Pulsar APX Oil 510 Instruction Manual

TECHNICAL SPECIFICATIONS
Size: 3.46 x 1.85 x .79" (88 x 47 x 20 mm)
Max Cart Size: .57 x 2.36" (14.5 x 60 mm)
Battery Capacity: 1000 mAh
Voltage: 2.4 / 2.6 / 2.8 / 3.4 / 3.8 V (1.8 V Pre-heat)
Charging: USB-C
Resistance: ≥0.8
POWER ON/OFF
The device doesn't turn off. It enters a standby mode after 10 seconds. To wake the device up, press the button on
the bottom 1 time and the screen will turn on and the LED will flash the current voltage. You can also pull from the
mouthpiece and the device will be ready to vape. The screen displays the battery life in %.
PRE HEATING
Quickly press the button on the bottom 2 times to activate the pre-heat function.
CHANGE VOLTAGE SETTINGS
You change the setting by pressing the button on the bottom 1 time. The screen also indicates the voltage setting
in the bars.
2.4 V - Yellow 2.6 V - Purple
CHARGING
The LED light will be red while charging and the lightning icon will flash on the screen. When the device is fully
charged the LED will change to green and the lightning icon will stop flashing. When the battery is dead the LED will
flash red 10 times and enter standby mode to let you know it needs to be charged before it's used again.
PROTECTION FEATURES
Battery life/ cartridge protection: After 10 continuous seconds of use, the red light will flash 4 times and enter
standby mode. Over-voltage/short-circuit protection: The LED will flash red 3 times and the device will fully turn off.
INSTRUCTIONS
1. Make sure the bottom magnetic connector is properly connected to the battery. The battery will not
charge if the bottom connector is not attached.
2. Before using the APX Oil, fully charge the device using a USB-C charging cable and a standard charging
brick. You will see the LED and screen turn on when the battery is charging.
3. Allow the battery to fully charge before the first use. When the LED light turns green the device is fully
charged and can be unplugged.
4. Remove the bottom magnetic connector and firmly screw in the 510-threaded cartridge of your choice.
5. Insert the cartridge into the device and ensure the bottom magnetic connector is properly connected. You
will feel haptic feedback to let you know there is a good connection.
6. Press the bottom button 1 time to adjust the voltage.
7. Activate the pre-heat function to prime the cartridge by pressing the bottom button 2 times. This will
activate the device at 1.8 V for 15 seconds. After 15 seconds, the device will switch to your previously
selected voltage.
8. Simply pull from the mouthpiece to activate the cartridge vapor and enjoy your session.
9. To reset your puff counter, press the button 3 times quickly, on the third press hold the button down until
the puff counter resets.
CLEANING INSTRUCTIONS
1. Remove the bottom magnetic connector from the battery.
2. Wipe the outside and inside of the bottom magnetic connector with an isopropyl alcohol pad. Use an
alcohol swab to wipe any excess oil out of the 510 connector.
3. Clean inside the air pathway with an alcohol swab. Using a circular motion, work your way up and down the
air pathway until you do not see any more oil.
4. Do not submerge any part of the device in a cleaning solution. Allow all parts to air dry prior to reassembly.
NOTE: The mouthpiece is not removable.
WARNINGS
Do not expose to extreme temperatures or direct sunlight. Do not drop the device or accessories. Do not drop or submerge in any
liquid. Do not modify the electronics in any way. This device is intended for adults only. Do not sell or provide to minors. Keep all
parts, concentrates, herbs, and liquids away from children and pets. This is not a medical device and is not intended to diagnose,
treat, mitigate, cure, or prevent any ailment, disease, or other conditions. Consult a physician before use, especially if you suffer
from heart disease or any other medical condition, or if you are pregnant or breastfeeding. Failure to follow any of these
instructions could result in product damage, property damage, personal injury, and may void warranty. Visit
warranty information.
INSTRUCTION
MANUAL
2.8 V - Green 3.4 V - Blue
KIT INCLUDES
1x Pulsar APX Oil Battery
1x Bottom Magnetic Connector
1x USB Cable
3.8 V - Red
PulsarShop.com for
PulsarShop.com
PU-0723-24
