Home Appliances
KF-66DIDD04IM1I-EN
KF-66DIDD04BH1I-EN
Cooking
EN
User Manual
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the KF-66DIDD04IM1I-EN and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Sharp KF-66DIDD04IM1I-EN

  • Page 1 Home Appliances KF-66DIDD04IM1I-EN KF-66DIDD04BH1I-EN Cooking User Manual...
  • Page 2 Thank you for choosing this product. This User Manual contains important safety information and instructions on the operation and maintenance of your appliance. Please take the time to read this User Manual before using your appliance and keep this book for future reference. Icon Type Meaning...
  • Page 3: Table Of Contents

    CONTENTS 1.SAFETY INSTRUCTIONS ....................4 1.1 General Safety Warnings ....................4 1.2 Installation Warnings ...................... 7 1.3 During Use........................8 1.4 During Cleaning and Maintenance ................. 9 2.INSTALLATION AND PREPARATION FOR USE .............11 2.1 Instructions for the Installer ...................11 2.2 Electrical Connection and Safety.................. 12 2.3 Anti-tilting kit .........................
  • Page 4: Safety Instructions

    1. SAFETY INSTRUCTIONS • Carefully read all instructions before using your appliance and keep them in a convenient place for reference when necessary. • This manual has been prepared for more than one model therefore your appliance may not have some of the features described within.
  • Page 5 WARNING: Danger of fire: Do not store items on the cooking surfaces. WARNING: If the surface is cracked, switch off the appliance to avoid the possibility of electric shock. • For induction hobs, metallic objects such as knives, forks, spoons and lids should not be placed on the hob surface because they can get hot.
  • Page 6 before replacing the lamp. CAUTION: Accessible parts may be hot when cooking or grilling. Keep young children away from the appliance when it is in use. • Your appliance is produced in accordance with all applicable local and international standards and regulations.
  • Page 7: Installation Warnings

    its service agent or similarly qualified persons in order to prevent a danger. • Do not let children climb on the oven door or sit on it while it is open. • Please keep children and animals away from this appliance.
  • Page 8: During Use

    decorative door, in order to avoid overheating. 1.3 DurinG uSe • When you first use your oven you may notice a slight smell. This is perfectly normal and is caused by the insulation materials on the heater elements. We suggest that, before using your oven for the first time, you leave it empty and operate it at maximum temperature for 45 minutes.
  • Page 9: During Cleaning And Maintenance

    valve off when gas appliances are not in use. • Make sure the appliance control knobs are always in the “0” (stop) position when it is not used. • The trays incline when pulled out. Take care not to spill or drop hot food while removing them from the oven.
  • Page 10 CE Declaration of conformity We declare that our products meet the applicable European Directives, Decisions and Regulations and the requirements listed in the standards referenced. This appliance has been designed to be used only for home cooking. Any other use (such as heating a room) is improper and dangerous.
  • Page 11: Installation And Preparation For Use

    2. INSTALLATION AND dryer. PREPARATION FOR USE • The appliance can be placed close to other furniture on condition that, in the WARNING : This appliance must be area where the appliance is set up, the installed by an authorised service furniture’s height does not exceed the person or qualified technician, height of the cooktop.
  • Page 12: Electrical Connection And Safety

    2.2 eleCtriCal ConneCtion anD Safety • If the appliance is not connected to the mains with a plug, a all-pole WARNING: The electrical connection disconnector (with at least 3 mm contact of this appliance should be carried out spacing) must be used in order to meet by an authorised service person or the safety regulations.
  • Page 13: Anti-Tilting Kit

    • For this connection, a ‘Twin and Earth Product Dimensions 6242Y’ type cable should be used. A (mm) B (mm) (Width X Depth X Height) (Cm) 60x60x90 (Double Oven) 297.5 50x60x90 (Double Oven) 247.5 90x60x85 60x60x90 309.5 60x60x85 309.5 50x60x90 247.5 50x60x85 247.5...
  • Page 14: Product Features

    3. PRODUCT FEATURES Important: Specifications for the product vary and the appearance of your appliance may differ from that shown in the figures below. List of Components 1. Cooktop 2. Control Panel 3. Top Oven Door Handle 4. Top Oven Door 5.
  • Page 15: Use Of Product

    4. USE OF PRODUCT must heating at a few seconds. • When using certain pans, you may hear 4.1 hob ControlS various noises coming from them, this is due to the design of the pans and does Induction Zone not affect the performance or safety of The induction zone is controlled by a knob the hob.
  • Page 16 Heat setting Safety switch off after 6 Hours 5 Hours 4 Hours 1.5 Hours Timer Function 1- Decrease timer Cooking Zone Timer (1 - 99 min.) 2- Timer display When the hob is switched on, an independent timer can be programmed for 3- Timer zone indicator each cooking zone.
  • Page 17 activated. Microprocessor alert. After this warning, The necessary power reduction is shown cut off energy from the product and then C1-C8 re-energize the product. If the same error is by the corresponding cooking zone display displayed again, call an authorised service blinking.
  • Page 18 Fan Function: Switch Upper Heating on the FAN function Function: Switch on using the main oven the UPPER function control knob. The using the top oven oven’s thermostat and function control knob. warning lights will The oven thermostat switch on, and the and warning lights will upper and lower illuminate, and the...
  • Page 19: Use Of The Digital Touch Timer

    4.2 uSe of the DiGital touCh tiMer 3. After a few seconds, the dot will stop flashing and will remain illuminated. Key Lock The key lock automatically activates after the timer has not been used for 7 Function Description seconds. “ ” symbol will appear and remain illuminated.
  • Page 20 period of time. A time range between 0 and 10 hours can be set. Prepare the food for cooking and put it in the oven. 1. Select the desired cooking function and the temperature using the control knobs. 2. Press “MODE” until you see “dur”...
  • Page 21: Cleaning And Maintenance

    recover their original appearance and performance. • Trays and wire grids can be positioned on any level from 1 to 5. • Telescopic rails can be positioned on levels T1, T2, 3, 4, 5. • Level 3 is recommended for single level cooking.
  • Page 22 Ceramic glass can hold heavy utensils but and dry them. may be broken if it is hit with a sharp object. Do not clean the enamelled parts while they are still hot from cooking.
  • Page 23 of alcohol, stain removers, degreasers, below. surface abrasive chemicals. Otherwise, 1. Open the oven door. corrosion may occur on the powder painted surfaces, and stains may occur. The manufacturer will not be held responsible for any damage caused by the use of inappropriate cleaning products or methods.
  • Page 24: Maintenance

    Removal of the Wire Shelf To remove the wire rack, pull the wire rack as shown in the figure. After releasing it from the clips (a), lift it up. 5.2 MaintenanCe WARNING: The maintenance of this appliance should be carried out by an authorised service person or qualified technician only.
  • Page 25: Troubleshooting&Transport

    6. TROUBLESHOOTING&TRANSPORT 6.1 troubleShootinG If you still have a problem with your appliance after checking these basic troubleshooting steps, please contact an authorised service person or qualified technician. Problem Possible Cause Solution Check the household fuse for the appliance. Hob control card’s display is blacked out.
  • Page 26: Transport

    6.2 tranSport If you need to transport the product, use the original product packaging and carry it using its original case. Follow the transport signs on the packaging. Tape all independent parts to the product to prevent damaging the product during transport. If you do not have the original packaging, prepare a carriage box so that the appliance, especially the external surfaces of the product, is protected against external threats.
  • Page 27: Technical Specifications

    7. TECHNICAL SPECIFICATIONS 7.1 enerGy fiChe Brand Model KF-66DIDD04IM1I-EN KF-66DIDD04BH1I-EN Type of Oven ELECTRIC Mass 44,9 Energy Efficiency Index - conventional 105,1 Energy Efficiency Index - fan forced Energy Class Energy consumption (electricity) - conventional kWh/cycle 0,75 Energy consumption (electricity) - fan forced...
  • Page 28 Brand Model KF-66DIDD04IM1I-EN KF-66DIDD04BH1I-EN Type of Hob Electric Number of Cooking Zones Heating Technology-1 Induction Size-1 Ø16,0 Energy Consumption-1 Wh/kg 182,0 Heating Technology-2 Induction Size-2 Ø16,0 Energy Consumption-2 Wh/kg 182,0 Heating Technology-3 Induction Size-3 Ø21,0 Energy Consumption-3 Wh/kg 182,0 Heating Technology-4...
  • Page 29 Service & Support Visit Our Website www.sharphome.eu UK Technical Support - Large Appliances helpdesk.GB@sharphomeappliances.com 0333 5777230 Republic Of Ireland Technical Support– Large Appliances Helpdesk.IE@sharphomeappliances.com 03335 777230 VESTEL Holland B.V. UK Branch, 1 Waterside Drive, Langley, Berkshire. SL3 6EZ VESTEL Holland B.V. Stationsplein 45, A2.191 3013 AK Rotterdam, The Netherlands.

This manual is also suitable for:

Kf-66didd04bh1i-en
