Page 1: Fcc 1
SensaSoft Curved Mirrors (Set of 2) SP7197 SensaSoft Curved Mirrors featured with optional SensaSoft Corner Platform (with legs) - SP7173 Waterless Color Column - CF7176 or Calming LED Bubble Tube - SP8371 (all optional additions sold separately) Installation Manual 82001 July 2024... -
Page 2: Table Of Contents
Contents Warnings Description Includes Installation (Mirrors) Installation Optional Products 7-10 Cleaning, Maintenance Guarantee Technical/Contact... -
Page 3: Warnings
Warnings All our equipment is designed for users with special needs. We suggest supervision at all times when using this equipment. For indoor use only. Do Not use free standing. The panels should be installed securely to the wall. Do not use any other power cord other than the one supplied. Before plugging in the power cord, ensure it is the cord supplied with your product. -
Page 4: Installation (Mirrors)
The wall panels sit on the floor and must be attached to the wall using the supplied brackets. If you are using the wall panels with a corner platform, velcro tabs connect the wall panels to the platform to keep the platform from sliding away from the wall panels. - Page 5 We recommend two people to lift the panel onto the wall brackets. Step 4 Identify the three brackets on the rear of the wall panel. Lift the panel onto the wall brackets.** The panel should stand on the floor if fitted correctly. The brackets stop the panel from tipping. **NOTE: Lift the panels gently and set slowly into place onto the wall brackets.
- Page 6 Step 5 Once the mirrors are securely connected to the brackets, slide the mirrors into the corner ensuring the cables from the Left Hand and Right Hand panels protrude from behind the panel from center front. These cables will be used to supply power to an optional bubble tube or waterless column. Right Hand Panel Left Hand Panel If the mirrors come without an optional, platform,...
-
Page 7: Installation Optional Products
Step 6 - Optional Corner Platform • The platform arrives with the legs unattached. • Remove the screws placed in the platform. Set them aside, you will need them. • Place the legs in the positions shown. • Using the same screws, secure the legs. Turn the platform right side up Note the Velcro Tabs that are used to attach to the mirror panels Step 7 - Optional Bubble Tube or Color Column... -
Page 8: Step 8 - Connecting The Cables
Step 8 - Connecting the Cables Connect cables as shown below. You cannot connect them incorrectly. Push the connectors together. IEC Male to Female Lead Insert Power Supply plug into base Cables from Under Mirrors Tube/Column Power Supply IEC Splitter From Power socket We recommend two people when lifting wall panels or platforms Step 9... -
Page 9: Step 11 - Connecting Power
Step 10 - Secure Velcro Tabs Velcro Tabs attach the platform to the mirrors. This keeps the platform from sliding away. Velcro Velcro Step 11 - Connecting Power The LED Calming Bubble Tube or Waterless Color Column requires an electrical outlet. You are supplied with a power cord. -
Page 10: Cleaning, Maintenance
Connecting other Sensasoft Product Every SensaSoft panel has an auxiliary lead to connect power to other Sensasoft panels. The entire range can run from one power outlet. To connect more panels, use the lead to the left of the wall panel. NOTE: If this lead is not being used, tuck it behind the panel so it cannot be tampered with. - Page 11 Information about products that generate electrical noise USA and Canada This device complies with FCC and industry Canada RF radiate exposure limits set forth for general population. It must not not be co-located or operating in conjunction with any other antennas or transmitters. This device complies with Part 15 of the FCC rules.
-
Page 12: Guarantee
Guarantee CONDITIONS OF GUARANTEE This guarantee is in addition to and does not in any way affect any statutory or other rights of consumer purchasers. If within the applicable guarantee period (as shown in 8 below) the appliance proves to be defective by reason of faulty design, workmanship or materials, we undertake subject to the following conditions to have the defective appliance (or any part or parts thereof) repaired, or at our discretion, replaced free of charge. -
Page 13: Technical/Contact
Technical This product does not require electricity. When the sensory equipment is installed it uses an IEC mains lead to supply power to the equipment. Please refer to the instruction manuals for each piece of equipment for electrical data and compliance information. Complies to: BS EN 60355-1 Generic EMC standards -...
