BM 2610995775 2/03
2/12/03
Functional Description and Specifications
Disconnect the plug from the power source before making any
WARNING
!
assembly, adjustments or changing accessories. Such preventive safety
measures reduce the risk of starting the tool accidentally.
TOOL
WING
HOLDER
KNOB
* DEPTH
GAUGE
LOCK
BOLT
AUXILIARY
HANDLE
HAND GRIP
Model number
11232EVS
Voltage rating
120 V
Amperage rating
8.8 A
No load speed
n
Maximum Capacities:
Carbide tipped bits
1 1/2"
Thru hole bits
2 1/2"
Thick wall core bits
3 1/2"
10:18 AM
Page 6
Rotary Hammers
FIG. 1
* RELEASE
BUTTON
* SELECTOR
LEVER
VENTILATION
OPENINGS
* NOT AVAILABLE ON ALL MODELS
11233EVS
50 - 60Hz
120 V
8.8 A
1,600-3,200/min
n
1,600-3,200/min
0
0
1 1/2"
2 1/2"
3 1/2"
-6-
TRIGGER
SWITCH
* VARIABLE
SPEED DIAL
* SERVICE
REMINDER
LIGHT
11244E
50 - 60Hz
120 V
50 - 60Hz
8.8 A
n
3,200/min
0
1 1/2"
2 1/2"
3 1/2"
