Fortin Electronic Systems PATS 2 Installation Manual

PATS 2
Copyright © 2006-2007, FORTIN AUTO RADIO INC
PATS KIT 2 FOR FORD & MAZDA TRANSPONDER BYPASS

WIRING / CONNECTION GUIDE

WIRING / CONNECTION GUIDE
START HERE
1
Vehicle harness
Connector 1 (Black):
Remove the covers surrounding the ignition barrel.
Peel off the adhesive back of the ring, place it on the ignition barrel.
(Secure the wire with tie-wrap.)
Connector 2 (White):
2
Connect the red wire to 12V constant.
Connect the black wire to "Ground out when running".
#1
3
You have 5 seconds to complete the following procedure
#1
4
#2

VEHICLE FITGUIDE

VEHICLE FITGUIDE
VEHICLES YEARS OF VEHICLE COMPATIBILITY
Ford 2000
Escape
Focus
Thunderbird
Jaguar 2000
XJ8
XType

TECHNICAL SUPPORT / INFORMATION

TECHNICAL SUPPORT / INFORMATION
Neither the manufacturer or distributor of this module is responsible of damages
of any kind indirectly or directly caused by this module, except for the
replacement of this module in case of manufacturing defects. This module must
be install by qualified technician. This instruction guide may change without
V
notice. isit www.ifar.ca to get latest version.
PATENT PENDING : Canada : 4,419,697 USA : 60/449.414
ALL RIGHTS RESERVED
1
Red
Black
2
Blue
3
1
ANTENNA (RING)
Connect wire to vehicle

INSTALLATION AND PROGRAMMING INSTRUCTIONS

INSTALLATION AND PROGRAMMING INSTRUCTIONS
FORD PATS
Insert first key into ignition barrel
and turn the ignition ON
ignition ON until the security light
turns OFF .
Turn the key to the OFF position and
remove the first key from the barrel.
Insert the second key into the
ignition barrel and turn it to the
ignition ON.
Keep the ignition ON until the
security light turns OFF.
2001 2002 2003 2004
2001 2002 2003 2004
12V Battery (+)
(-) While running
N.C
Connect wire to Remote-Starter/Alarm
You have 10 seconds to complete the following procedure
#2
5
. Keep the
Theft
6
Note : If you try to start the engine with a improperly programmed
PATS, you will have to turn the ignition On for more than 1 minute to
reset the system.
VEHICLES
2005
Lincoln
Lincoln LS
Mazda
Tribute
2005
Technical support:
TEL: 514-255-HELP (4357)
FAX: 514-255-1367
Web: www.ifar.ca
INSTALLATION GUIDE
Made in Canada - V3.0.g - June 29, 2007
W e b s i t e : h t t p : / / w w w . i f a r . c a
X2
Two (2) functional keys
required.
Keep the keys separate
while programming.
Each step must be
completed in the indicated
delay, otherwise the PATS
Kit will not be programmed
therefore it is necessary to
restart the procedure.
OUTPUT
Turn the key to the OFF position and
remove the second key from the
barrel.
Activate the remote starter with the
PATS Kit connected.
The PATS Kit is now
programmed.
If the programming procedure is
successful, the engine will be running
and the Theft light will turn OFF.
If the programming procedure is not
successful, the engine may run but
the Theft light will flash. If so you
must repeat from Step 1.
YEARS OF VEHICLE COMPATIBILITY
2000 2001 2002
2000 2001 2002
INPUT
2003 2004 2005
2003 2004 2005
