VEKOOTO SW7-1 User Manual
Magnetic wireless backup camera 7” monitor kit built-in battery and solar panel
Hide thumbs
Also See for SW7-1:
- Operating instructions and installation manual (8 pages) ,
- User manual (11 pages)
Subscribe to Our Youtube Channel
Related Manuals for VEKOOTO SW7-1
Summary of Contents for VEKOOTO SW7-1
- Page 1 Brand: VEKOOTO Model ： SW7-1 SW7-1 Magnetic Wireless Backup Camera 7” Monitor Kit Built-In Battery and Solar Panel USER MANUAL...
- Page 2 Brand: VEKOOTO Model ： SW7-1 oreword Thank you for purchasing committed to providing high-quality products and bringing a good experience to our customers. It's our great honor to have your trust! This manual includes product descriptions and operation descriptions. To get the best performance, read the manual carefully before installing and keep the manual correctly.
-
Page 3: Package List
Brand: VEKOOTO Model ： SW7-1 ackage List 7’ Monitor (Including 32GB SD Suction Cup Bracket Card) U-Bracket Sticker Monitor Cigarette lighter power cord Monitor Power extension cable Camera Charger... - Page 4 Brand: VEKOOTO Model ： SW7-1 Camera Metal Plate Monitor Antenna Extended Antenna Camera & Monitor Antenna If you find that the product in the packaging is damaged or lacks accessories, please send your #order number and your Shipping address/phone number to the after-sales customer service email, and we will immediately handle it.
- Page 5 Brand: VEKOOTO Model ： SW7-1 ntroduction to Camera Steady on 1 to 25% of the remaining power Steady on 26 to 50% of the remaining power Steady on 51 to 75% of the remaining power Steady on 76 to 100% of the remaining power...
- Page 6 Brand: VEKOOTO Model ： SW7-1 Critical！ When the camera is powered on, the blue battery indicator will illuminate. While charging, the blue power indicator light will flash consecutively. When the camera's solar panel is exposed to sunlight, the camera will start charging (indicated by the consecutive flashing of the blue lights).
- Page 7 Brand: VEKOOTO Model ： SW7-1 HD 1920×1080 （ 3 Million ） Resolution Transmission Distance 60ft in open distance 20Mbps （ Max ） Transmission Bandwidth Battery Capacity 9600mA Yes ， 4 Blue lights Battery Level Display Battery Charging Time USB 5V 2A / 6H Frequency 2400-2483.5MHZ...
-
Page 8: I Ntroduction To Monitor
Brand: VEKOOTO Model ： SW7-1 ntroduction to Monitor Reduce/Select Button Settings/ Back Button Increase/Select Button Confirm Button Switch Channel Button Show/No Parking Guideline Button Monitor's Power Button... - Page 9 Brand: VEKOOTO Model ： SW7-1 Monitor Size 7 inches Type Brightness 500 cd/m² Power input DC 12-35V Maximum power Max 6W Support channel Support up to 4 cameras Mirroring Support Recording Video Support SD Card Support up to 128G...
-
Page 10: Installation
Brand: VEKOOTO Model ： SW7-1 nstallation Install the Camera and Monitor Antennas;... - Page 11 Brand: VEKOOTO Model ： SW7-1 2. Insert the Monitor Power Cord into the Cigarette Lighter and Connect.
- Page 12 Brand: VEKOOTO Model ： SW7-1 3. Press the camera power button, and after a few seconds, the monitor will automatically display the camera's image. (Because the camera is already paired with Channel 1 of the monitor at the factory, no further action is required.)
-
Page 13: R Emote Control Introduction
Brand: VEKOOTO Model ： SW7-1 emote Control Introduction ○ 1 Power On/Off the Monitor ○ 2 Increase/Select Downward ○ 3 Decrease/Select Upward ○ 4 Enter Settings/Go Back ○ 5 Turn On/Off Guidelines ○ 6 Switch Channels... - Page 14 Brand: VEKOOTO Model ： SW7-1 onitor Function Introduction l System Settings Menu Press to switch the monitor image to CAM1 or CAM2 and press the button to enter the system settings menu.
- Page 15 Brand: VEKOOTO Model ： SW7-1 PAIRING The system defaults to the camera with CAM1. If you want to add an additional camera to your monitor, you can switch the channel to CAM2 or CAM3 or CAM4 and enter the menu pairing new camera.
- Page 16 Brand: VEKOOTO Model ： SW7-1 PICTURE Press the button to enter the menu, Press the button to select PICTURE, and press the button to confirm. Here you can DIY the image parameters of the current camera.
- Page 17 Brand: VEKOOTO Model ： SW7-1 l MIR-FLIP Press the button to enter the menu, Press the button to select MIR-FLIP and press the button to confirm. Here you can set the mirror image and flip of the current camera image.
- Page 18 Brand: VEKOOTO Model ： SW7-1 l MODE Press the button to enter the menu, Press the button to select MODE and press the button to confirm. Here you can set the image display model.
- Page 19 Brand: VEKOOTO Model ： SW7-1 l CAM-SETUP Press the button to enter the menu, Press the button to select CAM-SETUP, and press the button to confirm. Here you can open and close each camera channel.
- Page 20 Brand: VEKOOTO Model ： SW7-1 l System Press the button to enter the menu, Press the button to select SYSTEM, and press the button to confirm. Here you can set time, language, etc.
- Page 21 Brand: VEKOOTO Model ： SW7-1 l PLAY Press the button to enter the menu, Press the button to select PLAY, and press the button to confirm. Here you can play video recording files. Support cycle recording, it will automatically cover...
- Page 22 Brand: VEKOOTO Model ： SW7-1 l RECORD Press the button to enter the menu, Press the button to select RECORD, and press the button to confirm. REWRITE：Loop Recording FORMAT：Format memory card Record Time：The time length of the video clip...
- Page 23 Brand: VEKOOTO Model ： SW7-1 ENU FAQ Q1: Why is the signal very weak? Image delay？ A1: Make sure the antenna of the camera and the monitor is firmly installed, and the antenna does not touch the metal because the metal blocks the signal. You...
-
Page 24: Customer Service
12 hours. When you contact our customer service, please attach your #order number or your product model so that we can quickly reply to your question. VEKOOTO@OUTLOOK.COM arranty All VEKOOTO products provide a 2-year free warranty service. Unless human damage.
