- Page 1 Version v1.0 Mega 19ft Square Assembly & Maintenance Manual...
- Page 2 Read all assembly, warning, care maintenance and usage instructions in the manual and on the product prior to assembling and using the Jumpflex® product These products are for personal use only by one person aged 6 years and older. These products are for outdoor use only.
-
Page 3: Table Of Contents
Contents Notice to User & Safety Information Maintenance & Care Instructions Trampoline Placement Trampoline Parts List Assembly Instructions... -
Page 4: Notice To User & Safety Information
As a consequence, personal injury or death may occur. The customer assumes and accepts all such risks to the full extent permitted by law and waives any right of action against, and fully releases Jumpflex® for all loss, damages, personal injury or death in any way caused by, or relating to, the customer’s use of the Equipment. -
Page 5: Safety Instructions
Specific Use Limitations 1. Do not use a Jumpflex® trampoline without mature and knowledgeable supervision present. Children using a trampoline with a trampoline safety net must be supervised by adults. Young children must be supervised constantly. 2. Do not attempt or allow somersaults. - Page 6 Children using a trampoline with a trampoline safety net must be supervised by adults. Young children must be supervised constantly. Adults must pay particular attention to: • Ensuring that the entrance of the safety net is completely closed prior to Jumpflex® trampoline usage.
-
Page 7: Maintenance & Care Instructions
2 months. safety padding. High temperatures may result in melting or burning of the padding material and 2. We strongly recommend cleaning your Jumpflex extreme temperatures may cause the padding to Trampoline and accessories every month with warm catch fire. -
Page 8: Trampoline Placement
• Recommended clearance of 1m/3.3ft from obstacles such as walls, structures, fences and other play areas. • Keep the trampoline on a level surface. • The trampoline must not be used in gusty or severe wind. Jumpflex® Assembly & Maintenance Manual... -
Page 9: Trampoline Parts List
Trampoline Parts List Part Description Straight Top Rail - A (green sticker) Straight Top Rail - B (green sticker) Curved Top Rail T Joint Connector PowerPlate Foot Leg Pole Jumpflex® Assembly & Maintenance Manual... - Page 10 Part Description Lower Net Pole Upper Net Pole with Net Pole Cap Net Pole Sleeve Mega Spring Jump Mat Safety Net Corner Pad Straight Pad Ladder Jumpflex® Assembly & Maintenance Manual...
- Page 11 Part Description Airflow Straps Bolt, Nut and Washer Allen Key Tool Spanner Rubber Mallet Spring Tool Gloves Jumpflex® Assembly & Maintenance Manual...
-
Page 12: Assembly Instructions
Note: Straight Top Rails - A (1) has the green sticker on the small end and Straight Top Rails - B (2) has the green sticker on the larger end. Note the green stickers Jumpflex® Assembly & Maintenance Manual... - Page 13 Insert the larger end of one Straight Top Rail - B (2) into the T Joint Connector (4). Note: Ensure the green sticker is aligned next to the T Joint Connector (4). Jumpflex® Assembly & Maintenance Manual...
- Page 14 Insert the smaller end of one Straight Top Rail - A (1) into the opposite end of the T Joint Connector (4). Note: Both green stickers should be positioned next to the T Joint Connector. Jumpflex® Assembly & Maintenance Manual...
- Page 15 Attach and secure the PowerPlate (5) with the provided bolts and tools. Note: Position the Strengthening Plate on the correct side of the assembled top rails with the curved radius facing inwards towards the Jumping area. Jumpflex® Assembly & Maintenance Manual...
- Page 16 Jumpflex® Assembly & Maintenance Manual...
- Page 17 Attach another T Joint Connector (4) to the end of this assembly Jumpflex® Assembly & Maintenance Manual...
- Page 18 Connect 2 Leg Poles (7). Note: Ensure the button clips align and click into place. Jumpflex® Assembly & Maintenance Manual...
- Page 19 Connect 1 Foot (6). Note: Ensure the button clips align and click into place. Jumpflex® Assembly & Maintenance Manual...
- Page 20 Assemble 4 straight top rail assemblies. Jumpflex® Assembly & Maintenance Manual...
- Page 21 Now connect 1 Curved Top Rail (4) to 1 T Joint Connector (5). Jumpflex® Assembly & Maintenance Manual...
- Page 22 Insert another Curved Top Rail (3) into the assembled T Joint Connector (4) Jumpflex® Assembly & Maintenance Manual...
- Page 23 Insert another T Joint Connector (4) into the opposite end of the Curved Top Rail. Jumpflex® Assembly & Maintenance Manual...
- Page 24 Connect 2 Leg Poles (7). Note: Ensure the button clips align and click into place. Jumpflex® Assembly & Maintenance Manual...
- Page 25 Connect 1 Foot (6). Note: Ensure the button clips align and click into place. Jumpflex® Assembly & Maintenance Manual...
- Page 26 Assemble 4 corner top rail assemblies. Jumpflex® Assembly & Maintenance Manual...
- Page 27 Now assemble the trampoline frame by connecting 1 straight top rail assembly with 1 corner top rail assembly. Jumpflex® Assembly & Maintenance Manual...
- Page 28 Repeat until the complete square frame has been assembled as per the illustration Jumpflex® Assembly & Maintenance Manual...
- Page 29 Attach 2 Mega Springs (11) to either side of the T Joint Connector (4) at each corner of the square frame. Jumpflex® Assembly & Maintenance Manual...
- Page 30 Lay the Jump Mat (12) out with the Jumpflex logo facing upwards. Jumpflex® Assembly & Maintenance Manual...
- Page 31 Align the green tag on the Jump Mat (12) with the pre-attached springs and hook each spring to the Jump Mat (12) D-ring. Using the Spring Tool (22) attach a Spring (11) first to the Jump Mat (12) and then to the frame. Jumpflex® Assembly & Maintenance Manual...
- Page 32 Attach 2 more Mega Springs (11) to either side of the remaining T Joint Connectors (4) and connect them to the Jump Mat (12). Jumpflex® Assembly & Maintenance Manual...
- Page 33 Using the Spring Tool (22), continue around the Jump Mat (12), attaching a spring first to the Jump Mat (12) and then to the frame. Jumpflex® Assembly & Maintenance Manual...
- Page 34 Connect the Airflow Strap (17). Jumpflex® Assembly & Maintenance Manual...
- Page 35 The Airflow Straps (17) are designed to hold the weight of the Spring Padding while bouncing. This greatly improves the bounce performance of the trampoline. Jumpflex® Assembly & Maintenance Manual...
- Page 36 Locate the green tag making sure the tag is facing outwards. Important: Position the green tag exactly in the middle between two legs. Count out the springs from left to right and locate the two middle springs. Jumpflex® Assembly & Maintenance Manual...
- Page 37 Important: To make sure the net is not inside out, make sure the green tag is facing outwards. Jumpflex® Assembly & Maintenance Manual...
- Page 38 Safety Net (13) and thread it through the Jump Mat (12) D-Ring and over the attached spring hook. Work your way around the trampoline and repeat until all the eyelets are attached. Jumpflex® Assembly & Maintenance Manual...
- Page 39 Take out and lay all the Corner and Straight Pad (14,15) sections over the Springs and outer frame. Jumpflex® Assembly & Maintenance Manual...
- Page 40 Velcro each Spring Padding section together by positioning the Velcro tab between the Velcro flap. Jumpflex® Assembly & Maintenance Manual...
- Page 41 Once all Spring Pad sections are secured, insert the Net Pole Connection Tube up through the hole in each Spring Pad section. Jumpflex® Assembly & Maintenance Manual...
- Page 42 Take out one Upper Net Pole (9) and remove the Net Pole Cap. Make sure to keep the Top Screw Caps in a safe place. Jumpflex® Assembly & Maintenance Manual...
- Page 43 Attach the Upper Net Pole (9) to the Lower Net Pole (8). Ensure the button clip is aligned and clicks into place. Repeat these steps until all the net poles are assembled. Jumpflex® Assembly & Maintenance Manual...
- Page 44 Take out the Net Pole Sleeves (10) and slide them over the assembled net poles. Ensure the top thread is protruding through the sleeve. Jumpflex® Assembly & Maintenance Manual...
- Page 45 Attach each assembled net pole into the top of the T Joint Connector (4). Jumpflex® Assembly & Maintenance Manual...
- Page 46 Net (13) and insert the hole over the top thread of the Upper Net Poles (9) to raise the net. Screw the Net Pole Caps back on the top thread to secure the plastic eyelet. The Safety Net (13) is now fully assembled. Jumpflex® Assembly & Maintenance Manual...
- Page 47 Take the Ladder (16) and place the ladder hooks over the Upper Rail, in the middle of the entrance. Jumpflex® Assembly & Maintenance Manual...
