Digital Gas Controller Series
PolyGard
2 DGC6
®
Installation & Commissioning Guidelines
December 2024
April 17, 2025 – Revision
INTEC Controls | 12700 Stowe Drive, Suite 100, Poway, CA 92064 | (858) 578.7887 & (888) GO.INTEC | inteccontrols.com
