Operating Instructions
OLED TV
LZ1000H series
(image: TH-65LZ1000H)
For more detailed instructions, please refer to [eHELP]
(Built-in Operating Instructions).
How to use [eHELP]
≥
Thank you for purchasing this Panasonic product.
Please read these instructions carefully before operating this product and retain them
for future reference.
Please carefully read the "Safety Precautions" of this manual before use.
The images shown in this manual are for illustrative purposes only.
F0522HN0
(p. 24)
English
(image: TH-48LZ1000H)
TQB4GA0078
English
Advertisement
Table of Contents
Related Manuals for Panasonic LZ1000H Series
Summary of Contents for Panasonic LZ1000H Series
- Page 1 How to use [eHELP] (p. 24) ≥ Thank you for purchasing this Panasonic product. Please read these instructions carefully before operating this product and retain them for future reference. Please carefully read the “Safety Precautions” of this manual before use.
-
Page 2: Table Of Contents
Contents Be Sure to Read Important Notice ·················································· 4 Safety Precautions ·············································· 6 Accessories ························································ 9 Installing the TV ·················································10 Installing the wall-hanging bracket ·························13 Connections ······················································14 Identifying Controls ·············································19 First time Auto Tuning ·········································22 Watching TV ······················································23 How to Use eHELP ·············································24 FAQs ·······························································24 Maintenance ······················································25 Specifications ····················································26... - Page 3 The Bluetooth word mark and logos are registered ® trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Panasonic Holdings Corporation is under license. x.v.Colour™ is a trademark. Google is a trademark of Google LLC. YouTube and the YouTube logo are trademarks of Google LLC.
-
Page 4: Important Notice
≥ use of this product. perform the panel maintenance. During the panel maintenance, LED turns to orange. (p. 21) The Panasonic accepts no responsibility for the loss, etc., ≥ maintenance works as necessary. of data caused by disasters. Set aspect ratio to [4:3 Full] for 4:3 image. For details, ≥... - Page 5 Service as well as other device complies with applicable copyright to protect the rights or property of Panasonic. If you wish legislation in your country. Please refer to that legislation to know more about the processing of your information in...
-
Page 6: Safety Precautions
≥ ≥ Do not use an unapproved pedestal / mounting Do not touch the mains plug with wet ≥ equipment. Be sure to ask your local Panasonic hands. dealer to perform the setup or installation of approved wall-hanging brackets. ≥... -
Page 7: Radio Waves
• ALWAYS route cords and cables connected to physically damaged. If this occurs, contact your your TV so they cannot be tripped over, pulled or nearest Panasonic dealer immediately. grabbed. During setup, make sure that all screws are securely ≥... - Page 8 ∫ Built-in wireless LAN ∫ Ventilation Caution Caution Do not use the built-in wireless LAN to connect to any Allow sufficient space (at least 10 cm) around the TV in ≥ wireless network (SSID*) for which you do not have order to help prevent excessive heat, which could lead to usage rights.
-
Page 9: Use Conditions
Accessories ∫ When not in use for a long time Caution This TV will still consume some power even in the Off mode, as long as the mains plug is still connected to a Standard accessories live mains socket. Remove the mains plug from the wall socket when the ≥... -
Page 10: Installing The
Installing the TV Preparations Do not hold the screen panel part. ≥ ≥ Make sure not to scratch or break the TV. 48-inch model ≥ Do not place the TV temporarily on the floor or desk. A Assembly screw (4) Assembling the pedestal M5 ×... -
Page 11: Attaching The Cover
∫ Attaching the cover Be careful not to nip the cables between the TV and ≥ the cover. ≥ Do not apply load to the cover. To remove from the TV: ≥ English... -
Page 12: Attaching The Cable Cover
∫ Attaching the cable cover 55-inch model 65-inch model Be careful not to nip the cables between the TV and ≥ the cable cover. Do not apply load to the cable cover. ≥ English... -
Page 13: Removing The Pedestal
Installing the wall- ≥ To remove from the TV: hanging bracket Please contact your local Panasonic dealer to purchase the recommended wall-hanging bracket. ≥ Holes for wall-hanging bracket installation Rear of the TV 300 mm Removing the pedestal 300 mm... -
Page 14: Connections
Connections Basic connections ∫ AV devices External equipment and cables shown are not ≥ (DVD Recorder / Blu-ray Recorder, Set top box, etc.) supplied with this TV. For details, refer to [eHELP] (Search by Purpose > ≥ Please ensure that the unit is disconnected from the ≥... -
Page 15: Mains Lead
∫ Mains lead Connections for 4K / HDR compatible equipment AC 220-240 V 50 / 60 Hz Mains lead HDMI cable Cable tie (Bundled the mains lead) 4K / HDR compatible equipment Reproduces the image more precisely with the To loosen: ≥... -
Page 16: Other Connections
Connection for VRR/AMD FreeSync™ Other connections Premium compatible equipment ∫ DVD Player / Camcorder / Game equipment (VIDEO equipment) (Viewing) (Listening) HDMI cable VRR/AMD FreeSync™ Premium compatible equipment VRR (Variable Refresh Rate)/AMD FreeSync™ ≥ Premium provides smoother gaming experience with a b c d 3.5 mm low latency and without image stuttering, tearing. -
Page 17: Cable Arrangement
∫ Amplifier (listening with external speakers) Cable arrangement To enjoy multi-channel sound from external ≥ equipment (e.g. Dolby Digital 5.1ch), connect the Fix cables as necessary. ≥ equipment to the amplifier. For information about the When using the optional accessory, follow the option’s ≥... - Page 18 ∫ Fixing the cables using the cable clamp Connecting Bluetooth devices ® 55-inch model 65-inch model Registering Bluetooth devices ® This TV supports Bluetooth communications. ® Bluetooth devices that have been registered (paired) ® with this TV can connect to (communicate with) this TV. When registering (pairing) a Bluetooth ®...
-
Page 19: Identifying Controls
Identifying Controls ∫ If registration fails If registration (pairing) is not completed properly, try registering again. Display the menu bar and select [Main Menu], and Remote Control then select [Setup] Setup Main Menu 1 select 2 access Select the remote control setting menu in [System Menu] Select [Pairing] ≥... - Page 20 4 MY APP 19 APPS Assigns a favourite application. After setting, starts Displays [Apps] (applications list). ≥ ≥ the application easily by pressing this button. 20 TV Guide For details, refer to [eHELP] (Search by Purpose > ≥ 21 EXIT Home >...
-
Page 21: Voice Controls
Voice controls Indicator / Control panel The TV recognizes speech when you talk into the voice When pressing 4, 5, 6 buttons, the control panel guide ≥ control microphone, enabling you to perform operations appears on the right side of the screen for 3 seconds such as changing TV channels, adjusting the volume, to highlight which button has been pressed. -
Page 22: First Time Auto Tuning
First time Auto Panel maintenance Tuning Be sure to turn the TV off with the remote control to perform the panel maintenance. The panel maintenance automatically starts, and it takes approx. 10 minutes. During the panel maintenance, LED turns to orange. When the TV is turned on for the first time, it will ≥... -
Page 23: Watching
Watching TV Select the language Select [Home] Select [Home] for use in a home viewing environment. ≥ [Shop] is for shop display. Turn power on To change the viewing environment later on, the set ≥ will need to have all settings initialised by accessing [Shipping Condition]. -
Page 24: How To Use Ehelp
How to Use eHELP FAQs [eHELP] is the detailed operating instructions built into Before requesting service or assistance, please follow the TV, and gives a more detailed explanation for a these simple guides to solve the problem. better understanding of the operation of each feature. For details, refer to [eHELP] (Support >... -
Page 25: Maintenance
Do not allow the cabinet and pedestal to make contact with a rubber or PVC substance for a long time. This may degrade surface quality. About the inquiry Please contact your local Panasonic dealer for ≥ assistance. Mains plug If you make an inquiry from a place where this TV is not present, we cannot answer about contents that Wipe the mains plug with a dry cloth at regular intervals. -
Page 26: Specifications
Specifications Visible screen size (diagonal) 48-inch model ∫ TV 121 cm Model No. 55-inch model 139 cm : TH-48LZ1000H 48-inch model 65-inch model : TH-55LZ1000H 55-inch model 164 cm : TH-65LZ1000H 65-inch model Display resolution Dimensions (W × H × D) 3 840 (W) ×... -
Page 27: Operating Conditions
Receiving systems / Band name Built-in wireless LAN Digital Standard compliance and Frequency band DTMB IEEE802.11a/n/ac: 5 GHz band IEEE802.11b/g/n: 2.4 GHz band Security Analogue WPA3-SAE (AES) PAL B / G, D / K, H, I WPA2-PSK (TKIP/AES) SECAM B / G, D / K, K1 WPA-PSK (TKIP/AES) Channel coverage: UHF / VHF / Cable WEP (64 bit/128 bit) -
Page 28: Customer's Record
Warranty Service purposes. Model Number Serial Number English Web Site: http://www.panasonic.com Printed in Malaysia © Panasonic Entertainment & Communication Co., Ltd. 2022...
