- Page 1 INSTRUCTIONS FOR USE SECURITY CART SLIDING DOOR #INSTR-SECSLIDINGDOOR For Super Erecta assembly video scan here For MetroMax assembly video scan here For detailed instruction scan here...
- Page 2 Inside Clamp (x2) Right Door (x2) Left Door Bottom U-Channel & Hardware Bottom Channel Assy (x1) #1/4-20 Mounting Plate Nyloc Nut (x2) (x2) #1/4-20 Security Bracket Screw (x2) LH Door (x2) RH Door (x1) (x1) INSTR-SECSLIDINGDOOR REV A 05/24 www.metro.com...
- Page 3 Clamp Inside Clamp #10-24 Hex Nut Position Rail Mounts Around The Post Secure At The Highest Groove Under the Shelf Rail Mount #10-24 Flat Head Screw Fasten The Inside & Outside Rail Mount Components Together INSTR-SECSLIDINGDOOR REV A 05/24 www.metro.com...
- Page 4 1. Tilt the Left Door approximately 20 degree and rest the Door Rollers on the Back Channel of the Top Rail. 2. Let Bottom Of Door Swing Forward. LH Door Assy LH Door Assy Front Channel Back Channel INSTR-SECSLIDINGDOOR REV A 05/24 www.metro.com...
- Page 5 2. Secure Bottom U-Channel and Security #1/4-20 Bracket With #1/4-20 Screw Screw Security Bracket Left Door Bottom Channel 3. Secure Bottom U-Channel. Make Sure the Left Door is aligned in the Back of the U- Channel. INSTR-SECSLIDINGDOOR REV A 05/24 www.metro.com...
- Page 6 RH Door Assy Front Channel Back Channel 1. Align Top Shroud Cover With Slots Inside Rail mounts Rail Cover Rail Mount Slot 2. Secure With 2 Security Screws on each end. #10-24 Button Head Screw INSTR-SECSLIDINGDOOR REV A 05/24 www.metro.com...
- Page 7 Side and Right Door is on Right Side of Cart. Right Door Left Door 3. Rotate the Latch, till it 2. Lift the Latch upward. touches the Wire Loop. Wire Loop Latch Lock not included 4.Move the Latch down. INSTR-SECSLIDINGDOOR REV A 05/24 www.metro.com...
- Page 8 SECURITY CART SLIDING DOOR— INSTRUCTIONS FOR USE DOOR OPERATION - UNLOCKING 1. Lift the Latch upward. Latch 3.Move the Latch down. 2. Rotate the Latch back. INSTR-SECSLIDINGDOOR REV A 05/24 www.metro.com...
- Page 9 SECURITY CART SLIDING DOOR — INSTRUCTIONS FOR USE CAUTION • Always Use Handles To Open And Close The Doors. Failure To Do That Will Cause Injury To The Hand. THIS COMPLETES THE INSTALLATION OF SECURITY CART WITH SLIDING DOOR. INSTR-SECSLIDINGDOOR REV A 05/24 www.metro.com...
