charging. Charge the
battery fully before first use. For the best charging experience, use a USB-C cable and a standard
wall charging brick to charge the device. Charging will be indicated by the LED button lighting up
red. When the device is fully charged, the red light will turn green. To prolong the life of your Pulsar
510 Battery, don't leave it plugged in for more than 2 hours at a time, and do not use a car charger.
POWERING ON
Remove the charger from the device and press the power button 5 times to turn the device on.
Attach a pre-filled 510-threaded cartridge (do not overtighten).
CHANGE VOLTAGE SETTINGS
With the device turned on, press the power button once to change the voltage setting. The voltage settings are each
indicated by a different color light on the button.
 1.8 V - Yellow  2.4 V - Purple
PRE HEATING
Once your voltage setting is selected you can use the preheat function by pressing the power button quickly twice. The
pre-heat function is set at 1.8 V and will be indicated by the LED ring lighting up and cycling through the colors. The
preheat cycle will last 8 seconds. Note: Preheat mode can be stopped by pressing the power button once.
USAGE CLOSED TOP
This device is equipped with an autodraw function. Simply place your lips on the mouthpiece and pull. This will activate
the device. The light ring will light up showing the selected voltage during use. Note: there is a 10 second vape timer, if
you pull on the device consecutively for 10 seconds the battery will stop powering the cartridge and the button will
flash red 3 times.
USAGE OPEN TOP
Simply open the top of the device, this will automatically start the auto smoke function. Your vapor will propel out of the
opening in the device. Simply inhale directly. The open top use function will time out in 8 seconds. To sesh again simply
close the device top and reopen to restart.
POWERING OFF
To fully turn off the device press the power button 5 times. The device will enter sleep mode automatically with no input
after 10 seconds..
CLEANING
Use a cotton swab and 91% alcohol to clean any residue from the 510 connection. Remove the bottom magnetic
cartridge to clean the inside the air pathway with an alcohol swab. Using a circular motion, work your way up and down
the air pathway until you do not see any more oil. Repeat this process for the inside of the flip top mouthpiece.
Note: When using the Open Top function, do not apply any pressure to the mouthpiece as the hinge of the mouthpiece
may get damaged and affect the function of your device.
WARNINGS
Do not expose to extreme temperatures or direct sunlight. Do not drop the device or accessories. Do not drop or submerge in any
liquid. Do not modify the electronics in any way. This device is intended for adults only. Do not sell or provide to minors. Keep all parts,
concentrates, herbs, and liquids away from children and pets. This is not a medical device and is not intended to diagnose, treat,
mitigate, cure, or prevent any ailment, disease, or other conditions. Consult a physician before use, especially if you suffer from heart
disease or any other medical condition, or if you are pregnant or breastfeeding. Failure to follow any of these instructions could result
in product damage, property damage, personal injury, and may void warranty.
 2.8 V - Green  3.4 V - Blue
PulsarShop.com
KIT INCLUDES
1x Pulsar Jetpack 510 Battery
 3.8 V - Red
CARTRIDGE
NOT INCLUDED
CARTOUCHE
NON INCLUSE
PU-0759-24
