Fortin Electronic Systems KEY-OVERRIDE-ALL Quick Start Manual

LED Module Diagnostics :
On: Activated.
OFF: Not activated.
Flash: Not programmed.
Purple/White
Yellow/Black
Blue
Green
Yellow
White
1
Connector 1 (Black - 4 pins):
Determin the type of installation:
INSTALLATION
WITH
DATA-LINK
INSTALLATION
WITHOUT
DATA-LINK
Cut off one plug of the Data-Link connector, connect the red wire to +12V and the black wire to ground.
Connector 4 (White - 4 pins ):
FLASH LINK UPDATER
Connect with the for
web update.
Connect wire to Remote-Starter/Alarm
Copyright © 2008, FORTIN AUTO RADIO INC ALL RIGHTS RESERVED
Ford Explorer
Rx (Data In)
conn.
Tx (Data Out)
2
(-) While running
N.c.
Ignition
N.c.
Rede
conn.
Data-Link connector
Black
Blue
White
Red
+12V
Ground
Black
Blue
White
White/Black
N.c.
3
N.c.
Pink/Black
N.c.
conn.
N.c.
4
Web Update connector*
conn.
* Connector not supplied
Connect wire to vehicle
Technical support:
TEL: 514-255-HELP (4357)
FAX: 514-255-1367
Web: www.ifar.ca
2002-2005
4 3 2 1
Igniton barrel
PIN # DESCRIPTION
1 IGNITION +12V (N.C.)
2 GROUND (N.C.)
3 TX (Data)
4 RX (Data)
SEE www.ifar.ca (KEY-OVERRIDE-SL2
iNSTALLATION SUPPLEMENT) FOR VEHICLE WIRE
COLORS
Remote Starter or Alarm
1
Port Data Link Port
White
Pink
Back view of the module
OUTPUT INPUT
Neither the manufacturer or distributor of this module is
responsible of damages of any kind indirectly or directly
caused by this module, except for the replacement of this
module in case of manufacturing defects. This module must
be install by qualified technician. This instruction guide may
change without notice. Visit www.ifar.ca to get latest version.
KEY-OVERRIDE-ALL
WEB
UPDATE Made in Canada - Rev. A - 02 / 07 / 2008
W e b s i t e
ENCRYPTED TRANSPONDER BYPASS MODULE ( Self Learning )
Make the connections to the vehicle:
1
Connector 1 (Black):
1.A
Determin the type of installation:
- INSTALLATION WITH DATA-LINK
- INSTALLATION WITHOUT
1.B
Connector 2 (White): Make the connections
PROGRAMMATION Vehicle equipped with SMART KEY
10'
Remove all keys from key
remote cards.
Keep programming button pressed
2
while inserting connector 1
Insert connector 2 .
Release the programming button when the LED turns ON.
3
If the LED is flashing at this point the module is already Programmed
and can't be programmed again. (To prevent malicious use this module
can be programmed in only one vehicle.)
KEY#1
4 Insert the first functional key into
the ignition barrel and turn the ignition ON.
KEY#1
When the security light turns OFF, turn the key to
5 the OFF position and remove the first key from the barrel.
You have 5 seconds to complete the
following procedure
KEY 2 KEY 2 # #
6 Insert the second functional key into the
ignition barrel and turn the ignition ON.
KEY 2 KEY 2 # #
When the dash board security light turns OFF,
7
turn the key to the OFF position
second key from the barrel.
You have 10 seconds to complete one
8.a
of the following procedures
For MANUAL Transmission:
8.b
Ignition
Press and release the
12V
programming button.
The LED will flash 1 time.
For AUTOMATIC Transmission:
8.b
If the LED flashes 10 times, the module is
9
programmed.
If the LED turns ON, repeat from step 1.
: h t t p : / / w w w . i f a r . c a
DATA-LINK
Keep the card away from the vehicle
(10 feet/3 meters minimum) to proceed
with the programming procedure.
.
and remove the
With a jumper wire, apply power
(12v) to the vehicles ignition wire
until the dash board security
light turns OFF .
Remove the jumper.
Activate the remote starter.
