Summary of Contents for Westinghouse WSF6608XB
- Page 1 User Manual WSF6608XB DO NOT RETURN THIS PRODUCT TO THE STORE. If you have questions or need assistance, please call customer service. Contact details can be found on the last page of user manual.
-
Page 2: Table Of Contents
Products must be used, installed and operated in accordance with this manual. You may not be able to claim on the Westinghouse manufacturer’s warranty in the event that your product fault is due to failure to adhere this manual. -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS • Check whether the indoor electrical fuse system These warnings have been provided in the interest of safety. You is connected according to the regulations. MUST read them carefully before installing or using the appliance. Please read the user manual carefully and store in a handy place for •... -
Page 4: Safety Information And Recommendations
SAFETY INFORMATION AND RECOMMENDATIONS base chemicals; WARNING WARNING • Plastic items that are not heat-resistant, copper Do not leave your dishwasher’s door open, this may lead to accidents or tin coated containers; and injury. • Aluminium and silver objects (they may discolour, become dull); •... -
Page 5: Description Of Your Appliance
DESCRIPTION OF YOUR APPLIANCE Worktop Detergent and rinse-aid dispenser Upper basket with racks Lower spray arm Upper spray arm Lower basket Filters Sliding cutlery tray Rating plate Turbo Drying unit Control panel Ceiling spray rose TECHNICAL SPECIFICATIONS Capacity ................15 place settings •... -
Page 6: The Control Panel
THE CONTROL PANEL 8.Child Lock Indicator: Child lock is activated/deactivated by pressing select button (7) for about 3 seconds. When it is activated, all leds blink and “CL” is shown on Remaning Time Indicator (4) once. When it is deactivated, all lamps and “CL” blink twice. Child Lock indicator illuminates while the Child Lock is active. -
Page 7: Changing A Program
THE CONTROL PANEL NOTE: Do not open the door before the program ends. Changing a program If you would like to change the program when the NOTE: At the end of washing program-me, you can leave machine is already running. the door of your machine ajar to hasten the drying. -
Page 8: Installig The Machine
INSTALLING THE MACHINE Positioning the machine After the connections are made, the tap should be turned on fully and • When considering the location for the dishwasher, ensure that checked for water tightness. For the safety of your machine, make there is adequate space to enable loading and unloading of the sure to always turn off the water inlet tap after each wash program is dishes. -
Page 9: Water Drain Hose
INSTALLING THE MACHINE WARNING WARNING Water drain hose The water drain hose can be Electrical Connection connected either directly to the water drain hole or to the sink The plug of your machine should be connected to an earthed outlet that outlet spigot. - Page 10 INSTALLING THE MACHINE Adjust the machine feet according to the slope of the floor. Fit your machine by pushing it undercounter without letting the hoses get crushed or bent. WARNING WARNING Ensure the opening for the dishwasher is according to the following dimensions.
-
Page 11: Preparing The Machine For Use
PREPARING THE MACHINE FOR USE Prior to using the machine for the first time Combined detergent • Check whether the electricity and water supply specifications Detergent manufacturers also produce combined detergents called match the values indicated by the installation instructions for the “2 in 1”, “3 in 1”... -
Page 12: When You Stop Using Combined Detergents
PREPARING THE MACHINE FOR USE When you STOP using combined detergents In order to set rinse aid level, follow below steps: • Fill the rinse aid compartments. • Turn on the machine by pressing the On/Off button. • Select a suitable rinse aid setting. •... -
Page 13: Loading Your Dishwasher
LOADING YOUR DISHWASHER For best results, follow these loading guidelines. Loading the household dishwasher up to the capacity indicated by the manufacturer will contribute to energy and water savings. Manual pre-rinsing of tableware items leads to increased water and energy consumption and is not recommended You can place cups, glasses, stemware, small plates, bowls, etc. - Page 14 Upper Cutlery Basket The upper cutlery basket is designed for you to place forks, spoons and knives, long dippers and small items. The Upper Cutlery Basket is composed of three pieces; if you need to space for the dishes in the upper basket, you can slide the left or right part of the upper cutlery basket in order to obtain more space.
-
Page 15: Alternative Modular Basket Position
LOADING YOUR DISHWASHER Alternative modular basket position Alternative basket loads Lower Basket LOADING YOUR DISHWASHER Top Basket TIPS & INFORMATION TIPS AND INFORMATION Examples of incorrect loading LOADING YOUR DISHWASHER... -
Page 16: Program Descriptions
PROGRAM DESCRIPTIONS Program items SENSORWASH- SENSORWASH- SENSORWASH- NAME OF PROGRAM FAST 30’ DELICATE ECO* DUAL WASH TIMESAVE 50’ DELICATE DAILY HEAVY TYPE OF FOOD Lightly soiled Suitable for Standard Suitable for Suitable for Auto program Auto program for Auto program both lightly normally soiled for lightly soiled... -
Page 17: Maintenance And Cleaning
MAINTENANCE AND CLEANING Spray arms Make sure that the spray holes are not clogged and that no food waste or foreign object is stuck to the spray arms. If there Cleaning your dishwasher is important to maintain the machine’s is any clogging,remove the spray arms and clean them under service life water. -
Page 18: Failure Codes And What To Do In Case Of Failure
FAILURE CODES AND WHAT TO DO IN CASE OF FAILURE TROUBLE CODE POSSIBLE FAULT WHAT TO DO Make sure the water inlet tap is open and water is flowing. Separate the inlet hose from the tap and clean the filter of Water inlet system failure the hose. -
Page 19: Troubleshooting
TROUBLESHOOTING PROBLEM SOLUTION If one of program monitor lights is on and • Your machine’s door is open, shut the door. start/pause light is flashing If the program won’t start • Check if the plug is connected. • Check your indoor fuses. •... -
Page 20: Warranty
(c) ‘ASC’ means Electrolux’s authorised serviced centres; the Appliance; (d) ‘Westinghouse’ is the brand controlled by Electrolux Home Products In addition, Electrolux is not liable under this warranty if: Pty Ltd of 163 O’Riordan Street, Mascot NSW 2020, ABN 51 004... - Page 21 For more information on all Westinghouse appliances, or for dimension and installation information, call into your retailer, phone or email our customer care team or visit our website: AUSTRALIA service: 13 13 49 spare parts: 13 13 50 email: customercare@electrolux.com.au web: westinghouse.com.au...
