Operating Instructions & Installation Guide
SW7-1
Portable Backup Camera with 7"Monitor
Built-in battery and solar panel
USER MANUAL
Thank You for Buying VEKOOTO Product.
Read This User Manual Before Installing and Using It.
Pls keep this instruction or write down our email VEKOOTO@OUTLOOK.COM
So you can find us once you have any question.
1
Advertisement
Related Manuals for VEKOOTO SW7-1
Summary of Contents for VEKOOTO SW7-1
- Page 1 Built-in battery and solar panel USER MANUAL Thank You for Buying VEKOOTO Product. Read This User Manual Before Installing and Using It. Pls keep this instruction or write down our email VEKOOTO@OUTLOOK.COM So you can find us once you have any question.
- Page 2 VEKOOTO@outlook.com...
-
Page 3: Monitor Introduction
VEKOOTO@outlook.com 1. Monitor introduction The user can perform the manipulation of the guest power segment on the display parameters through the following nuclear health operations. –– ① : Decrease button ② : Setting menu ③ : Increase button ④ : Confirm/ Record ⑤... -
Page 4: Product Features
VEKOOTO@outlook.com Monitor Size 7 inch Type IPS 1024*600 Brightness 500 cd/m² Power input DC9-35V Maximum power Max 6W Support channel Support CH4/ CH3/ CH2/ CH1/ split screen at the same time Mirroring Support Recording Video Support SD card Support up to 512G... - Page 5 VEKOOTO@outlook.com 1、 2.4G WIFI wireless transmission, 3db antenna. 2、 Support for HD 850 infrared night vision function. 3、 Waterproof rating IP68. 4、 Transmission bandwidth 20MHz, 50M in the open distance. 5、 Horizontal and left and right viewing angles are larger than 140 degrees.
-
Page 6: Package List
VEKOOTO@outlook.com hours. 9、Support for charge while using. 10、Magnet anti-skid function. 3. Package List 7-inch Monitor Suction cup holder Sticker Monitor antenna Bakcup Camera Camera antenna... - Page 7 VEKOOTO@outlook.com Power extension cable Cigarette lighter power cord Screws×4 Type-C charging cable 4. Install Monitor Bracket Snap the mount's patch into the notch on the back of the monitor.
- Page 8 VEKOOTO@outlook.com How to format SD card and turn on recording video? 1. Press the "M" button to open the setup menu and select RECORD with the "+" and "-" buttons 2. Press the "+" "-" button to select FORMAT, press the "OK"...
- Page 9 VEKOOTO@outlook.com indicating that the recording has started, press the "OK" button to stop/open the recording. 6. How do I pair the camera? 1. Press "CH" button to select channel 1, press "M" to enter the setup menu, select "PAIRING" and press "OK", the system will search for the first camera signal and pair up automatically.
- Page 10 VEKOOTO@outlook.com 7. MENU FAQ Q1: The screen shows a blue screen, no signal how to do? A1: First make sure the backup camera is powered and on, click the settings button to enter the settings menu and select pairing for pairing.
- Page 11 VEKOOTO@outlook.com A3: You need to insert the SD card in the SD card socket at the top of the monitor and follow the steps below. 8. Note: It is recommended that the backup camera be charged for 5 hours for the first time.
