Packing List
In addition to this guide, the package includes the following items:
iKAN-208A-IP65/iKAN-216A-IP65/
iKAN-224A-IP65 LED Display
RJ-45 Connector x 2
Waterproof Assembly
Technical Support
service@icpdas.com
www.icpdas.com
Installation Guide
For Desktop Web
iKAN-208A-IP65/iKAN-216A-IP65/
iKAN-224A-IP65 Quick Start
CA-039
I/O Cable
Resources
How to search for drivers, manuals and
spec information on ICP DAS website.
For Mobile Web
Model
Name
Model
Name
v1.0, March 2025
Wall Mounting Kit x 2
M4x6L
Screw x 12
Screw
Driver
P1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ICP DAS USA iKAN-208A-IP65
Summary of Contents for ICP DAS USA iKAN-208A-IP65
- Page 1 Quick Start v1.0, March 2025 Packing List In addition to this guide, the package includes the following items: iKAN-208A-IP65/iKAN-216A-IP65/ iKAN-224A-IP65 LED Display Wall Mounting Kit x 2 Screw RJ-45 Connector x 2 CA-039 M4x6L Driver Waterproof Assembly I/O Cable...
- Page 2 Ethernet Port (E2) I/O Connector Installing the Waterproof Assembly LED display is iKAN-208A-IP65/iKAN-216A-IP65/iKAN-224A-IP65 equipped with two RJ-45 waterproof connectors that are optional for use with E1 and E2 port. It can effectively protect the connection points from weather and climate.
-
Page 3: Connecting The Power Connector
Connecting the RJ-45 Connector After installing the RJ-45 Ethernet waterproof connector, insert the Ethernet cable and screw the RJ-45 waterproof into the receptacle. Hub/Switch Ethernet Port Connecting the Power Connector Here we recommend that you install a breaker (5V, 30A) between the DC power supply and the iKAN LED Display. - Page 4 Installing, Wiring and Connecting the I/O Connector The iKAN LED display is equipped with an I/O cable that provides access to RS-232, RS-485 and digital I/O signals. Wiring and Insert the I/O cable into the receptacle RS-232 x 1 RS-485 x2 I/O Connector Digital Input x 2 Digital Output x 2...
- Page 5 RJ-45 Ethernet Waterproof Installation Guide v1.0, March 2025 1. Remove the RJ-45 connector from the RJ-45 cable 2. Feed the end of the RJ-45 cable through the Sealing Nut, Seal, Screw Nut, Clamping Ring and Gasket Screw Clamping Gaske Seal Ring Sealing 3.
- Page 6 4. Wrap the Screw Nut around the Clamping Ring 5. Insert the Seal into the Clamping Ring 6. Push the Sealing Nut forward and Hand-tighten it to seal the assembly 7. Insert the RJ-45 cable into the RJ-45 connector...
