Installation manual :
- SPH-EVO950DAB-RM
- SPH-EVO107DAB-RM
- SPH-DA97DAB-RM
Compatible with vehicles equipped with original car radio and
steering wheel control / Compatible with vehicles without
original car radio and without steering wheel control.
Remove the empty slot, the frame and the
radio (screws x4)
Cables and connectors of the
original car radio
Interface
1
3
Installation Manual - Renault Master - V1.0.2
RENAULT Master from 2019
NISSAN Interstar from 2022
SPH-EVO950DAB pre-assembled for
RENAULT Master & NISSAN Interstar
Remove the 2 screws on the top side of the
frame to release the frame so that the
original radio can be removed.
Cables and connectors on the non-original versions.
No USB connector available & white connector
replaced by ISO FM
2
4
