Pulsar SYNDR User Manual

DRY HERB VAPORIZER
USER MANUAL
TECHNICAL SPECIFICATIONS:
Dimensions: 0.99 x 0.72 x 4.29 Inches
Battery capacity: 880mAh
Battery discharge current: 8A discharging
Charging port: USB-C
Charging Voltage: 5V 1A
Temperature setting: 440°F / 410°F / 390°F / 360°F
Heating element: 316L stainless steel
OPERATING INSTRUCTIONS
You will need to fully charge the Pulsar
before first use. The charging port is located
underneath the silicone cover by the power button.
The cover does not come all the way off. Simply
pull down from the top and pivot the cover off to the
side so it's out of the way. Use included USB-C
cable and compatible charging brick to charge the
device. The light will turn red while charging and
green when fully charged. Once the device is
charged, unplug from the cable and cover the
USB-C port.
Upon first use, it is recommended to run this device
through a heating cycle without any material in the
chamber to burn off any manufacturing residue
which may affect taste or smell during normal use.
Open the bottom heating chamber by pushing one
side with your thumb. It should be removed with
ease. Fill the chamber to the top of the stainless steel
chamber. This is the maximum fill for the unit.
Once loaded, replace the bottom chamber. Hold the
power button for 5 seconds to power on the device.
Power button is located just below the charging
cover. You will notice the power button insignia. You
will feel the haptic feedback (vibration) and also see
the light pulsate when turned on. The pulsating light
signifies the device heating up to the preferred
temperature (approximately 30 seconds). At this
time, to find your preferred heat setting, press the
power button one time for each heat setting. Cycle through the
settings to find your desired setting. Once you find your desired
temperature setting then the device will heat to that setting.
Yellow Light - 360°F
Green Light - 390°F
Blue Light - 410°F
Red Light - 440°F
The unit will vibrate twice once the device achieves your set
temperature. The Pulsar insignia will also turn a solid color
instead of the flashing during the pre-heat cycle. This is when
you can begin your vape session. When you power the device
back on after your last use, the last heat setting you set it to will
be present. To change the setting follow the instructions above.
To end your session before the sesh timer times out, simply
hold the button down for 5 seconds to power off the device.
When the device is powered off, you can view the battery life by
pressing the power button once.
Green Light - 75% or higher
Blue Light - 30%-75%
Red Light - 30% or below
PRO TIPS
Vape timer is set to 3 minutes for the Yellow, Green, and Blue
settings. The Red setting is set to 2 minutes. If you do not
Syndr vape
® ™
complete your session at this time, take the bottom connector
off and stir with the included stir/brush tool.
The device does not support pass-through charging.
To maximize efficiency, whenever possible, allow the unit to
cool completely before the next session.
Empty the cashed material at the end of each session and use
the cleaning brush to remove any excess particles from the
heating chamber. This will keep the unit clean for your next
session.
CLEANING INSTRUCTIONS
First remove the bottom chamber cover and the silicone
mouthpiece insert.
Use the cleaning brush to clean the mouthpiece opening and
the bottom chamber opening.
Insert the poker side of the cleaning tool all the way into the
mouthpiece opening to push out the screen.
Use the isopropyl cotton swabs to push through the airpath
chamber, while also wiping out the bottom chamber and
mouthpiece opening. Allow to air dry after cleaning.
To reassemble, put the screen back into the bottom chamber
and press with the poker tool side of the cleaning tool. It should
lock into place.
Place the mouthpiece insert back into the mouthpiece opening.
